Operation and Description of Function Settings

Operation and Description of Function Settings
16

Current Conditions Screen

This unit is designed to control the operation of the side wall curtains in a natural only
house. This is done by satisfying set temperature or temperatures if the optional
second sensor is used.
Below shows the default screen and will always show as long as other subject buttons
are not pressed.
T1 00.0 T2 00.0
1
Figure 6. Current Conditions Screen.
1. Current temperature from sensor 1.
2. Current temperature from sensor 2 (optional).

Set Temperature 1

Set Temp1 =00.0
1
Figure 7. Set Temperature 1 Screen.
1. Set Temperature 1 - this is the desired temperature that you chose to operate
your house at.The control will do its best to maintain this temperature by
operating the curtains accordingly. Maximum — 99.0°F (37.7°C), minimum —
40.°F (4.0°C).

Set Temperature 2

Set Temp1 =00.0
1
Figure 8. Set Temperature 2 Screen.
1. Set Temperature 2 (optional) - same as Set Temperature 1 BUTTON 3
.
Chore-Tronics NV Control
2
MT1558B
