SIM802 Hardware Design

1 Introduction

This document describes the hardware interface of the SIMCom SIM802 module that connects to
the specific application and the air interface. As SIM802 can be integrated with a wide range of
applications, all functional components of SIM802 are described in great detail.
This document can help you quickly understand SIM802 interface specifications, electrical and
mechanical details. With the help of this document and other SIM802 application notes and user
guide, you can use SIM802 module to design and set-up mobile applications quickly.

1.1 Related documents

Table 1: Related documents
SN Document name
[1] SIM802_ATC
[2] ITU-T Draft
recommendation V.25ter:
[3] GSM 07.07:
[4] GSM 07.05:
[5] GSM 11.14:
[6] GSM 11.11:
[7] GSM 03.38:
[8] GSM 11.10
[9] GSM 11.10
[10] AN_SerialPort
SIM802_HD_V2.01
Remark
SIM802_ATC
new Serial asynchronous automatic dialing and control
Digital cellular telecommunications (Phase 2+); AT
command set for GSM Mobile Equipment (ME)
Digital cellular telecommunications (Phase 2+); Use of
Data Terminal Equipment – Data Circuit terminating
Equipment (DTE – DCE) interface for Short Message
Service (SMS) and Cell Broadcast Service (CBS)
Digital cellular telecommunications system (Phase 2+);
Specification of the SIM Application Toolkit for the
Subscriber Identity Module – Mobile Equipment (SIM –
ME) interface
Digital cellular telecommunications system (Phase 2+);
Specification of the Subscriber Identity Module – Mobile
Equipment (SIM – ME) interface
Digital cellular telecommunications system (Phase 2+);
Alphabets and language-specific information
Digital cellular telecommunications system (Phase 2)；
Mobile Station (MS) conformance specification； Part 1:
Conformance specification
Digital cellular telecommunications system (Phase 2)；
Mobile Station (MS) conformance specification； Part 1:
Conformance specification
AN_SerialPort
