Hydrotech 89 HIMTLC Series Owner's Manual

Softener & tannins reduction system, new style parallel tank connector

Advertisement

Quick Links

New Style Parallel Tank Connector
1. Read all instruc ons carefully before opera on.
2. Avoid pinched o‐rings during installa on by applying (provided with install kit) NSF cer fied lubri‐
cant to all seals.
3. This system is not intended for trea ng water that is microbiologically unsafe or of unknown
quality without adequate disinfec on before or a er the system.
REVISION #
0
REVISION DATE May 4,2015
54862-1
89 HIMTLC
So ener & Tannins
Reduc on System
Canadian Head Office
655 Park St.
Regina, SK S4N 5N1
U.S. Head Office
8437 10th Avenue North
Golden Valley, MN 55427

Advertisement

loading
Need help?

Need help?

Do you have a question about the 89 HIMTLC Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Hydrotech 89 HIMTLC Series

  • Page 1 89 HIMTLC So ener & Tannins Reduc on System New Style Parallel Tank Connector 1. Read all instruc ons carefully before opera on. 2. Avoid pinched o‐rings during installa on by applying (provided with install kit) NSF cer fied lubri‐ cant to all seals.
  • Page 2: Table Of Contents

    Table of Contents PAGE Unpacking / Inspection Safety Guide Proper Installation Specification Before Starting Installation Installation Instructions System Start Up Programming Instructions About The System Maintenance Sanitizing Procedure Main Repair Parts Trouble Shooting Warranty Unpacking / Inspection Be sure to check the entire softener for any shipping damage or parts loss. Also note dam- age to the shipping cartons.
  • Page 3: Proper Installation

    Proper Installation This water softening system must be properly installed and located in accordance with the Installation Instructions before it is used. Do not install or store where it will not be psi, night time pressure may exceed the  exposed to temperatures below freezing or maximum.
  • Page 4: Specification

    Specifications 89HIMTLC-100 89HIMTLC-150 89HIMTLC-200 89HIMTLC-300  Continuous operation at flow rates greater than the service flow rate may affect capacity and efficiency performance.  The manufacturer reserves the right to make product improvements which may deviate from the specifications and descriptions stated herein, without obligation to change previously manufactured products or to note the change.
  • Page 5 Where To Install The Softener Place the softener as close as possible to is least likely to occur if a leak develops.  the pressure tank (well system) or water The manufacturer will not repair or pay for meter (city water). water damage.
  • Page 6 New Style Parallel Tank Connector The design of the parallel tank adaptor used in our dual-tank products (i.e. BIF/BAF, HTO, HEDP etc.) has been redeveloped. This new shorter version will also change the New flow directions. OUT— IN...
  • Page 7 Regeneration Process Explained Backwash: Backwash: During the backwash cycle, water enters tank #2 through the center of the distribution tube and flows up- wards in the tank#2 expanding the media bed and carrying any precipitated contaminants trapped within the bed. It then travels to tank #1 through the center of the distribution tube and flow upwards in tank #1 and then out to the drain.
  • Page 8: Installation Instructions

    Installation Instructions 1. If your hot water tank is electric, turn off the power to it to avoid damage to the element in the tank. 2. If you have a private well, turn the power off to the pump and then shut off the main wa- ter shut off valve.
  • Page 9 Installation...
  • Page 10 Note: As the picture shows, connect the inlet and outlet according to the arrow direc on which seeing from the top view, where you can see the mark of “Up flow” or “Down flow” on the standard inlet and outlet connector assembly. The installa on of 1“...
  • Page 11 So ener commissioning 1. This water so ening system must be properly installed(check the inlet and outlet, brine line, drain line , power supply)and located in accordance with the installa on instruc- ons before commissioning and pu ng into opera on. 2.
  • Page 12 Button Configuration MENU Flow Rate: 24.5 GPM 18-Apr-2015 10:35AM Remain: 1,280 GAL Capacity: 1,500 GAL Key Pad Configuration MENU This func on is to enter the basic set up informa on required at the me of installa on. This func on is to accept the values if changed and advance to the next page in the menu. These bu ons are used to increase or decrease the value of the se ngs while in the pro- + / - gramming mode.
  • Page 13 User Settings (Level I) Press MENU key. Press + or - to change menu option. Press SET to enter. Press + or - to change value. Press SET to accept. CAUTION: The values in this page are for illus- tration purpose and can be changed by the factory without notice.
  • Page 14 Manual Regenera on Press “■” key to ini ate a manual regenera on, the regenera on steps will be different according to different valve type: The regenera on steps of DOWN FLOW valve:backwash、brine +slow rinse、fast  rinse、service +refill; The regenera on steps of UP FLOW valve:brine +slow rinse、backwash、fast rinse、 ...
  • Page 15 Press any key will stop brine +slow rinse, and the valve will advance to the next regenera on process, Fast Rinse, the screen will display: Press any key will stop fast rinse, and the valve will advance to the next regenera on process, Refill, the screen will display: Press any key will stop service + refill, and the valve will advance to the next regenera on process: service...
  • Page 16 Controller assembly parts list: Part description Controller front cover assembly 89 PCB PCB absorb shock foam PCB fix screws 85HE mounting plate Screws 85 drive gear Connect screw 85HE main gear Brine gear screw Locating wheel assembly: three options Down flow wheel Up flow wheel Filter wheel 85HE brine gear...
  • Page 17 : Parts list of Standard connec on assembly Part description Part description Big O-ring of Adaptor 89 secure clip coupling Adaptor coupling of 89 89 valve connector control valve Small O-ring of adaptor Connector O-ring coupling...
  • Page 18 : Parts list of control valve body Part description 89 valve body 95 secure clip DLFC assembly:optional 1S、2S、3S、4S、 1#、3#、4#、5#、6# Drain elbow O-ring Drain elbow: 1/2”、 3/4” Brine valve injector stem assembly Spacer and seal assembly Three options of piston Down flow piston Up flow piston Filter piston...
  • Page 19 Three options of piston Down flow piston Up flow piston Filter piston Piston retainer End plug Piston pin Piston rod End plug retainer End plug retainer screws Brine line adaptor assem- bly:optional BLFC: 0.7gpm BLFC:0.95gpm Injector assembly: optional grey、purple、red、 white、blue、yellow Injector cover O-ring Injector cover Injector cover screws...
  • Page 20: Sanitizing Procedure

    Care of Your System To retain the attractive appearance of your new water softener, clean occasionally with mild soap solution. Do not use abrasive cleaners, ammonia or solvents. Never subject your sof- tener to freezing or to temperatures above 100°F. Resin Cleaner An approved resin cleaner must be used on a regular basis if your water supply contains iron.
  • Page 21 Brine Tank & Res-Up Feeder Assembly 80030022 64 OZ PRO RESCARE...
  • Page 22 Blank Page...
  • Page 23 Blank Page...
  • Page 24: Warranty

    Warranty Canature Watergroup guarantees that your new water conditioner is built of quality ma- terial and workmanship. When properly installed and maintained, it will give years of trou- ble free service. Five Year Limited Warranty Canature WaterGroup will replace the salt tank or cabinet tank, the fibreglass mineral tank, the ion exchange resin, and valve parts provided the failure is due to a defect in material or workmanship and not the result of damage from any of the conditions described in the gen- eral conditions of this warranty.
