- Page 1 INNOVATION AND INSPIRATION ON FIRE™ INSTALLATION, USE AND CARE MANUAL MODELS: TE1BQ36RS TE1BQ42RS TE1BQ54RS...
- Page 2 We recommend reading this manual before your first use to ensure safety, proper care and operation. At Twin Eagles, we want you to enjoy grilling and spending time together as much as we do – making memories that linger long after the grill cools down.
-
Page 3: Table Of Contents
CUSTOMER CARE GETTING STARTED Please record the product information below and ASSEMBLY INSTRUCTIONS refer to it when contacting Twin Eagles. BURNER INSTALLATION This information is found on the data nameplate, AIR SHUTTER ADJUSTMENT located on the bottom right hand side of the firebox FEATURES near the regulator. -
Page 4: Important Safety Instructions
à trois broches adéquatement mise à remove the third prong from this plug. la terre. Il ne faut pas couper ou enlever la broche de mise à la terre de cette fiche. Twin Eagles Service (562) 263-3600 | iv... -
Page 5: General Safety Requirements
For adjacent • The pressure regulator and hose assembly combustible construction extending above the supplied with the Twin Eagles Gas Grill must be counter-top surface, the minimum clearance used. Replacement pressure regulators and hose from sides and back of the grill is 18 inches. - Page 6 GRILL U-BURNER (STANDARD) SEAR ZONE BURNER INFRARED ROTISSERIE BURNER LOCATED UNDERNEATH THE BRI- (STANDARD) BEHIND GLASS QUETTE TRAYS LOCATED ON LEFT SIDE OF THE LOCATED IN THE REAR PANEL FIREBOX ABOVE THE HEX GRATES vi | Twin Eagles Service 562 - 263-3600...
-
Page 7: Getting Started
GETTING STARTED 1. Remove all packaging materials, labels and protective plastic film. DO NOT LEAVE UNIT IN THE SUN WITH PROTECTIVE PLASTIC FILM ON FOR AN EXTENDED PERIOD OF TIME AS IT WILL BECOME DIFFICULT TO RE- MOVE. 2. Check to ensure all grill accessories listed below are included. GRILL ACCESSORIES TE1BQ36RSN TE1BQ36RSL... -
Page 8: Assembly Instructions
• The warming rack may be used at a HI and LOW level position. The HI level is further away from the heat source while the lower level position is closer to the heat source. POSITION POSITION Twin Eagles Service (562) 263-3600 | 2... -
Page 9: Burner Installation
BURNER INSTALLATION CORRECT BURNER INSTALLATION The orifice is completely inserted into the venturi. U-burner bracket in proper position on the threaded stud. INCORRECT BURNER INSTALLATION The venturi is out of position and the orifice is Burner is out of position. The threaded stud not inserted into the venturi. -
Page 10: Air Shutter Adjustment
• If the flame is noisy and tends to lift away from the burner, indicating too much air, turn the air shutter clockwise. Remember to tighten the set screw prior to re-installing the burner. ENSURE THAT THE BURNERS ARE SITTING PROPERLY ON THE ORIFICES BEFORE LIGHTING THE BURNERS. SET TO LP SET TO NG Twin Eagles Service (562) 263-3600 | 4... -
Page 11: Features
FEATURES Your Twin Eagles Eagle One Grill is equipped with many new and advanced features that put it at the forefront of at home grilling technology. Understanding these features and how they function is critical to maintaining the functionality of these features. Below are descriptions of these new grill features and how they integrate into your grilling experience. - Page 12 These blue LEDs will change color from blue to yellow, to orange, and then to red. These colored LEDs indicate the relative temperature for that bezel’s burner zone. Yellow is low, orange is medium, and red is high tempera- tures. YELLOW ORANGE Twin Eagles Service (562) 263-3600 | 6...
-
Page 13: Gas Safety Requirements
GAS SAFETY REQUIREMENTS Each appliance is set and tested at the factory for the type of gas supply to be used. Identify the type of gas, either natural gas (NG) or Liquid Propane (LP) gas and make sure that the marking on the data plate (rating plate) matches the gas being supplied to the grill. -
Page 14: Lp Gas Hook-Up
The upper edge shall be no more than 5 in (127 mm) above the floor level. 3. Every opening shall have a minimum dimension so as to permit the entrance of 1/8 in (3.2 mm) rod. Twin Eagles Service (562) 263-3600 | 8... -
Page 15: Portable Lp Connection
PORTABLE LP CONNECTION One of the many features of the Twin Eagles grill base is the pullout slide pan for easy access to the LP gas tank. 1. To install the gas cylinder, pull out the slide pan and place the cylinder onto the pan. -
Page 16: Natural Gas Installation
For both natural and LP, the maximum inlet pressure is 14 in wc (3.5 kPa). SET TO NG SET TO LP Twin Eagles Service (562) 263-3600 | 10... -
Page 17: Leak Test
• Check to ensure that flexible hoses do not have any cuts and wear that may affect the safety before each use. Only the factory supplied hose and regulator must be used. Use only replacement regulator and hose assemblies specified by Twin Eagles. LEAK TEST... -
Page 18: Electrical Requirements
8. Never remove the grounding plug or use with an adapter of two prongs; and 9. Use only extension cords with three prong grounding plugs, rated for the power of the equipment, and approved for outdoor use with a W-A marking. Twin Eagles Service (562) 263-3600 | 12... -
Page 19: Locating The Grill
LOCATING THE GRILL This gas appliance is designed and certified for outdoor use only. Do not locate this grill under over- head combustible surfaces. When installed under overhead combustible surfaces, we recommend a venti- lating hood wider than the appliance be installed with a minimum distance of 36 inches above the cooking surface. -
Page 20: Windy Conditions
Damaged components such as wiring, control knobs, gas valves, etc. and the discoloration of the stainless steel by using the grill in windy conditions is not covered under the product warranty. Twin Eagles Service (562) 263-3600 | 14... -
Page 21: Insulation Jacket Cut-Out Dimensions
Do not build the grill under overhead combustible construction. If the grill is to be placed into combustible enclosure, an approved insulating jacket is necessary to prevent fire, property damage and bodily injury. Use only Twin Eagles insulating jacket. NOTE: When installing, use front right knockout to keep power cord cool. -
Page 22: Grill Cut-Out Dimensions
11 P5 34 25 * - ADD 5.00” TO ALLOW 24 25 FOR HOOD OPENING 11 P5 24 25 DETAIL SEE DETAIL (TYPICAL TO ALL TOP UNITS) WIDTH OF UNIT COUNTER TOP OVERHANG Twin Eagles Service (562) 263-3600 | 16... -
Page 23: Operating Instructions
OPERATING INSTRUCTIONS BEFORE LIGHTING THE GRILL WARNING DO NOT ATTEMPT TO LIGHT THE GRILL IF YOU SMELL GAS. • WARNING: IT IS CRITICAL THAT THE GAS BURNERS ARE PROPERLY INSTALLED WITH THEIR ORIFICES INSIDE THE BURNERS AIR SHUTTERS. If not properly installed, gas may leak outside of the burner that could lead to fire, potential damage to your grill and bodily injury. - Page 24 It is recommended to use a meat thermometer to check if the food is completely cooked. CAUTION: In sunny or heavy light environments, the flame from the infrared rotisserie burner may be difficult to see and verify complete ignition. Twin Eagles Service (562) 263-3600 | 18...
- Page 25 1. Push the switch located on the front panel to turn ON/OFF interior Halogen lights, the mood light, and bezel back lights. USING THE SMOKER BOX The Twin Eagles sealed smoker box can hold dry wood chips or liquids for hickory, mesquite or your favorite wood chips to give meat a smoky flavor. 1. Remove a grate.
-
Page 26: Cleaning & Maintenance
However, the conditions outlined above, along with neglect, can lead to surface corrosion or rust. • It is recommended that your Twin Eagles products be kept dry and covered when not in use. This is even more important when long-term storage is intended. - Page 27 CLEANING & MAINTENANCE - cont. GRATES The easiest way to clean the grates is to scrub them with a barbecue brush immediately after cooking is completed and the flame is turned off. Wear a barbecue mitt to protect your hands from the heat and steam.
- Page 28 1. The smell of gas in conjunction with the burner flames appearing yellow. 2. The grill does not reach temperature. 3. The grill heats unevenly. 4. The burners make popping noises. Twin Eagles Service (562) 263-3600 | 22...
-
Page 29: Eagle One Exploded View
EAGLE ONE EXPLODED VIEW 23 | www.twineaglesgrills.com... -
Page 30: Replacement Parts List
BULB, HALOGEN LIGHT S26310 ROTIS PLATE SPACER S14420 ROLLER BEARING S27236 WARMING RACK BRACKET S26308Y SPROCKET ASSEMBLY S27232 SPROCKET COVER S27225-36Y INFRARED GLASS ASSEMBLY, 36 S27225-42Y INFRARED GLASS ASSEMBLY, 42 S27225-54Y INFRARED GLASS ASSEMBLY, 54 Twin Eagles Service (562) 263-3600 | 24... - Page 31 REPLACEMENT PARTS LIST - cont. ITEM TE PART TE1BQ TE1BQ TE1BQ TE1BQ TE1BQ TE1BQ DESCRIPTION NUMBER 36RSN 36RSL 42RSN 42RSL 54RSN 54RSL S14532-36 INFRARED GLASS, 36 S14532-42 INFRARED GLASS, 42 S14532-54 INFRARED GLASS, 54 S27223-36 GLASS GASKET, 36 S27223-42 GLASS GASKET, 42 S27223-54 GLASS GASKET, 54 S27227-36...
- Page 32 .5 NIPPLE S12602 BRASS COUPLING S15303 NG REGULATOR S26713 REGULATOR BRACKET S15302-GR150 LP REGULATOR W/ HOSE S16366 ROTIS MOTOR S26349 ROTIS MOTOR HOUSING S26351 ROTIS HOUSING COVER S13932 CHAIN S26352 CHAIN GUARD S13301 U6-BURNER Twin Eagles Service (562) 263-3600 | 26...
- Page 33 REPLACEMENT PARTS LIST - cont. ITEM TE PART TE1BQ TE1BQ TE1BQ TE1BQ TE1BQ TE1BQ DESCRIPTION NUMBER 36RSN 36RSL 42RSN 42RSL 54RSN 54RSL S13350 U5-BURNER S13345 SEAR BURNER ASSEMBLY S13144 SEAR BURNER MESH SCREEN S26345 BURNER DOOR S27378WY U-BURNER FLASHTUBE S27380WY SEAR ZONE FLASH TUBE S21743 DIVIDER...
-
Page 34: Wiring Diagram
WIRING DIAGRAM Twin Eagles Service (562) 263-3600 | 28... -
Page 35: Troubleshooting Guide
TROUBLESHOOTING GUIDE BEFORE CALLING FOR SERVICE: If your Eagle One grill does not function properly, use the following troubleshooting guide before contacting your dealer for service. The troubleshooting guide may save the cost of a service call and the inconvenience of being without your grill. -
Page 36: Warranty
Twin Eagles will repair or replace parts found to be defective at no cost to the original purchaser. Warranty service must be performed by a Twin Eagles authorized representative during normal business hours. -
Page 37: How To Obtain Service
HOW TO OBTAIN SERVICE For service, please contact your Twin Eagles dealer or call Twin Eagles direct at (562) 263-3600 or fax (562) 802-3391 Mailing address: Twin Eagles, Inc. 13259 East 166th Street Cerritos, CA 90703 Visit us at www.twineaglesgrills.com Please provide: •... - Page 38 CUT HERE P/N: 17582D 01/20 Place Postage Here INNOVATION AND INSPIRATION ON FIRE™ Customer Service ATTN: Warranty Department 13259 East 166th Street Cerritos, CA 90703 Fax no. (562) 802-3391...
