1. Read all instructions carefully before operation.
2. Avoid pinched o-rings during installation by applying (provided with install kit) NSF
certified lubricant to all seals.
3. This system is not intended for treating water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or after the system.
REVISION #
0
REVISION DATE May 4,2015
#54586
565 Birm Water Filters
Canadian Head Office
655 Park St.
Regina, SK S4N 5N1


U.S. Head Office
8437 10th Avenue North
Golden Valley, MN 55427

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 565BM-75 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hydrotech 565BM-75

  • Page 1 565 Birm Water Filters    1. Read all instructions carefully before operation. 2. Avoid pinched o-rings during installation by applying (provided with install kit) NSF certified lubricant to all seals. 3. This system is not intended for treating water that is microbiologically unsafe or of unknown quality without adequate disinfection before or after the system.
  • Page 2: Table Of Contents

    Table of Contents PAGE Unpacking / Inspection Safety Guide Proper Installation Specification Before Starting Installation Sizing Requirements Installation Instructions System Start Up About The System Maintenance Main Repair Parts Trouble Shooting Warranty Unpacking / Inspection Be sure to check the entire unit for any shipping damage or parts loss. Also note damage to the shipping cartons.
  • Page 3: Proper Installation

    Proper Installation This water filter system must be properly installed and located in accordance with the Installation Instructions before it is used. Do not install or store where it will not be sweat-solder connections, as required by  exposed to temperatures below freezing or state and federal codes.
  • Page 4: Specification

    Specifications Specifications 585MM‐75 585MM‐100 585MM‐150 585MM‐200 585MM‐300 565BM-75 565BM-100 565BM-150 565BM-200 565BM-300 Service Flow Rates           Normal 4.0 gpm 5.0 gpm 7.0 gpm 10.0 gpm 12.0 gpm           Peak 5.0 gpm 7.0 gpm 10.0 gpm 12.0 gpm 15.0 gpm Micron Rating 15‐20 micron 15‐20 micron 15‐20 micron 15‐20 micron 15‐20 micron Backwash Flow Rate 4.0 gpm 5.0 gpm 7.0 gpm 10.0 gpm 14.0 gpm Filter Media Volume ‐ Cubic Feet 0.75 ft 1.0 ft 1.5 ft...
  • Page 5: Before Starting Installation

    Birm Filter A backwashing-type filter containing special media that causes the iron in the air-injected water to precipitate throughout the filter bed This process produces an iron removal ca- pacity of up to 30,000 ppm. The media re- quires no chemical regenerant for oxygen enrichment.
  • Page 6 Where To Install The Filter Place the filter tank as close as possible to ter damage.  the pressure tank (well system) or water A 120 volt electric outlet, to plug the in-  meter (city water). cluded transformer into, is needed within 6 Place the filter tank as close as possible to feet of the filter.
  • Page 7: Sizing Requirements

    Sizing Requirements Water Pressure The water system must have a pump big enough to deliver the recommended backwash rate with a minimum pressure at the inlet of the filter of 30 psi. If the existing system can- not do this, it must be upgraded to do so. Whenever possible, the water system should be adjusted to deliver at least 30 psi for even more satisfactory results.
  • Page 8: Installation Instructions

    Installation Instructions 1. If your hot water tank is electric, turn off the power to it to avoid damage to the element in the tank. 2. If you have a private well, turn the power off to the pump and then shut off the main wa- ter shut off valve.
  • Page 9 Filter Installation...
  • Page 10: System Start Up

    System Start-Up Key Pad Configuration SETTINGS  This function is to enter the basic set up information required at the  time of installation.  MANUAL REGEN  This button has two functions.  The first is to initiate an immediate or  delayed manual regeneration.  The second is while in programming  mode, pressing this key allows the user to change the value of each  setting.  DOWN / UP  Increase or decrease the value of the settings while in the  program‐ ming mode.  Start-up Instructions 1. Plug the valve into an approved power source. 2. When power is supplied to the control, the screen will display “WAITING PLEASE” while it finds the service position.
  • Page 11 Programming Instructions Backwash Frequency The table below can be used to help deter- owner to suite their individual needs with fre- mine the frequency of regeneration for Multi- quencies available from 1 – 99 days. Media and Taste & Odour filters. Use this ta- ble as a guide since individual circumstances To prevent bacterial build up in the media, will require more or less frequent regenera-...
  • Page 12: About The System

    Manual Regeneration (Step / Cycle Valve) If screen is locked, press and hold SETTINGS for 3 seconds to unlock. To initiate an imme- diate regeneration, press and hold the MANUAL REGEN key for 5 seconds. The valve will immediately start into manual regeneration. To initiate a delayed regeneration, press the MANUAL REGEN key once to turn on and a re- generation will be queued at the next pre-set regeneration time (i.e.
  • Page 13: System Configuration

    New Sounds You may notice new sounds as your filter operates. The regeneration cycle lasts up to 30 minutes. During this time, you may hear water running intermittently to the drain. Automatic Raw Water Bypass During Regeneration The regeneration cycle can last 30 minutes after which filtered water service will be re- stored.
  • Page 14: Maintenance

    Maintenance Maintenance of your new water filter requires very little time or effort but it is essential. Regular maintenance will ensure many years of efficient and trouble-free operation. 1. Periodically make sure your pump is performing satisfactorily to ensure sufficient water is available for backwashing the filter.
  • Page 15 Loading the Media Pak Place the distributor tube back down the center of the tank. NOTE: the top of this tube should be plugged with a rag or cork to prevent media from entering. Pour the bag of coarse gravel into the tank, and then pour the bag of fine gravel into the tank. It is important that the distributor tube is not moved or pulled out as it is not possible to put it down to the bottom of the tank once gravel or media are in the tank.
  • Page 16: Main Repair Parts

    Replacing Drain Line Flow Control (DLFC) 1. Remove the red clip that secures the drain line elbow. 2. Remove the BLFC washer from the elbow fitting. 3. Reassemble using the reverse procedure. Main Repair Parts REPLACEMENT PARTS - FILTER Replacement Part Number Part Description DWG # Quantity...
  • Page 18 Main Repair Parts - Connectors REPLACEMENT PARTS - CONNECTORS Replacement Part Number Part Description DWG # Quantity 60010020 3/4" NPT ELBOW 60010019 1" NPT STRAIGHT 60010023 3/4" NPT STRAIGHT 60010079 VALVE COUPLING INLET 60010101 VALVE COUPLING OUTLET (METER SIDE) 60010025 PLASTIC SECURE CLIP 60010046 BYPASS SS CLIP...
  • Page 19 Control Valve Exploded View Control Valve Exploded View...
  • Page 20: Control Valve Parts List

    Control Valve Parts List Item No. Part No. Part Discription Quantity 05056087 Screw-M5×12(Hexagon) 05056088 Screw-M5×16(Hexagon with Washer) 05056047 End Plug Retainer 05010081 Bnt65 Piston Rod 05056097 Piston Pin 05056023 End Plug 05056070 Quad Ring 05056024 End Plug Washer 05056022 Piston Retainer 05056181 Piston (Electrical) 05056104...
  • Page 21 Power Head Exploded View...
  • Page 22: Power Head Parts List

    Power Head Parts List Item No. Part No. Part Description Quantity 5056136 Screw-ST3.5×13(Hexagon with Washer) 5056014 Bnt65 Back Cover 5010045 Piston Stem Holder 13000426 Screw-ST2.9×13(Large Wafer) 5056139 Washer-3x13 5056005 Main Gear 5056083 Screw-M4x14 5056166 Screw-ST4.2×12(Large Wafer) 5056141 Washer-4x12 13111004 Washer-4x9 5056016 Refill Regulator 5056015...
  • Page 23: Trouble Shooting

    Trouble Shooting Issue Possible Cause Possible Solution A. Unit fails to initiate a  1. No power supply. Check electrical service, fuse, etc. regeneration cycle. 2. Defective circuit board. Replace faulty parts. 3. Power failure. Reset time of day. B. FILTER BLEEDS TASTE 1. By‐pass valve open. Close by‐pass valve. AND ODOR OR SEDIMENT 2. Electrical service to unit has been  Assure permanent electrical service (check  interrupted fuse, plug or switch) 3. Defective or stripped media bed Replace media 4. Quality of water has worsened Have water sample analyzed to determine  any change 5. Filter capacity too small Replace with larger unit or add another filter 6. Filter not backwashing enough Be sure control is not clogged or drain line restricted. Be sure water pressure has not dropped and that pump has sufficient capacity. 7. Leak between valve and central tube. Check if central tube is cracked or o‐ring is  damaged.  Replace faulty parts. 8. Internal valve leak. Replace valve seals, spacer, and piston  assembly. C. Low water pressure.
  • Page 24: Warranty

    Warranty Canature WaterGroup warrants that your new water conditioner is built of quality mate- rial and workmanship. When properly installed and maintained, it will give years of trouble free service. Seven Year Complete Parts Guarantee Canature WaterGroup will replace any part which fails within 84 months from date of manufacture, as indicated by the serial number, provided the failure is due to a defect in material or workmanship.
