Basic Wiring Examples - Alarm Lock NETWORXPANEL Installation Instructions Manual

One Door / One Keypad / Magnetic Lock or Electric Door Strike
As shown below, the Magnetic Lock and Fail-Safe Electric Door Strike wiring are identical. Do NOT use Fail-Secure devices for fire exit
doors! In the event of power loss, Fail-Secure devices remain "secure" (locked).
The keypad interrupts MAG LOCK (or Fail-Safe Electric Door Strike) power upon a successful User Code entry (or Prox Card presenta-
tion), initiating "Pass Time" (time the door remains unlocked). The default Pass Time is 3 seconds, but you can change this time to 10 or
15 seconds using Functions 52-54 (see the keypad programming instructions WI1855).
TSD = Transient Suppression Device (two supplied): Mount the TSD as close to the device to be protected as possible.
EGND AC IN WOA
T1 T2 T3 T4
One or Two Doors / Two Keypads or Two Wiegand Devices
Magnetic Lock and/or Electric Door Strike
The system is capable of controlling two doors using up to two of any combination of NETDK or NETPDK keypads, PLUS up to two Wie-
gand devices. Two auxiliary Form-C relays are available for up to two of any combination of magnetic locks and/or electric door strikes.
SECONDARY
WIEGAND**
EGND AC IN WOA
T1 T2 T3 T4
*TSD = Transient Suppression Device (two supplied): Mount the TSD as close to the device to be protected as possible.
®
**Example device shown: HID ProxPoint Plus Model 6005B.
10
B A S I C W I R I N G E X A M P L E S
RED GRN
WO W1 PWR GND
LED LED
WIEGAND INPUT
T5 T6 T7 T8 T9 T10
PRIMARY
PRIMARY
NETDK
WIEGAND**
RED GRN
WO W1 PWR GND
LED LED
WIEGAND INPUT
T5 T6 T7 T8 T9 T10
NETPDK
N/C
Emergency Exit
Switch (or Fire
H I D
Panel Relay)
HID CORPORATION
SNDR TX RX
N/O
(+) (–)
DRIVE (YEL) (GRN)
KYPD PWR
T11 T12 T13 T14 T15 T16
SECONDARY
NETPDK
N/C
Emergency Exit
Switch (or Fire
Panel Relay)
SNDR TX RX
N/O
(+) (–)
DRIVE (YEL) (GRN)
KYPD PWR
T11 T12 T13 T14 T15 T16
MAG LOCK
(OR
FAIL-SAFE
ELECTRIC
DOOR
STRIKE)
TSD*
Jumper
Wire
LOCK
N/C COM COM N/C
PWR
AUX RELAY MAIN RELAY
(+)
T17 T18 T19 T20 T21 T22
MAG LOCK
(OR
FAIL-SAFE
ELECTRIC
DOOR
STRIKE)
TSD*
Jumper
Wire
LOCK
N/C COM COM N/C
PWR
AUX RELAY MAIN RELAY
(+)
T17 T18 T19 T20 T21 T22
NETWORXPANEL Installation Instructions
ELECTRIC DOOR
STRIKE
(FAIL-SECURE)
NOT FOR FIRE EXITS
TSD*
Door
N/O
Position
Momentary
Contact
Switch
LOCK DOOR REMOTE
N/O
PWR POSITION RELEASE
CONTACT INPUT
(–)
T23 T24 T25 T26 T27
ELECTRIC DOOR
STRIKE
(FAIL-SECURE)
NOT FOR FIRE EXITS
TSD* Door
N/O
Position
Momentary
Contact
Switch
LOCK DOOR REMOTE
N/O
PWR POSITION RELEASE
CONTACT INPUT
(–)
T23 T24 T25 T26 T27
