SIM802 Hardware Design
SIM_VDD
SIM_CLK
SIM802
SIM_RST
MODULE
SIM_DATA
Figure 27: SIM interface reference circuit with 6 pins SIM card

3.11.3 Design considerations for SIM card holder

For 6 pins SIM card, we recommend to use Amphenol C707-10M006 512 2 .You can visit
http://www.amphenol.com
SIM802_HD_V2.01
22O
22O
22O
22O
22O
22P 22P 22P
for more information about the holder.
52
220nF
SIM_VDD
SIM_CLK
SIM_RST
SIM CARD
SIM_DATA
MOLEX-91228
TVS
GND
12.01.2010
