Summary of Contents for INNO View 950M
- Page 1 Revision 1.0...
-
Page 2: Table Of Contents
....................... 25 ARKER ETUP OVING 3.8....................................26 ALIBRATION 3.9......................................26 IMIT 3.9.1................27 IMIT ISPLAY ACCORDING TO EACH MENU SETTING 3.10.......................................29 RACE 3.10.1. T – D & M ......................30 RACE ISPLAY INNO Instrument Inc. Page 2 of 55... - Page 3 ..........................44 ALIBRATION 4.1.2..........................46 ALIBRATION 4.2........................48 ULTI ARGET TO INGLE IMIT ROCEDURE 4.2.1..................49 ULTI ARGET MPLEMENTATION ROCEDURE 4.2.2......................50 ULTI ARGET TO INGLE IMIT WARRANTY INFORMATION ........................52 INNO Instrument Inc. Page 3 of 55...
-
Page 4: General Information
View950M Multi-Scan 1. G ENERAL NFORMATION INNO Instrument Inc. Page 4 of 55... -
Page 5: Description
Inno-Instrument's VIEW950M is the right product to meet the needs of this market, and can be expanded to six ports if additional options are added on the base 4 port. It is optimized for VSWR measurements and includes the necessary functions in the mobile phone production line, allowing you to quickly and easily reset the measurement conditions as needed. -
Page 6: The Layout Of View900
View950M Multi-Scan Ext. For Jig Supply. DC 24V Out Jig Interface (32Pin) 19 "rack mountable 1.2. T VIEW900 AYOUT OF Image 3 types. Front photo, Rear photo, Top photo INNO Instrument Inc. Page 6 of 55... - Page 7 View950M Multi-Scan INNO Instrument Inc. Page 7 of 55...
-
Page 8: Instrument Overview
View950M Multi-Scan 2. INSTRUMENT OVERVIEW INNO Instrument Inc. Page 8 of 55... -
Page 9: Front
The rear part is configured as shown below. The rear left has a FAN for heat dissipation and a terminal for grounding. On the right side, power and data related connectors are arranged. INNO Instrument Inc. Page 9 of 55... -
Page 10: Specifications
Number of Test Port 4 Port (Optional Max 6 Port) Measurements VSWR, Return Loss Frequency Setting Resolution 10kHz VSWR Range 1 to 65 Return Loss Range +60dB to -60dB Resolution 0.01dB Max Input Level +25dBm INNO Instrument Inc. Page 10 of 55... - Page 11 Power Output DC 24V, Max 0.5A Sound Buzzer, Resonant Frequency 2300Hz Dimension 445.2mm(W) X 197.2mm(H) X 325.8mm(D) Weight About 11kg Operating Temperature 0℃ to +50℃ Storage Temperature -40℃ to +80℃ (-40℉ to +176℉) INNO Instrument Inc. Page 11 of 55...
-
Page 12: Menu Descriptions
View950M Multi-Scan MENU DESCRIPTIONS INNO Instrument Inc. Page 12 of 55... -
Page 13: Main Window Description
- Port Display Setting (Full & Multi) ① - Preset execution - Test alarm sound control ② - Trace indicating area (Full & Multi) ③ - Side Menu area ① - Port Display setup (Full & Multi) Selected Explanation INNO Instrument Inc. Page 13 of 55... - Page 14 LCD in the corresponding area. The figure below shows the switch of port 1 to full screen to explain '②-Trace display area'. INNO Instrument Inc. Page 14 of 55...
- Page 15 - Indicate setup data point - Indicate Run / Hold - Indicate nothing in case of Run - Indicate Cont. / Single - Indicate nothing in case of Cont. - Indicate Calibration On, Off INNO Instrument Inc. Page 15 of 55...
-
Page 16: Measure
Trace, the type of trace is applied. - Display Measure menu - When clicked, move to upper menu (VIEW950M) - Change Trace indication to VSWR form - Change Trace indication to Log/Mag form INNO Instrument Inc. Page 16 of 55... - Page 17 Measure setting confirmation can be checked by checking each Tr setting status at the top of each port trace chart. In the figure below, port 1 is set to VSWR, ports 2 to 4 are set to Log / Mag. INNO Instrument Inc. Page 17 of 55...
-
Page 18: Stimulus
Select items Select among Start Freq. / Stop Freq. / Center Freq. / Span - Click the item you want to change - Input window appears - Composed of trace chart and input number of currently selected port Enter setup values INNO Instrument Inc. Page 18 of 55... -
Page 19: Scale
- Amplitude range that can be set is as follows. (When selecting Full Scale, set to the range below) VSWR : 1~65 Log/Mag : +60dB ~ -60dB - The Top value cannot be less than the Bottom, and the Bottom value cannot be greater than the Top. INNO Instrument Inc. Page 19 of 55... -
Page 20: Scale Change Order
- Click the Auto Scale button - Scale automatically applied to the appropriate level Full Scale - Full Scale Select Port to Run - Click the Full Scale button - Scale Full Range INNO Instrument Inc. Page 20 of 55... -
Page 21: Sweep
XTERNAL RIGGER ETUP External Trigger setup - Click 'INT EXT' button to switch to EXT - After switching to EXT, press Ext. Delay is activated and switch to Single setting External Delay setup INNO Instrument Inc. Page 21 of 55... -
Page 22: Display
- When clicked, move to upper menu (VIEW950M) - Set Trace 1 or 2 - Tr1 yellow, Tr2 green - Minimize the program and display the Windows desktop Move to the previous menu INNO Instrument Inc. Page 22 of 55... -
Page 23: Num Of Trace & Windows Icon
Edit frequency can be input directly. Multi Target function is supported, and Single Limit Line can be set conveniently. Marker menu of VIEW950M is as follows. INNO Instrument Inc. Page 23 of 55... - Page 24 - Search the point passing with target value from top to the bottom of trace - Search the point passing through target value from top to the bottom of trace - Transmit (Target value ± Tolerance) with limit line transmitting function INNO Instrument Inc. Page 24 of 55...
-
Page 25: Marker Setup & Moving
Move Marker – Use Mkr Edit - Click on Mkr Edit - Directly input the position of the selected marker with the numeric key - Select another marker and set the position Move Marker – Move Touch INNO Instrument Inc. Page 25 of 55... -
Page 26: Calibration
In the Limit menu, you can set the main criteria for selecting good products and defects in the production process. It supports Max, Min, and Single settings, and can change settings for each screen display. The Limit menu is configured as shown below. INNO Instrument Inc. Page 26 of 55... -
Page 27: Limit Display According To Each Menu Setting
- Release text in red color if failing limit test off shown in the picture above if the test as above it passes - Failed areas in trace are changed to red color INNO Instrument Inc. Page 27 of 55... - Page 28 - Sound output in case of Fail - Silent when Pass Limit – Fail Sign - When fail signal is turned on, red color fail indication - Fail sign is displayed if any of the 4 ports fails INNO Instrument Inc. Page 28 of 55...
-
Page 29: Trace
- Save the current measurement result to Trace Memory - Indicate only the measured results in trace - Indicate only the trace saved in the trace memory - Indicate all the traces saved in memory and measured traces INNO Instrument Inc. Page 29 of 55... -
Page 30: Trace - Data & Mem Display
Copy Data to Memory - Select port and Tr - Perform Copy Data to Memory Data & Mem setup - Select Data&Mem in data display - Indicate both data trace and memory trace on the screen INNO Instrument Inc. Page 30 of 55... -
Page 31: Save
- Rename saved file is supported by Load 3.11.1. S If clicking 'Save Trace', 'Save Screen', or 'Save Config' from the Save menu, the side menu changes as below. Save Trace – Slot INNO Instrument Inc. Page 31 of 55... -
Page 32: Save File Type
Save Window appears for saving the file type, and it is possible to set the file name and the storage medium. Save As As soon as you enter the screen, the on-screen keyboard appears and you can set the file name using the on-screen keyboard. Save Trace – Save As INNO Instrument Inc. Page 32 of 55... - Page 33 VIEW950M / SaveData' folder and select '/ VIEW950M / SaveData / Trace' / VIEW950M / SaveData / Screen After creating '' / VIEW950M / SaveData / Config 'folder, files are saved in each folder. INNO Instrument Inc. Page 33 of 55...
-
Page 34: Load
- Display Load menu - When clicked, move to upper menu (VIEW950M) - Load saved Trace data - Load saved Screen capture - Load saved equipment configuration - Move to the previous menu INNO Instrument Inc. Page 34 of 55... -
Page 35: Slot Load
Slot Load is a function to load a slot saved by Slot Save. That is, 'Save Trace', 'Save Screen' and 'Save Config' load each file stored in Load Trace – Slot Load Screen – Slot Load Config – Slot INNO Instrument Inc. Page 35 of 55... -
Page 36: File Load
View950M Multi-Scan 3.12.2. F If clicking the load below each load menu, load window appears. Load Trace – Load Load Screen – Load Load Config – Load Load Window is as follows. INNO Instrument Inc. Page 36 of 55... -
Page 37: Inno Instrument Inc
Change the name of selected files. Virtual keyboard appears Delete selected files Delete all the files on the list window Copy USB of selected file Copy all the files on the list window to USB INNO Instrument Inc. Page 37 of 55... -
Page 38: System
- When clicked, move to upper menu (VIEW950M) - Select language (English, Chinese etc.) - IP setup for Ethernet communication - SW Upgrade function - Indicate equipment information - Move to the previous menu INNO Instrument Inc. Page 38 of 55... -
Page 39: Lan Setup
FW Upgrade – FW 선택 - Click the File Select button at the bottom of Upgrade screen - Open a navigation window to select files - Select and open the file - FW Upgrade after reboot INNO Instrument Inc. Page 39 of 55... - Page 40 - After selecting a file and clicking Open, file name confirmation window will appear. - Press OK to reboot & Upgrade INNO Instrument Inc. Page 40 of 55...
-
Page 41: Information
View950M Multi-Scan 3.13.3. I NFORMATION If selecting System> Information, information window will appear as below to check the basic information of the device. INNO Instrument Inc. Page 41 of 55... -
Page 42: Test Method
View950M Multi-Scan TEST METHOD INNO Instrument Inc. Page 42 of 55... -
Page 43: Calibration Procedure
Electronic Calibration kit - After selecting, click 'Start' button. <OSL Start screen> <E-Cal Start screen> Notice - In case of E-Cal, if USB of VIEW950 and E-Cal is not connected, Calibration Window can not enter. INNO Instrument Inc. Page 43 of 55... -
Page 44: Osl Calibration
- When Open is completed, a screen for connection of Short is displayed. - Remove Open and connect Short. - After connecting short to the port, click the Short Icon as shown on the left. - After clicking, short calibration will proceed as below. INNO Instrument Inc. Page 44 of 55... - Page 45 - After completing Open, Short, and Load, the corresponding icon on the screen will change to , and the 'Apply' button will appear on the bottom button array. - Click the 'Apply' button to apply the actual calibration. INNO Instrument Inc. Page 45 of 55...
-
Page 46: E-Cal Calibration
- Connect USB port of E-Cal to USB port of VIEW950M as shown on the left - Connect the RF port of E-Cal to port 1 of VIEW950M - Click the 'Run' button at the bottom INNO Instrument Inc. Page 46 of 55... - Page 47 < Proceed port 2> < Complete port 2> < Run port 2> Proceed E-Cal – 3 port < Run port 3> < Proceed port 3> < Complete port 3> Proceed E-Cal – 4 port INNO Instrument Inc. Page 47 of 55...
-
Page 48: Ulti Arget To Ingle Imit Rocedure
If the VSWR value is less than the predetermined value, it is defective. If the VSWR value is less than the predetermined value, it is processed as non-conforming product. INNO Instrument Inc. Page 48 of 55... -
Page 49: Multi Target Implementation Procedure
Setup value to be found in the target value entering window Close Multi Target Search If closing the input window after setting Target Value, Clicking Multi Target Search button will execute search based on the clicked point INNO Instrument Inc. Page 49 of 55... -
Page 50: Multi Target To Single Limit
- Target value setting to set - Perform Multi Target - Confirm activation of "Transfer to Single Limit" Tolerance setup - Single Limit Amplitude Low, High Range Setting - In other words, it is (Target Value ± Tolerance) INNO Instrument Inc. Page 50 of 55... - Page 51 - The Limit edit window appears, and the points that you have searched for in the list with multi target are automatically list-up - Edit the points required for measurement Setup related to limit in the limit menu INNO Instrument Inc. Page 51 of 55...
-
Page 52: Warranty Information
View950M Multi-Scan WARRANTY INFORMATION INNO Instrument Inc. Page 52 of 55... - Page 53 V96, V95S, V96S and AC adapter, be free from defects due to defective materials or workmanship for a period of 1 year from the date of shipment. During the warranty period, INNO Instrument Inc. will, at its option, repair or replace parts or products that prove to be defective.
- Page 54 The purchaser acknowledges that no oral-statements purporting to be warranties, representations, or guarantees of any product from INNO Instrument Inc. have been made by INNO Instrument Inc. or its dealer which in any way expands, alters or modifies the terms of the warranty set out herein. Any such statements do not constitute warranties, shall not be relied on by the purchaser, and are not part of the contract of sale.
- Page 55 www.innoinstrument.com...
