- Page 1 MLP-35 Operator’s Manual Printek LLC 3515 Lakeshore Dr. St. Joseph, MI 49085 269-925-3200 www.printek.com Printek, LLC. A Company. Part Number 7685 Rev A...
- Page 2 This device fulfills the European standards requirements by complying with the Directive relating to electromagnetic compatibility and relating to low-voltage electrical equipment. Furthermore it fulfills the requirements for RoHS and RED where applicable. Conformity with the above mentioned Directives is indicated by the CE symbol attached to the device. Note: Conformity may be affected by: - using interface cables not complying with the specifications - non-observance of important instructions in the operator´s manual...
- Page 3 brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada.
-
Page 4: Table Of Contents
Content Packaging list ..................................5 Printer Parts ..................................5 1 Preparation before using..............................6 1.1 Battery installation ....................6 1.2 Charging the battery ................... 6 1.3 Loading Media ..................... 7 2 Using your printer ................................8 2.1 Power on ......................8 2.2 Paper Feed ...................... -
Page 5: Packaging List
2” paper (1 pc) Quick start Instruction Power adapter(1pc) Test paper roll (1 pc) Quick Start Instruction (1pc) Reference Printek website www.printek.com for MLP-35 Operators Manual Printer Parts TOP VIEW BOTTOM VIEW Paper door open button Battery door Display USB port/Charge Port... -
Page 6: Preparation Before Using
1 Preparation before using 1.1 Battery installation The battery needs to be fully charged prior to first use. After long-term storage, also fully charge the battery before use to ensure highest performance. Place battery into printer with the label facing inside. Press down until you hear an audible click. -
Page 7: Loading Media
1.3 Loading Media Before printing, please check the media type for printing. The printer prints labels by default, if you want to print continuous paper, you will need to set the Print Type to Continuous. Refer to the Configuration section of this manual. -
Page 8: Using Your Printer
2 Using your printer 2.1 Power on To power the printer on or off press for 2 seconds. 2.2 Paper Feed Feed paper by pressing on control panel. Continuous paper will perform a line feed. Label/Black mark paper will perform a form feed to next label. 2.3 Self-Test Press for 3 seconds to print a self test page... -
Page 9: Oled Display
2.5 OLED display Messages Status Display Buzzer Buffer has data Working Buffer is empty Working Print Ready Cover open Buzz/2s Head Up Paper run out Buzz/2s Paper Out Abnormal label positioning Calibrate Error No label gap detected Out Tear Error Print head overheats Head Hot Energy saving mode... -
Page 10: Setting Descriptions
Be sure the label roll is in the printer. Bluetooth Setup Version Bluetooth version Factory set (information only) BT Name Name displayed when MLP-35 selecting printer through Bluetooth connection PIN Code Passkey when connecting... -
Page 11: Installing Configuration Tool
3.3 Installing Configuration Tool Printek offers a Windows based configuration program, Printek LLC Printer Config Tool, to setup your MLP-35 printer. This can be downloaded from our web page, www.printek.com. Select Printek LLC Config Tool Setup 1.0.0.exe” and select installation path. -
Page 12: Using Configuration Tool
Click Install Click Finish. 3.4 Using Configuration Tool Open Printek LLC Config Tool... - Page 13 Click “Connection Config” and choose current connection port in the upper right corner. Set up relevant interface parameters. Click “Connect” box to connect to the printer. Click the “Settings” button to enter the Settings Menu.
-
Page 14: Configuration Settings
3.5 Configuration Settings Click on the items you wish to modify. Select the value and then click Save button complete settings. 3.6 Reset factory default settings Click the “Reset” button on lower left side of settings page. Click “OK” in pop-up confirmation dialog box. -
Page 15: Software Upgrade
4 Software upgrade 4.1 Software upgrade steps To upgrade software connect printer to the computer with USB cable. Open the Printek LLC Config Tool. Click “Upgrade” Click “Browse” to select the firmware file. After selecting the file click “Start”. -
Page 16: Hexadecimal Mode
After the update, the Printek LLC Config Tool pops up to tell you that the update is complete. The printer automatically restarts. 4.2 Hexadecimal Mode: To enter hexadecimal, in the boot state, press power key twice quickly. To indicate the printer has entered hexadecimal mode, the following will print;... -
Page 17: Communication
Wireless: Bluetooth or Wi-Fi 5.1 USB Plug the USB end of cable into the host USB port and plug universal type C connector to the printer 5.2 Bluetooth The MLP-35 has a 4.0/CLASS 2 (10m) Bluetooth communication interface. Device name：MLP-35-XXXX... -
Page 18: Wi-Fi
5.3 Wi-FI The MLP-35 supports WiFi/IEEE 802.11 b/g/n standard communication. Wi-Fi can support AP mode and STA mode. The networking mode is convenient and diverse with a strong signal strength. Maximum distance for Wi-Fi communication is 300m. The default communication mode is AP mode. -
Page 19: Maintenance
6 Maintenance 6.1 Daily Printer Maintenance To clean outside case and paper bin, gently wipe with moist cloth. Be sure to fully dry. Clean print head mechanism with thermal cleaning pen, or with a degreasing cotton with anhydrous alcohol. If you do not use the printer regularly, store battery separate from printer. 6.2 Use and storage of paper Avoid storing paper in direct sunlight or in high temperature. -
Page 20: Maintenance
7 Maintenance 7.1 Troubleshooting Problem Possible Cause Solution Press the power The battery has not been installed correctly. Install the battery correctly. button and the The battery has run out of power. Charge immediately. printer does not work. The battery has run out of power. Charge or replace the battery Printer immediately. -
Page 21: Printer Specifications
8 Printer Specifications Printing mode Directly thermal Printing Print width 72mm parameters Resolution 203dpi OLED screen Standard 128×32dot matrix Speed 3inch/s Emulation ESC/POS、JPL、ZIC、ZPLII、CPCL Speed Character GB18030 Barcode One dimensional code：UPC-A、UPC-E、EAN-8、 QR code：QRCode、PDF417、DataMatrix EAN-13、Codabar、Code39、ITF、Code128、 Type Thermal paper / thermal label Code93 Thickness 60-150μm Media... -
Page 22: Accessories
9 Accessories Part Number Description 93361 Carrying Strap 34260008 Belt Loop Case 99635 Battery ?????? AC Adaptor...
