Contents

Product Specification .............................................................................................................. 2

Packaging List .......................................................................................................................... 3

Important Notice (Must Read) ............................................................................................... 4

Usage Instructions ................................................................................................................... 6

Screen Information .......................................................................................................... 6

Introduction of Other Parts ........................................................................................... 10

Key Pressing Operation ................................................................................................ 11

Start record mode .................................................................................................. 11

Display content of the instrument ........................................................................ 11

Reset Max and Min values ................................................................................... 14

Instrument Working Mode ............................................................................................ 16

Wait mode ............................................................................................................... 16

Record mode .......................................................................................................... 16

End mode ................................................................................................................ 17

Measurement mode .............................................................................................. 17

Other introduction .......................................................................................................... 18

PC connection ........................................................................................................ 18

Smart phone connection....................................................................................... 19

LED alarm ............................................................................................................... 20

LCD backlight ......................................................................................................... 20

LCD screen performance at low temperature ................................................... 21

Status indication when display is lost ................................................................. 21

Battery replacement .............................................................................................. 22

How to make the battery more durable .............................................................. 24

Table of Contents

Need help?

Do you have a question about the 320 and is the answer not in the manual?

Questions and answers

Summary of Contents for INNO 320

Page 1: Table Of Contents
INNO 320 User Manual Contents Product Specification ......................2 Packaging List .......................... 3 Important Notice (Must Read) ....................4 Usage Instructions ........................6 Screen Information ......................6 Introduction of Other Parts ................... 10 Key Pressing Operation ....................11 Start record mode ....................11 Display content of the instrument ................
Page 2: Product Specification
Product Specification Measuring range: -45 °C to 60 °C Temperature accuracy: ±0.3 °C (-15 °C ~ 60 °C) ±0.5 °C (-45 °C ~ -15 °C) Resolution: 0.1 °C Operation range: -45 °C ~ 60 °C Time accuracy: 2 mins / year Memory: 130,599 temperature values Battery type:...
Page 3: Packaging List
Packaging List 1 pcs INNO 320 instrument 1 pcs INNO 320 wall holder 1 pcs CR2 Li battery 1 pcs type C / Micro USB OTG adapter 1 pcs double-sided adhesive tape...
Page 4: Important Notice (Must Read)
Important Notice (Must Read) 1. For battery replacement, it is a must to use a new and high quality CR2 lithium battery for replacement. Otherwise the instrument cannot correctly estimate the battery life. 2. During replacing the battery, after the old battery is removed, the instrument still has residual power.
Page 5 7. When the instrument has just been used at low temperature environment, do not replace the battery when the temperature of the instrument has not returned to room condition. It is because the relatively warm outside air will enter the instrument from the battery compartment, which can produce moisture when the warm air meet the cold parts inside the instrument that will adversely affect the instrument.
Page 6: Usage Instructions
Usage Instructions Screen Information 1． When the symbol is displayed, it means that the measured temperature is higher than or equal to the pre-set upper temperature limit. When the symbol flashes, it indicates that the value displaying on the screen now is the pre-set upper temperature limit value.
Page 7 2． When the symbol is displayed, it means that the measured temperature is lower than or equal to the pre-set lower temperature limit. When the symbol flashes, it indicates that value displaying on the screen now is the pre-set lower temperature limit value.
Page 8 8． When the symbol is displayed, it means that the temperature unit is Celsius. 9． It is the numerical display area. 10． The symbol displays, that the symbol is flashing, that indicates the value displaying is the number of days the battery still can be used. 11．...
Page 9 15． When the symbol is displaying, it means that the displaying number is the year. 16． When the symbol is displaying, it means that the displaying time is the morning time. 17． When the symbol is displaying, it indicates that the displaying value is the highest temperature that has been recorded.
Page 10: Introduction Of Other Parts
Introduction of Other Parts 20． Ambient light intensity sensor. For the measurement of the ambient light intensity and to work with the automatic backlight function. 21． Red light LED. 22． Green light LED. 23． LCD screen. 24． Key. 25． Build in magnet. 26．...
Page 11: Key Pressing Operation
Key Pressing Operation Start record mode  When key start recording mode is set, the user can press and hold the key for more than 3 seconds, the instrument will enter the recording mode and start recording temperature. Wait mode Record mode Display content of the instrument ...
Page 12 temperature The max temperature value is outside the measurement range. temperature The min temperature value is outside the measurement range. symbol flashes, it shows the upper temperature limit.
Page 13 symbol flashes, it shows the number of recorded values which are above or equal to the upper temperature limit. symbol flashes, it shows the lower temperature limit. symbol flashes, it shows the number of recorded values which are lower than or equal to the upper temperature limit.
Page 14: Reset Max And Min Values
Showing date, left side is the month, right side is the day. Year Reset Max and Min values  At measurement mode, maximum and minimum values can be reset. When the maximum temperature value is displayed, press and hold the key for more than 3 seconds to reset the maximum value.
Page 15 When the minimum temperature value is displayed, press and hold the key for more than 3 seconds to reset the minimum value. The digital zone will not display the temperature value at this time, and the instrument will recalculate the minimum value from the next measurement and display it again.
Page 16: Instrument Working Mode
Instrument Working Mode INNO 320 has 4 working modes: Wait mode  In wait mode, the instrument has been scheduled to record temperature. It is waiting to enter to record mode and start temperature recording. The symbol is displaying on the screen.
Page 17: End Mode
simultaneously. If the LED alarm function is enabled, the red LED will flash every 10 seconds after alarm was triggered.  Three recording method can be set: Set a number of temperature values to be recorded, when the recording amount was reached，recording will stop, instrument will enter end mode.
Page 18: Other Introduction
Other introduction PC connection Users can use USB Type C cable to connect INNO 320 to the PC. When it was connected, symbol will show on the screen. Users can use innoware (a PC software for INNO 320) to setup the instrument.
Page 19: Smart Phone Connection
Smart phone connection With an OTG adapter, a USB Type C cable, users can connect INNO 320 to an android OS smart phone (android 5.0 or above). symbol will be show on the screen when connecting. Users can use inno APP (an android APP for INNO 320) to setup the instrument.
Page 20: Led Alarm
LCD backlight  INNO 320 display has backlight function.  The backlight can be set to 3 working mode Backlight function always enabled. Whenever the key is pressed, backlight will be on for 10 seconds, so the display contents can be clearly seen in a dark environment.
Page 21: Lcd Screen Performance At Low Temperature
In environment below -30 °C / -22 °F, the LCD may not be able to display content, but the INNO 320 is still working fine. At that situation, the user can press the key and observe the flashing of the LED to understand the status of the instrument.
Page 22: Battery Replacement
Instrument’s status LED flashing pattern Green flash once Wait mode or measurement mode Green flash twice Record mode Green flash 3 times End mode Red flash once Upper or lower limit triggered Red flash twice Battery capacity less than 30 days Limit triggered and battery capacity Red flash 3 times less than 30 days...
Page 23 Remove the old battery from the instrument and wait for about 5 seconds until the residual power in the instrument is completely exhausted and the instrument screen has no displays. Insert a new battery, and install the battery cover as shown above and press it tightly.
Page 24: How To Make The Battery More Durable
The shortest measurement interval for the INNO 320 is 10 seconds. However, for most usage scenarios, a measurement interval of 5 minutes to 15 minutes is sufficient.
Page 25 while providing the longest days for remaining battery capacity. ----- End -----...
