Operating manual
(Translation of the original version)
Matrix 900 TRS V B VB
Stolzenberg GmbH & Co. KG
Reinigungsmaschinen - Maschinenbau
Hamburger Str. 15 - 17
D-49124 Georgsmarienhütte
Telefon +49 (0 54 01) 83 53-0
Telefax +49 (0 54 01) 83 53-11
E-Mail: info@stolzenberg.de
Internet: www.stolzenberg.de
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for STOLZENBERG Matrix 900 TRS V B VB
Summary of Contents for STOLZENBERG Matrix 900 TRS V B VB
- Page 1 Operating manual (Translation of the original version) Matrix 900 TRS V B VB Stolzenberg GmbH & Co. KG Reinigungsmaschinen - Maschinenbau Hamburger Str. 15 - 17 D-49124 Georgsmarienhütte Telefon +49 (0 54 01) 83 53-0 Telefax +49 (0 54 01) 83 53-11 E-Mail: info@stolzenberg.de...
-
Page 3: Table Of Contents
Table of Contents Table of Contents Introduction............................3 Usage conformant with intended purpose ................3 Safety information ..........................4 Sweeper description ........................6 Sweeper description ......................6 Initial start-up ........................7 Operation............................8 Sweeping ..........................8 Height adjustment of the side brushes ................8 After sweeping ........................ - Page 4 Table of Contents 5.16 Technical Data ........................19 5.17 Disposal ..........................19 5.18 Accessories and spare parts .................... 19 5.19 Service ..........................19 5.20 Transport ........................... 20 EC Declaration of conformity (Translation of the original version) .......... 21 Matrix V B VB...
-
Page 5: Introduction
Introduction Introduction This operating manual contains instructions for using the hand-operated sweeper. Our products are subject to continuous improvement. Therefore, design changes that were made after this manual went to print could not be incorporated. If you have any questions, please contact our Service department. -
Page 6: Safety Information
Safety information Safety information The machine should only be used in a flawless state, as well as in keeping with its intended purpose, in a safety- conscious and risk-conscious manner and in compliance with these operating instructions. In addition to the operating manual, please heed general le- gal and other binding regulations for accident prevention and environmental protection. - Page 7 Safety information Charge flat batteries directly after use and only in well- ventilated rooms. Keep naked flames and electrical sparks away from the charging area, since a highly-explosive electrolytic gas mix- ture is generated when batteries are being charged. Note that the accumulator batteries are filled with battery ac- Batteries should always be kept clean and dry to avoid leakage currents! Never short-circuit battery poles! Smoking, eating and drinking should be avoided in the vicin-...
-
Page 8: Sweeper Description
Sweeper description Sweeper description Sweeper description The battery-operated sweeper has been equipped with two side brushes and two counter-rotating brush rollers. The sweeping mechanism features two side brushes which convey the refuse to the two brush rollers that are mounted parallel to the direction of motion. -
Page 9: Initial Start-Up
Sweeper description Initial start-up Unpacking and assembly Open the packaging and carefully lift the machine off the pallet. CAUTION! Danger of Injuries! Reach under the frame of the machinery to lift it. There is a risk of injury if you attempt to lift the machinery at the hood, the side brush retainer, or the dustbin. -
Page 10: Operation
Operation Operation Sweeping Lower the side brushes until the tips touch the ground. To turn on the desired sweeping function, select and push the button for the desired function on the control panel. Cover must be closed to operate the sweeper. Always use the button on the left first, regardless of the model. -
Page 11: After Sweeping
Operation After sweeping Push the respective button on the control panel to turn off all the actuators and park the sweeper in a safe location. Empty the dustbin in a suitable container. Make sure the container is appropriate for this type of refuse. Insert the dustbin back into the sweeper. -
Page 12: Maintenance
Maintenance Maintenance Safety Information Only complete the type of maintenance work described in the following chapter. All other maintenance and upkeep work may only be carried out by the manufacturer or by companies and persons authorised by the manufacturer, who are familiar with the relevant safety specifications, because portable devices in industrial use are subject to the safety test according to VDE 0701. -
Page 13: Readjusting The Brush Rollers
Maintenance Readjusting the brush rollers The height of the brush rollers can be adjusted to obtain the best possi- ble cleaning results of the area to be swept and to effectively exploit the efficiency of the brush rollers. The brush rollers need to be lowered once the sweeping performance starts to wane due to wear and tear of the brush rollers, or if the area to be swept is not level (bumpy). -
Page 14: Removing The Brush Rollers
Maintenance Test the sweeper. Removing the brush rollers Every brush roller consists of two split shells with brushes. Screws join the split shells. Park the sweeper on level ground that has been designated (as- signed) for this purpose. ... -
Page 15: Installing The Brush Rollers
Maintenance Installing the brush rollers The split shells have square recesses, which retain the brush roller shaft. Position the first split shell under the square shaft of the brush roller. Make sure the shaft fits flush into the recess of the split shell. ... -
Page 16: Mounting The Side Brushes
Maintenance Make sure the sweeper has been secured from rolling away by ac- cident. Lift the side brushes. Reach under the side brushes. With your fingers squeeze together the snap-in fixtures in the centre of the side brush retainer. ... -
Page 17: Filter Cleaning
Maintenance Remove these wing nuts. Pull out the filter frame -4- with the filter -5- from the trim panel of the ejector -2- in the direction of the dustbin retainer 5.11 Filter cleaning To consistently attain the best possible cleaning results, you must al- ways clean the lamellar filter prior to emptying the dust bin. -
Page 18: Changing The Chain
Maintenance Swiftly slide these slides back and forth. These slides initiate a vibrating mechanism, which works loose the dust from the lamellar filter. The worked off dust drops directly into the dust- bin. To remove stubborn dirt, you should use a brush to clean off the filter or take out the filter and gently knock off the dirt. -
Page 19: Charging The Battery
Maintenance 5.13 Charging the battery. The machine has an on-board-charger. Position the machine on an approprate surface close to a socket. Switch the machine completely of. Make sure the machine is blocked against possible movement Open the cover. Connect plug 1 of the charger using the cable delivered with the ma- chine and connect plug 2 to the 230 V socket. -
Page 20: After Each 50 Operating Hours Also
Maintenance Check if machine is damaged or impaired in any way. Empty dust container. Search brush - roller tunnel for jammed particles and seized up dirt that may narrow the brush tunnel and obstruct free roller brush movement. -
Page 21: Technical Data
Maintenance Disturbance Possible Cause Remedy Brush rollers are jammed by dirt, Dismount brush rollers and clean cords, strings or the like them Check side brushes and remove obstacles Drive wheels obstructed Jack up the Sweeping & Suction Machine check wheels and free running In addition, the following applies to MTX-900-V TRS and MTX- Filter heavily polluted... -
Page 22: Disposal
Accessories and spare parts must conform to the requirements of the manufacturer. This is ensured by using genuine replacement parts. 5.19 Service Stolzenberg GmbH & Co. KG Hamburger Str. 15-17 D-49124 Georgsmarienhütte Telefon: 0049 / (0)5401 8353-0 Fax: 0049 / (0)5401 8353-11 www.stolzenberg.de... -
Page 23: Ec Declaration Of Conformity (Translation Of The Original Version)
EC Machine Directive 2006/42/EC, Appendix II, No. 1A Mr. Kai Stolzenberg – Management of the Stolzenberg GmbH & Co. KG, Hamburger Straße 15-17, D-49124 Georgsmarienhütte - is authorized to arrange technical information. We hereby declare that the machine described below corresponds, in its...
