AKO -52064 Manual

Optical and acoustic alarm and emergency lighting for low temperature or controlled atmosphere cold stores

Advertisement

Quick Links

Contents
Chapter 1: Introduction
Cahpter 2: Versions and references
Capitulo 3: Installation
3.1- Wall mounting
3.2- Panel Mounting
3.3- Installing the push button
3.4- Connection
3.5- Configuration
Chapter 4: Equipment description
Capitulo 5: Operation
Capitulo 6: Maintenance
Capitulo 7: Technical data
AKO Electromecànica thanks you and congratulates you on the purchase of our product, the development and manufacture of which
involved the most innovative technologies, as well as rigorous production and quality control processes.
Our commitment to achieving customer satisfaction and our continuous efforts to improve day by day are confirmed by the various
quality certificates obtained.
This is a high performance, technologically advanced product. Its operation and the final performance achieved will depend, to a great
extent, on correct planning, installation, configuration and commissioning. Please read this manual carefully before proceeding to install
it and respect the instructions in the manual at all times.
Only qualified personnel may install the product or carry out technical support.
This product has been developed for use in the applications described in the manual. AKO Electromecànica does not guarantee its
operation in any use not foreseen in this document and accepts no liability in the case of damage of any type which may result from
incorrect use, configuration, installation or commissioning.
Complying with and enforcing the regulations applying to installations where our products are destined to be used is the responsibility of
the installer and the customer. AKO Electromecànica accepts no liability for damage which may occur due to failure to comply with these
regulations. Rigorously follow the instructions described in this manual.
In order to extend the lifetime of our products to the maximum, the following points must be observed:
Do not expose electronic equipment to dust, dirt, water, rain, moisture, high temperatures, chemical agents or corrosive
substances of any type.
Do not subject equipment to knocks or vibrations or attempt to handle them in any way differently to that indicated in
the manual.
Do not under any circumstances exceed the specifications and limitations indicated in the manual.
Respect the indicated environmental conditions for operation and storage at all times.
During installation and on completion of this, avoid the presence of loose, broken or unprotected cables or cables in poor
condition. These may constitute a risk for the equipment and its users.
AKO Electromecànica reserves the right to make any modification to the documentation and the product without prior notification.
8
Page 9
Page 9
Page 9
Page 9
Page 10
Page 10
Page 10
Page 11
Page 12
Page 12
Page 13
Page 13

Advertisement

loading

Summary of Contents for AKO AKO-52064

  • Page 1 Complying with and enforcing the regulations applying to installations where our products are destined to be used is the responsibility of the installer and the customer. AKO Electromecànica accepts no liability for damage which may occur due to failure to comply with these regulations.
  • Page 2: Versions And References

    2.- Versions and references INPUTS PUSH BUTTONS MODELS TYPE POWER SUPPLY for push buttons INCLUDED AKO-52063 Alarm + push button AKO-52064 Alarm + push button AKO-520631 Alarm 230 Vac ±10% 50/60 Hz ± 3 Hz AKO-520641 Alarm AKO-156332 CAMCombi +...
  • Page 3 3.2 Panel Mounting (maximum panel thickness: 3 mm) - Remove cover T from the equipment (Fig.1). - Open the equipment and separate the front part of the housing (Fig.2). - Replace the gasket installed in the front panel with panel mounting gasket, bearing in mind its correct position. - Make a hole in the panel of the specified size (214 x 214 mm).
  • Page 4 If the cable supplied for connecting the push button is not used, use a V3V3-F type cable with three 0,5 mm2 wires and a minimum resistance of 300/500 V. The maximum distance is 100 m. Any of the push buttons may be replaced by a volt-free contact, after first switching off the wiring monitoring function on the input in question (see section 3.5) and connecting it as shown in the sketch.
  • Page 5: Equipment Description

    AKO5005, allows you to read the status of the alarm inputs and the battery and to change the equipment's MODBUS configuration. You can connect the alarm to a computer by connecting it to an existing AKO equipment network (MODBUS), or via an exclusive AKO “USB/RS485 Conversion Module”.
  • Page 6: Maintenance

    Double insulation between supply, secondary circuit and relay output. Cold room alarm - 1 push button......................AKO-52063 Cold room alarm - up to 4 push buttons ....................AKO-52064 Spare push button with 2 m of cable ....................AKO-52062 Spare power supply for AKO-52063 ....................AKO-520631 Spare power supply for AKO-52064 ....................AKO-520641...
