ALARM
TOYOTA VEHICLE SECURITY SYSTEM
T T V V S S S S I I V V - - S S
Setting Guide
(LHD)
Manual Ref. Nr. T4SLSET-2-0
TOYOTA MOTOR CORPORATION

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TVSS IV-S and is the answer not in the manual?

Questions and answers

Related Manuals for Toyota TVSS IV-S

Summary of Contents for Toyota TVSS IV-S

  • Page 1 ALARM TOYOTA VEHICLE SECURITY SYSTEM T T V V S S S S I I V V - - S S Setting Guide (LHD) Manual Ref. Nr. T4SLSET-2-0 TOYOTA MOTOR CORPORATION...

  • Page 2: Table Of Contents

    Setting Guide TVSS IV-S TABLE OF CONTENTS Connection and Function Test ..................................... Radar Sensor Sensitivity Check and Adjustment ..........................Glass Breakage Sensor Sensitivity Check and Adjustment ..................... Selectable Functions ..........................................Changing the Functions ........................................- Arming mode ............................................ - Status monitor LED flashing ..................................

  • Page 3: Connection And Function Test

    Setting Guide TVSS IV-S CONNECTION AND FUNCTION TEST Verify the connections and functions of TVSS before mounting the TVSS ECU and refitting the removed parts. Follow all procedures below : TESTING MODE PREPARATION Check that all connectors and terminals of the fitting kit wiring harnesses (main) and (engine) are fitted correctly.
  • Page 4 Setting Guide TVSS IV-S BONNET SWITCH TEST (if fitted) 18) Open and close the BONNET. Ë Indicator lights will flash once. REMOTE CONTROL TEST 19) Press the “LOCK”-button of the remote control. Ë Indicator lights will flash once. Ë Doors will lock.
  • Page 5 Setting Guide TVSS IV-S STANDARD MODE REMOTE OPERATION Remove the key from the ignition key cylinder and make sure that all doors, boot and bonnet are com- pletely closed. Press the "LOCK"-button of the remote control once. Ë Indicator lights will flash once.
  • Page 6 Setting Guide TVSS IV-S 13) Wait for 15 seconds. 14) Insert your hand into the vehicle by the open window and wave it widely. Ë No response. n ALARM AND ALARM MEMORY 15) Press the “LOCK”-button of the remote control once.

  • Page 7: Radar Sensor Sensitivity Check And Adjustment

    Setting Guide TVSS IV-S RADAR SENSOR SENSITIVITY CHECK AND ADJUSTMENT Verify and adjust the radar sensor sensitivity before completing the installation of the TVSS and the refitting of the removed parts. Follow the procedures below: PREPARATION 1) Check that all connectors and terminals of the fitting kit wiring harnesses (main) and (engine) are fitted cor- rectly.
  • Page 8 Setting Guide TVSS IV-S (Continue from previous page) 5) Put your hand through the driver’s window and then wave your hand sideways across about 30 cm span several times (See figure 8). Trimmer Radar sensor Min. Max. Fig. 7 6) Is the alarm triggered ? Fig.

  • Page 9: Glass Breakage Sensor Sensitivity Check And Adjustment

    Setting Guide TVSS IV-S GLASS BREAKAGE SENSOR SENSITIVITY CHECK AND ADJUSTMENT Verify and adjust the glass breakage sensor sensitivity before completing the installation of the TVSS and the refitting of the removed parts. Follow the procedures below: PREPARATION 1) Check that all connectors and terminals of the fitting kit wiring harnesses (main) and (engine) are fitted correctly.
  • Page 10 Setting Guide TVSS IV-S (Continue from previous page) 3) Tap on the centre of the glass with slightly stronger force. 4) Is the alarm triggered ? 7) Turn the glass breakage sensor The sensor is too unsensitive, and must sensitivity adjustment screw one be adjusted.

  • Page 11: Selectable Functions

    Setting Guide TVSS IV-S SELECTABLE FUNCTIONS TVSS IV-S has 5 selectable functions. The functions indicated with u are the default settings. To change the settings refer to “CHANGING THE FUNCTIONS”, page 13. ARMING MODE : Automatic arming ON or OFF.

  • Page 12: Changing The Functions

    Setting Guide TVSS IV-S CHANGING THE FUNCTIONS ARMING MODE : Automatic arming ON or OFF. PREPARATION Check that all connectors and terminals of the fitting kit wire harnesses (main) and (engine) are fitted correctly. 2) Reconnect the negative battery cable.

  • Page 13: Status Monitor Led Flashing

    Setting Guide TVSS IV-S STATUS MONITOR LED FLASHING : Flashing while disarmed ON or OFF. PREPARATION Check that all connectors and terminals of the fitting kit wire harnesses (main) and (engine) are fitted correctly. 2) Reconnect the negative battery cable.

  • Page 14: Piezo Buzzer Defeat

    Setting Guide TVSS IV-S PIEZO BUZZER DEFEAT : Door AJAR warning ON or OFF. PREPARATION Check that all connectors and terminals of the fitting kit wire harnesses (main) and (engine) are fitted correctly. 2) Reconnect the negative battery cable. 3) Remove the key from the ignition key cylinder and push the “unlock” button of the remote control.

  • Page 15: Answer Back

    Setting Guide TVSS IV-S ANSWER BACK : Indicator light Indication ON or OFF. PREPARATION Check that all connectors and terminals of the fitting kit wire harnesses (main) and (engine) are fitted correctly. 2) Reconnect the negative battery cable. 3) Remove the key from the ignition key cylinder and push the “unlock” button of the remote control.

  • Page 16: Ignition Controlled Door Lock

    Setting Guide TVSS IV-S IGNITION CONTROLLED DOOR LOCK : Door locking while driving controlled by Ignition-ON. PREPARATION Check that all connectors and terminals of the fitting kit wire harnesses (main) and (engine) are fitted correctly. 2) Reconnect the negative battery cable.

  • Page 17: How To Verify The Latest Alarm Cause

    Setting Guide TVSS IV-S HOW TO VERIFY THE LATEST ALARM CAUSE It is possible to verify the latest alarm cause by the following procedure : PREPARATION Check that all connectors and terminals of the fitting kit wire harness (main) and (engine) are fitted correctly.

  • Page 18: Temporary Override

    Setting Guide TVSS IV-S TEMPORARY OVERRIDE The alarm system has a temporary override. It is possible to defeat the arming of the alarm system for maxi- mum one hour. PREPARATION Check that all connectors and terminals of the fitting kit wire harness (main) and (engine) are fitted cor- rectly.
  • Page 19 Setting Guide TVSS IV-S NOTES ..........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................(LHD) - 20...
  • Page 20 SETTING GUIDE TOYOTA TVSS IV-S NOTES ..........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................(LHD) - 21...
  • Page 21 SETTING GUIDE TOYOTA TVSS IV-S NOTES ..........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................(LHD) - 22...
  • Page 22 GENUINE PARTS PRINTED IN BELGIUM...
