Printekmobile Interceptor 800 Quick Start Manual

Interceptor 800

Printer Features

Loading Paper

•
Pull up on paper door lever to release paper door.
•
Drop in paper with leader coming off top of roll as shown.
•
Tear paper up or down against tear edge.
I800 with Optional Battery - Charging & Use
•
Charge via the printers USB port using a standard
USB Micro-B charger.
•
Approximate Battery Life of 100 pages.
•
New batteries shipped in uncharged state.
•
Charge for 8 hours prior to first use.
•
USB port is also "data in" port in normal cabled use.

Printing Self-test

•
Turn off printer
•
&
Press and hold
•
Release when self-test begins to print.
© 2014 Printek LLC, 1517 Townline Road, Benton Harbor, MI 49022 PH: 269-925-3200 FX: 888-211-3400
Quick Start Guide
approximately 8 seconds.
Drivers, User Manuals, and SW Utilities available @ www.printek.com

Indicator Panel

Indicator Symbol Type
Power
Button
& LED
Battery
LED
Attention
LED
Paper
Button
Feed
Note: Wi-Fi and Bluetooth printers will include indicator light for
wireless communication.

I800 without Battery - Cable Installation

Note: Can be used with either 12V or 24V vehicle systems.
Function
Turns printer power on or off.
An indicator LED will light when
power is on.
Indicates battery-powered
operation.
Indicates paper jam or other
malfunction.
Advances paper from printer
unit.
USB port
External Power input port
Snap on USB port cover
after seating connectors
for extra strain relief.
Part 7414 Rev C
