SIM802 Hardware Design
DCS1800/PCS1900
DATA mode, GPRS ( 3 Rx, 2 Tx ) CLASS 10
GSM 850/EGSM 900
DCS1800/PCS1900
DATA mode, GPRS ( 4 Rx,1 Tx ) CLASS 8
GSM 850/EGSM 900
DCS1800/PCS1900
Class 10 is default set when the module work at data translation mode, the module can also work
at class 8 set by AT command.

5.5 Electro-Static discharge

The GSM engine is not protected against Electrostatic Discharge (ESD) in general. Therefore, it is
subject to ESD handing precautions that typically apply to ESD sensitive components. Proper
ESD handing and packaging procedures must be applied throughout the processing, handing and
operation of any application using a SIM802 module.
The measured values of SIM802 are shown as the following table:
Table 35: The ESD endure statue measured table
The test condition: temperature 25 ℃ , humidity 45%
Part
VBAT,GND
KBR0-4, DTR, RXD, TXD, RTS,
DISP_DATA, DISP_CLK
Antenna pad
Other pad
SIM802_HD_V2.01
@power level #19,Typical 90mA
@power level #0 <300mA,Typical 220mA
@power level #10,Typical 83mA
@power level #15,Typical 76mA
@power level #5 <550mA,Typical 420mA
@power level #10,Typical 225mA
@power level #19,Typical 142mA
@power level #0 <450mA,Typical 380mA
@power level #10,Typical 140mA
@power level #15,Typical 127mA
@power level #5 <350mA,Typical 270mA
@power level #10,Typical 160mA
@power level #19,Typical 120mA
@power level #0 <300mA,Typical 230mA
@power level #10,Typical 120mA
@power level #15,Typical 113mA
Contact discharge
±5KV
±4KV
±5KV
±3KV
64
Air discharge
±10KV
±8KV
±10KV
±6KV
