ALARM
TOYOTA VEHICLE SECURITY SYSTEM
T T V V S S S S I I V V - - S S / / - - D D

INSTALLATION INSTRUCTIONS

MAIN KIT
FOR VEHICLES WITH DOUBLE LOCK
•
FOR VEHICLES WITHOUT DOUBLE LOCK
•
FITTING KIT (FOR 3-DOOR MODELS)
FITTING KIT (FOR 5-DOOR MODELS)
SUB KIT (SIREN AND RADAR)
Manual Ref. Nr. 2T4RA2-400
for
RAV4 (RHD)
PART NUMBER
FOR
**
TOYOTA MOTOR CORPORATION
A2
R
*
08585-12950
08585-12890
08586-4A810
08586-4A860
08586-1A890

Advertisement

Table of Contents
loading

Related Manuals for Toyota TVSS IV-S

Summary of Contents for Toyota TVSS IV-S

  • Page 1: Installation Instructions

    ALARM TOYOTA VEHICLE SECURITY SYSTEM T T V V S S S S I I V V - - S S / / - - D D INSTALLATION INSTRUCTIONS RAV4 (RHD) PART NUMBER MAIN KIT FOR VEHICLES WITH DOUBLE LOCK 08585-12950 •...

  • Page 2: Precautions

    RAV4 TVSS IV-S/-D PRECAUTIONS PLEASE READ THOROUGHLY THESE PRECAUTIONS BEFORE THE TVSS INSTALLATION • Be sure to disconnect the negative (-) • Use the correct tool when tightening lead from the battery terminals. bolts or nuts. • Do not pinch the rear wiring or harness •...

  • Page 3: Table Of Contents

    RAV4 TVSS IV-S/-D TABLE OF CONTENTS Precautions ................................System Components • Fitting Kit ................................• Main Kit ................................• Sub Kit (Siren and Radar) ..........................System Layout and Wire Harness Outline ....................Connector Arrangement of the TVSS Fitting Kit (Pin View) ..............

  • Page 4: Fitting Kit

    RAV4 TVSS IV-S/-D FITTING KIT 08586-4A810 / 08586-4A860 Pos. No. Description WIRE HARNESS (MAIN) WIRE HARNESS (SUB) RADAR SENSOR BRACKET SIREN BRACKET TVSS ECU BRACKET HOOD SWITCH BRACKET HOOD SWITCH GLASS BREAKAGE CONTROL UNIT (FOR 5-DOOR MODELS) MICROPHONE (FOR 5-DOOR MODELS)
  • Page 5 RAV4 TVSS IV-S/-D RAV4 (RHD) - 5 06-00...

  • Page 6: Main Kit

    RAV4 TVSS IV-S/-D MAIN KIT 08585-12890 / 08585-12950 Pos. No. Description TVSS ECU ECU PROTECTIVE BRACKET BLIND RIVET SUB KIT (RADAR AND SIREN) 08586-1A890 Pos. No. Description RADAR SENSOR SIREN SIREN BRACKET ( * ) NOT USED FOR RAV4 BOLT...

  • Page 7: System Layout And Wire Harness Outline

    RAV4 TVSS IV-S/-D SYSTEM LAYOUT AND WIRE HARNESS (MAIN) OUTLINE ( * ) ( * ) ( * ) ( * ) ( * ) For 5-Door Models only RAV4 (RHD) - 7 06-00...
  • Page 8 RAV4 TVSS IV-S/-D Pre-wire connector (5P male white) Pre-wire connector (6P male white) Pre-wire connector (8P male white) Ground terminal TVSS ECU connector (26P female grey) Glass breakage control unit connector (6P female clear) Radar sensor connector (4P female white)

  • Page 9: Connector Arrangement Of The Tvss Fitting Kit (Pin View)

    RAV4 TVSS IV-S/-D CONNECTOR ARRANGEMENT OF THE TVSS (PIN VIEW) (male) (male) (male) (ground terminal) (female) (female) (female) (female) (male) (female) (male) (ground terminal) (female) RAV4 (RHD) - 9 06-00...

  • Page 10: Vehicle Disassembly (Main)

    RAV4 TVSS IV-S/-D VEHICLE DISASSEMBLY Remove the passenger’s side front door scuff plate : Clip (4x) Fig. 1 Remove the passenger’s side cowl cover : Retainer (1x) Fig. 2 Remove the cover : Clip (3x) Pull down the glove compartment Fig.
  • Page 11 RAV4 TVSS IV-S/-D Remove the glove compartment : Screw (2x) Fig. 4 Remove the centre cluster panel : Clip (3x) : Bolt (4x) Fig. 5 Remove the audio assembly : Bolt (4x) Fig. 6 RAV4 (RHD) - 11 06-00...
  • Page 12 RAV4 TVSS IV-S/-D Remove the ashtray Remove the centre cluster under pan- : Clip (4x) : Screw (2x) Fig. 7 FOR 5-DOOR MODELS Remove the passenger’s side rear door scuff plate : Clip (3x) Fig. 8 FOR 5-DOOR MODELS Remove the seat belt floor anchor...
  • Page 13 RAV4 TVSS IV-S/-D FOR 5-DOOR MODELS Remove the luggage finish plate : Clip (5x) Fig. 10 FOR 5-DOOR MODELS Remove the cover from the rear LH side compartment Remove the screws (2x). Fig. 11 FOR 5-DOOR MODELS Remove the rear side compartment...

  • Page 14: Vehicle Disassembly (Engine Compartment)

    RAV4 TVSS IV-S/-D VEHICLE DISASSEMBLY (ENGINE COMPARTMENT) Remove the battery cover : Clip (6x) Fig. 13 Lift the cap and remove the positive ter- minal of the battery Fig. 14 Remove the battery : Nut (2x) : Hook bracket (2x) : Bracket (1x) Fig.
  • Page 15 RAV4 TVSS IV-S/-D Remove the battery carrier : Bolt (4x) Fig. 16 Loosen the cover : Clip (1x) Fig. 17 RAV4 (RHD) - 15 06-00...

  • Page 16: Wire Harness Installation (Main)

    RAV4 TVSS IV-S/-D WIRE HARNESS INSTALLATION (MAIN) Locate the pre-wired 5P female con- nector (white) and remove the tape. Locate the pre-wired 6P female con- nector (white) and remove the tape. Fig. 18 Remove the bolt Fig. 19 Connect the 5P male connector...
  • Page 17 RAV4 TVSS IV-S/-D Fit the ground terminal of the TVSS wire harness using the bolt Fig. 21 Locate the pre-wired 8P male connector ( white) and connect it to the 8P male con- nector of the TVSS wire harness Fig. 22...
  • Page 18 RAV4 TVSS IV-S/-D Secure the 6P connector to the vehicle harness using the wire tie (1x). Fig. 24 Secure the 5P connector to the vehicle harness using the wire tie (1x). Fig. 25 Attach the TVSS wire harness to the reinforcement using the wire ties (3x).
  • Page 19 RAV4 TVSS IV-S/-D Route the TVSS wire harness to the centre cluster area as shown. Fig. 27 FOR 5-DOOR MODELS Route and attach the TVSS wire harness to the vehicle harness using the wire ties (2x). Fig. 28 FOR 5-DOOR MODELS...
  • Page 20 RAV4 TVSS IV-S/-D FOR 5-DOOR MODELS Route and attach the TVSS wire harness to the vehicle harness using the wire ties (3x). Fig. 30 FOR 5-DOOR MODELS Route and attach the TVSS wire harness to the vehicle harness using the wire ties (4x).
  • Page 21 RAV4 TVSS IV-S/-D FOR 5-DOOR MODELS Route and attach the TVSS wire harness to the vehicle harness using the wire ties (2x). Fig. 33 RAV4 (RHD) - 21 06-00...

  • Page 22: Mounting The Status Monitor

    RAV4 TVSS IV-S/-D MOUNTING THE STATUS MONITOR Remove and discard the knockout panel from the centre cluster under panel Fig. 34 Fit the status monitor to the centre clu- ster under panel Fig. 35 Connect the 2P connector (clear) of...

  • Page 23: Mounting The Radar Sensor

    RAV4 TVSS IV-S/-D MOUNTING THE RADAR SENSOR Remove the screws and the bracket (2x) from the radar sensor Fig. 37 Fit the caps (2x) to the radar sensor Fig. 38 Remove the cap from the radar sensor Locate the trimmer in the small hole.
  • Page 24 RAV4 TVSS IV-S/-D Attach the butyl tape (2x) to the radar sensor bracket as indicated in the draw- ing. Fig. 40 Ensure to attach the radar sensor to the radar sensor bracket as shown. Fig. 41 Secure the radar sensor...
  • Page 25 RAV4 TVSS IV-S/-D Connect the 4P connector of the TVSS wire harness to the 4P con- nector of the radar sensor Wrap the 4P connectors into the foam tape Position the radar sensor shown. 75mm Fig. 43 Secure the radar sensor...

  • Page 26: Mounting The Glass Breakage Control Unit (Only 5-Door Models)

    RAV4 TVSS IV-S/-D MOUNTING THE GLASS BREAKAGE SENSOR CONTROL UNIT (Only 5-door models) Turn the sensor adjustment screw to position "5" for optimum sensitivity. Run the wire tie (2x) through the glass breakage sensor control unit NOTE: False alarm may occur if the sensitivi- ty is set too high.

  • Page 27: Mounting The Microphone (Only 5-Door Models)

    RAV4 TVSS IV-S/-D MOUNTING THE MICROPHONE (Only 5-door models) Fit the foam tape underneath the wire route as shown. Fig. 48 Connect the 2P connector of the microphone to the 2P connector of the TVSS wire harness Attach the microphone as shown.

  • Page 28: Mounting The Tvss Ecu

    RAV4 TVSS IV-S/-D MOUNTING THE TVSS ECU Connect the TVSS ECU wire harness 26P connector (grey) to the TVSS ECU Fit the protective bracket to the TVSS ECU with blind rivets (2x). Fig. 51 Fit the nose adapter fitting to the...
  • Page 29 RAV4 TVSS IV-S/-D Remove the screw Fig. 54 Position the TVSS ECU in the passen- ger’s side area as shown. Fig. 55 Refit the screw Fig. 56 RAV4 (RHD) - 29 06-00...

  • Page 30: Wire Harness Installation (Engine Compartment)

    RAV4 TVSS IV-S/-D WIRE HARNESS INSTALLATION (ENGINE COMPARTMENT) Remove the tape from the 6P connec- (grey). Remove the cap from the 6P connector (grey). Fig. 57 Remove and discard the bolt Fig. 58 Connect the 6P male connector (grey) of the TVSS wire harness...
  • Page 31 RAV4 TVSS IV-S/-D Wrap the 6P connectors in the foam tape Fit the ground terminal using the bolt Attach the TVSS wire harness the vehicle harness using the wire ties (3x) and (1x). Fig. 60 Attach the TVSS wire harness...

  • Page 32: Mounting The Siren

    RAV4 TVSS IV-S/-D MOUNTING THE SIREN Fit the siren bracket to the battery carri- with the bolts (2x) and the nuts (2x). Fig. 63 Fit the siren bracket to the battery carri- with the bolts (2x) and the nuts (2x).
  • Page 33 RAV4 TVSS IV-S/-D Attach the clip to the 6P connector of the siren wire harness Attach the clip to the battery carrier Fig. 66 Refit the battery carrier Connect the 6P connector of the TVSS wire harness to the 6P con-...

  • Page 34: Mounting The Hood Switch

    RAV4 TVSS IV-S/-D MOUNTING THE HOOD SWITCH Fit the hood switch bracket using the bolt (1x) and nut (1x). Fit the hood switch to the hood switch bracket Fig. 69 Connect the 2P connector of the TVSS wire harness to the hood...

  • Page 35: Attaching The Stickers

    RAV4 TVSS IV-S/-D ATTACHING THE STICKERS VEHICLES WITH DOUBLE LOCK Clean the inside surface of both front windows. Attach the stickers to the indicated lock sticker position. Fig. 71 VEHICLES WITHOUT DOUBLE LOCK Clean the inside surface of both front windows.
  • Page 36 RAV4 TVSS IV-S/-D NOTES ..............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................RAV4 (RHD) - 36 06-00...
  • Page 37 RAV4 TVSS IV-S/-D NOTES ..............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................RAV4 (RHD) - 37 06-00...
  • Page 38 RAV4 TVSS IV-S/-D NOTES ..............................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................RAV4 (RHD) - 38 06-00...
  • Page 39 GENUINE PARTS...
