- Page 1 -a patientlifter from TM04301 Molift Quick Raiser 2+ 09 English...
-
Page 2: Table Of Contents
Molift Group AS Appendix A ............14 Ole Deviksvei 44 Chassis w/ legs ..........15 0668 OSLO, Norway Teleph: (+47) 40001004 www.molift.com Fax: (+47) 40001008 info@molift.com Page 2 of 24 TM04301 Molift Quick Raiser 2+ 09 English - Rev B 01/2011... -
Page 3: General Advice
Molift Group AS will accept no liability for Safety regulations damages resulting from such acts. Heavy, long and/or sharp objects will have to be lifted and handled when repairing the lifter. -
Page 4: Technical Description
The button is pushed straight down to activate the emergency stop and is released by turning it clockwise. Page 4 of 24 TM04301 Molift Quick Raiser 2+ 09 English - Rev B 01/2011... -
Page 5: Lifting Column
The battery pack is placed in a special alumi- nium holder on the lifting column. See also the instructions for the charger. Only use original Molift Batteries for Molift lifters. Operating handle The height of the operating handle (which con-... -
Page 6: Service
LED. The owner is responsible to ensure proper logging and written verification performed by authorised service partner. Page 6 of 24 TM04301 Molift Quick Raiser 2+ 09 English - Rev B 01/2011... -
Page 7: Equipment And Special Tools
Equipment and special tools Replacement of parts Equipment The replacement of parts must only be carried See the Operator Manual for accessories and out by authorised dealers! equipment relating to the daily use of the lifter. Lifting motor, removing Special tools You will need: No special tools are required. • Hex key 5mm Procedure: •... -
Page 8: Wheels, Removing And Fitting
Ø115mm wheels You will need: • 19mm spanner • Loctite 2701 • Hot air gun • Disconnect all the wires from the circuit board Page 8 of 24 TM04301 Molift Quick Raiser 2+ 09 English - Rev B 01/2011... -
Page 9: Replacing The Contact Points In The Lifting Column
C is released repair as necessary. Contact Molift Group AS. • Pull out the holder carefully so that the wires are freed (about 5 cm) • Use the soldering iron to disconnect the con-... -
Page 10: Completing The Job
Please make copies of this and next page! Serial number of lifter:___________________________ Date Description of fault Repair Date/sign. Page 10 of 24 TM04301 Molift Quick Raiser 2+ 09 English - Rev B 01/2011... -
Page 11: Inspection Diagram After Service And Repair
Marked lift with safety sticker with month/year and certifi cate number for completed safety inspection. Inspecting person must sign safety sticker and this diagram. Inspection, repair and service should be done by a person certifi ed by, or on behalf of Molift Group AS. Always complete below:... -
Page 12: Parts Catalogue
Knee support small QR2/QR2+ (optional) 0541000 Battery 1340100 Battery Charger 1340005 Integrated battery charger adapter kit 1140105 Plug Europe 1140106 Plug Great Britain 1140104 Plug USA 1140107 Plug Australia Page 12 of 24 TM04301 Molift Quick Raiser 2+ 09 English - Rev B 01/2011... -
Page 13: Main Components
Main Components Appendix Page 13 of 24... -
Page 14: Appendix A
Screw DIN 7981F 4,8X9,5 ELZN 0220310 Label Safety Check 0620133 Cable clip self-adhesive 4,8 0220136 Strip 100x2,5mm nature 0440003 O-ring 10x2 0228120 Bearing (Double Cogwheel P3) Page 14 of 24 TM04301 Molift Quick Raiser 2+ 09 English - Rev B 01/2011... -
Page 15: Chassis W/ Legs
Added pos 48 and 49 EO 33/10 08.03.2010 TÅB Drawing name: Chassis complete QR Update of pos no 12.02.2009 TÅB Added pos 39 29.01.2009/TES Uppdate of list 21.01.2009 TÅB Released for production 10.09.2008 TÅB Molift Quick Raiser Rev. Description: Date/Sign. Approved: Appendix Page 15 of 24... -
Page 16: Appendix B
Handle QR1/QR2/QR2+ 0425000 Handle QR1/QR2/QR2+ (incl pos 2, 3, 4) 0458101 Hand Grip, V-shape arm QR 0235102 Adjusting Wheel M10/Ø50 0235107 Connection Bolt, Push Bar Page 16 of 24 TM04301 Molift Quick Raiser 2+ 09 English - Rev B 01/2011... -
Page 17: Lifting Column
200 kg Lifti Added pos 7 spirol Eo 22710 08.02.2010TÅB Assembly d Added dry time and text 01.09.2009 TÅB Changed glue, added pos 4,5 and 6 28.05.2009 TÅB Molift QR II Released for production. 25.10.2004 ORH MH Lie Rev. Description: Date/Sign. -
Page 18: Appendix C
Cable clamp Self-Adhesive 9,6 0410306 Bumpon Type SJ-5027 Grey 0420593 Panel holder for 5mm Diode 0421138 Bushing GFW-1517-17 0421139 Tape 3M Ring 0420135 Cable Gland 16x24x30 Page 18 of 24 TM04301 Molift Quick Raiser 2+ 09 English - Rev B 01/2011... -
Page 19: Cover With Electronics Qr2
28/08-2008 Drawing name: Cover with electronics QR2 SECTION A-A Added rubber ring 05.08.2009 TÅB SCALE 1 : 2 Update of drawing 22.12.2008 TÅB 08-105 Molift Quic Raiser Size Drawing number: Released for production 28.08.2008 TÅB Rev. Description: Date/Sign. Approved: Appendix... -
Page 20: Appendix D
0540120 Screw DIN965A Elzn 0540123 Nut w threads brass 0510302 Decal Wire red 0,75 L=750 Wire black 0,75 L=750 Heat crimp tube 1310306 Decal art.no Page 20 of 24 TM04301 Molift Quick Raiser 2+ 09 English - Rev B 01/2011... -
Page 21: Battery Holder
Drawing name: Battery holder and electro Pos 4, 5, 6 and 7 replaced by new 07.10.2008 TES pos 4 Changed drawing no 19.09.2008 TÅB Released for production 28.09.2007 TÅB Molift Quick Raiser Rev. Description: Date/Sign. Approved: Appendix Page 21 of 24... -
Page 22: Knee Support Complete
Drawing n Added control information EO80/10 04.08.2010 TÅB Added pos 5 label art no 29.06.2009 TÅB Released for production 15.01.2009 TÅB Rev. Description: Date/Sign. Approved: Page 22 of 24 TM04301 Molift Quick Raiser 2+ 09 English - Rev B 01/2011... -
Page 23: Electrical Diagram
Appendix F Electrical Diagram Page 23 of 24... - Page 24 Strohbogasse 8 Mediscan Systems Ltd 1210 Wien United Kingdom P.B Box 2195 Tel. 01-405 35 43 Meditec Molift Ltd 6 Hamanov St. Fax 01-406 81 02 Rehovot 76386 Hi Trac House www.bstaendig.at IL-76121 Rehovot Unit 1 Woodrow Business Centre Belgium www.mediscan.co.il...
