InstallatIon and operatIon Manual
Thank you for purchasing an AirScape
natural, quiet, and energy-efficient cooling for many years.
Please take a few minutes to read over this manual and its accompanying documents to make sure you are pre-
pared to install the fan. In particular:
•
The green ThEORY Of OPERATION insert provides information critical to locating this fan within the home, and
to ensuring the home's attic has adequate ventilation for its operation.
•
This manual's ELEcTRIcAL REquIREmENTS section describes the electrical supply needed to operate this fan.
Before installing this fan, inspect it and all of its parts for any damage that may have been sustained
during shipping. do not Install daMaGed eQuIpMent. If you suspect this fan was damaged during
shipping, contact airscape technical support by phone at 1.866.448.4187, or email at experts@airscape-
fans.com.
Whole House Fans are designed to be installed within a home's attic, which makes them and their sub-com-
ponents extremely difficult to access once installed. test thIs fan outsIde of the attIc Before In-
stallInG It. connect the fan to its controls and to a power supply, and ensure it operates properly by
turning it on and cycling through its speed settings. If any difficulties are encountered, contact AirScape
technical support at the numbers listed above.
airscape 1.0 & 1.7 Whole house fan Installation Manual, 03222018
©AirScape, Inc., 2018. All Rights Reserved.
1.0 & 1.7
Whole house fan
whole house fan. Your fan has been designed to provide your home with
®
ORDER #:
S/N:
(Required for Warranty)
page 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for AirScape 1.0
Summary of Contents for AirScape 1.0
- Page 1 It. connect the fan to its controls and to a power supply, and ensure it operates properly by turning it on and cycling through its speed settings. If any difficulties are encountered, contact AirScape technical support at the numbers listed above.
-
Page 2: Safety Information
INSTALLATION section electRicAl RequiRements the 1.0 model requires an 120 volt, 1 amp, and the 1.7 model a 120 volts, 2 amp, uninterrupted power supply. These specifications must be taken into account when allocating power from existing circuits. - Page 3 And dimensions airscape 1.0 & 1.7 Whole house fan Installation Manual, 03222018 page 3 ©AirScape, Inc., 2018. All Rights Reserved.
- Page 4 Do not over tighten the screws, since this may reduce the vibra- tion isolation qualities of the foam gasket. figures 1 and 2 below show the 1.7 and 1.0, respectively, mounted to 16"...
- Page 5 Generation controls include a webserver that allows you to operate your fan from any smartphone, tablet, or com- puter with access to your home’s local area network (“LAN”); they are also necessary to use AirScape’s Tempera- ture Sensor Package (“TSP”) and SafeSpeed™ Pressure Interlock accessories.
- Page 6 The AirScape 1.7 and 1.0 each have two speed settings. Turn on the fan by touching FAN UP or TIMER UP. Its damper door(s) will open and there will be a 10 second delay before the fan begins to operate. The fan will start at minimum speed.
-
Page 7: Specifications
If problems are encountered, please take a few moments to run through the troubleshooting procedures described on the blue Warranty Card. If these suggestions do not work, contact AirScape technical sup- port at 1.866.448.4187 or by email at experts@airscapefans.com for further assistance.
