GraceHoop²

Table of Contents

Customer Service Information . . . . . . . . . . . . . . . . . . 2
Care, Finishing and Storage . . . . . . . . . . . . . . . . . . . . 2
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Parts list (General Assembly and Hoop Assembly) . .3-4
Stand Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
Hoop Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9-10
Folding the GraceHoop 2005™ . . . . . . . . . . . . . . . . . 13
EdgeTool™ Assembly . . . . . . . . . . . . . . . . . . . . . . . . 14
Using the EdgeTool™ . . . . . . . . . . . . . . . . . . . . . . . . 14
Installing Fabric . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Copyright December 2005
Jim M. Bagley, Gracewood, Inc.
Reproduction Prohibited
Printed on 6-5-06
Quilting with The
2005
™
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GraceHoop 2 2005 and is the answer not in the manual?

Questions and answers

Related Manuals for Grace GraceHoop 2 2005

Summary of Contents for Grace GraceHoop 2 2005

  • Page 1: Table Of Contents

    Quilting with The GraceHoop² 2005 ™ Table of Contents Customer Service Information ....2 Care, Finishing and Storage ....2 Warranty .

  • Page 2: Customer Service Information

    Parts must be returned to The Grace Company, shipping prepaid using a company-issued RMA# , before we can replace them. We will promptly return the repaired or replaced part at our expense. Customers will never have to pay the cost of a part covered by the 5 year warranty.
  • Page 3 GraceHoop² 2005 General Assembly Parts List 1: Vertical Stand (1) 10: 1/4” Plastic Knob (2) 2: Front Foot (1) 11: Roller Bushing (10) 3: Back Foot (1) 12: Flat Washer 5/16” (8) 4: Height Adjust Arm (1) 13: Hex Bolt 5/16” x 4” (4) 5: Hoop and Arm Assembly (1) 14: Thin Nyloc Nut 5/16”...
  • Page 4 GraceHoop² 2005 Hoop Assembly Parts List 1: Ball Swivel Bottom (1) 14: Carriage Bolt 1/4” x 3” (2) 2: Arm (1) 15: Knurled Finger Nut (2) 3: 2” Ball (1) 16: Hex Jam Nut 1/4” (8) 4: Ball Swivel Dowel (1) 17: Carriage Bolt 1/4”...

  • Page 5: Stand Assembly

    Using the parts list as a reference, make sure all parts of your assembly are present. If something is missing or broken, contact The Grace Company at 1- 800-264-0644. We will promptly ship any needed Hoop arm adjustment knob item.
  • Page 6 NOTE!! It should not be necessary to use force in order to pivot the foot. IF IT IS DIFFICULT TO PIVOT THE FOOT: Check to make sure that you have moved the foot into the correct pre-pivot position before attempting to pivot the foot (see picture at bottom of previous page). Hold the foot in that position.
  • Page 7 Step 4: Unfold the front foot of the stand Loosen the knob on the front foot of the stand and lower the front foot into the horizontal position. Slide the front foot back into the back foot. (The tabs on the heel of the front foot will fi...
  • Page 8 Step 5: Position Ball Swivel Loosen ball swivel lock knob. Position ball swivel in vertical position as shown in the bottom picture. Re-tighten the ball swivel lock knob to secure the pivot ball into position. Ball Swivel Lock knob Rotation Swivel Lock Knob The pivot ball shown in vertical position...

  • Page 9: Hoop Assembly

    Step 6: Prepare the Stand for Hoop Placement Disassemble the ball swivel unit as described below. Using the allen wrench (provided) remove the cap nut from the ball swivel unit. Remove the top bracket clamp from the ball swivel unit. Remove the bottomw bracket clamp from the ball swivel unit.
  • Page 10 Brackets and clamps attached to hoop. NOTE: You should still be holding the bracket clamps in to place. Step 8: Attach Hoop To Stand Attach the hoop to the ball swivel using the cap nut previously removed from the ball swivel unit in step #6.

  • Page 11: Rotating And Adjusting The Gracehoop 2005

    Rotating And Adjusting The GraceHoop²™ 2005 There are four main ways to adjust the GraceHoop²™ 2005 to customize your working area. With the hoop swivel adjustment knob. With the hoop rotation adjustment knob. With the arm pivot adjustment knob. With the arm height adjustment knob. Each of the adjustment knobs listed above will allow you to adjust the GraceHoop²™...
  • Page 12 The Hoop Swivel Adjustment Knob: The hoop swivel adjustment knob allows you to angle the hoop. You may tilt it to the exact angle of comfort. Just loosen the hoop swivel adjustment knob, swivel the hoop until you fi nd the desired position, and then tighten the hoop swivel adjustment knob to secure the hoop at that angle.

  • Page 13: Folding The Gracehoop 2005

    Folding The GraceHoop² 2005 for Storage and Toting Loosen the front foot adjustment knob. Pull the front foot out just a bit, so that it is no longer interlocked with the back foot. Fold the front foot up to the stand. Make sure that the foot folds up snuggly against the stand leg to prevent movement in storage.

  • Page 14: Edgetool™ Assembly

    EdgeTool Assembly ™ Use the EdgeTool as an extension of your quilt while completing your borders and corners. Parts Needed: 2 – Cloth Sleeves (Muslin recommended (not included) Insert cloth through this slot to make the Cut two pieces of fabric to the following dimensions: sleeve for the EdgeTool™.
