antenna shown with optional mast bracket!
Best.Nr. / part no.:
18760.LIN
Antenne für Wandmontage/
antenna with wall mount
18626.H optionale Masthalterung /
optional mast bracket
WiMo Antennen und Elektronik GmbH
Am Gäxwald 14, D-76863 Herxheim Tel. (07276) 9668-0 FAX 9668-11
http://www.wimo.com
CK-868LIN
868 MHz linear patch antenna
# 18760.LIN
This antenna covers both EU and USA RFID
bands. The antenna has been designed to be
waterproof and is easy to install. Polarisation is
linear (H or V).
1.2:1, giving a return loss better then 20dB.
Features:
Application:
VSWR is typically less then
860 - 960 MHz.
Extremely low VSWR return loss.
linear polarised.
Wall mountable.
RFID readers
GSM
e-mail: info@wimo.com
