ASROCK IMB-192 Settings Manual

*15G06M053000AK*
P/ N: 15G06M053000AK V1.0
IMB-192
The terms HDMI™ and HDMI High-Definition
Multimedia Interface, and the HDMI logo are
trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other
countries.
1 : Clear CMOS Header
1-2: Normal
2-3: Clear CMOS
2 : 2-pin UPS Module Power Input
Connector
2
Pin1: GND
Pin2: DC Input
3 : M.2 (Key-M)
4 : USB2.0 Header (USB2_1_2)
USB_PWR
P-
P+
GND
DUMMY
1
GND
P+
P-
USB_PWR
5 : USB2.0 Port
6 : 4-Pin Chassis FAN Connector (+12V)
GND
+12V
FAN_SPEED
FAN_SPEED_CONTROL
Jumpers and Headers Setting Guide
1 2
37
DC_JACK1
TO_UPS1
36
USB 3.0
T: USB1
35
B: USB2
1
34 CLRMOS1
33
32
31
LAN1
30
USB 3.0
T: USB3
29
B: USB4
Mic In
28
27 Line Out
1
HD_AUDIO1
SPEAKER1
1
SPDIF1
BUZZ2
1
1
26 25 24
7 : SATA3 Connectors
(SATA3_0, SATA3_1)
8 : Monitor Switch Header
1
9 : SATA Power Output Connector
10 : Backlight Control (BLT_CTL1)
PIN Signal Name
1 CON_LBKLT_EN
2 CON_LBKLT_CTL
3 LCD_BLT_VCC
4 LCD_BLT_VCC
5 GND
6 GND
7 GPIO_BLT_UP
8 GPIO_BLT_DW
11 : System Panel Header
12 : BL1
Open: Protect LCD_BLT_VCC
Short: No Protect LCD_BLT_VCC
BL2
Open: Protect LCD_VCC
Short: No Protect LCD_VCC
13 : Panel Power Select (PNL_PWR1)
1-2: +3V
2-3: +5V
14 : Backlight Power Select (BKT_PWR1)
1-2: +19V
2-3: +12V
3 4 5 6 7
1
USB2_1_2
SATA3_0 SATA3_1
CHA_FAN1
CI1
1
CI2
1
1
1 1
BIOS
Chip
1
PCIE1
IMB-192
23 22 21 20 19
SATA3_0 SATA3_1
1
PWRDN
GND
1
PLED+
PLED-
PWRBTN#
GND
1
GND
RESET#
GND
HDLED-
HDLED+
1
8 9 10 11 12
PANEL1
SATA_POW1
PLED PWRBTN
1
HDLED RESET
1
1
1 1
MONITOR_SWITCH1
BL1 Bl2
BLT_CTL1 1
1 1
Industrial
1
PWR_COM1
1
1 1
USB2_4_5
1
15 : LVDS Panel Connector
PIN Signal Name PIN Signal Name
2
2 LCD_VCC 1 LCD_VCC
4 LDDC_CLK 3 +3.3V
6 LVDS_A_DATA0# 5 LDDC_DATA
8 GND 7 LVDS_A_DATA0
10 LVDS_A_DATA1 9 LVDS_A_DATA1#
12 LVDS_A_DATA2# 11 GND
14 GND 13 LVDS_A_DATA2
16 LVDS_A_DATA3 15 LVDS_A_DATA3#
18 LVDS_A_CLK# 17 GND
40
20 GND 19 LVDS_A_CLK
22 LVDS_B_DATA0 21 LVDS_B_DATA0#
24 LVDS_B_DATA1# 23 GND
26 GND 25 LVDS_B_DATA1
28 LVDS_B_DATA2 27 LVDS_B_DATA2#
30 LVDS_B_DATA3# 29 DPLVDD_EN
32 GND 31 LVDS_B_DATA3
34 LVDS_B_CLK 33 LVDS_B_CLK#
36 CON_LBKLT_EN 35 GND
38 LCD_BLT_VCC 37 CON_LBKLT_CTL
40 LCD_BLT_VCC 39 LCD_BLT_VCC
16 : COM Port Pin9 PWR Setting Jumpers
PWR_COM1 (For COM Port1)
1-2: +5V
2-3: +12V
PWR_COM2 (For COM Port2)
1-2: +5V
2-3: +12V
17 : COM Port Headers (COM1, COM2)
(RS232)
PIN Signal Name PIN Signal Name
9 +5V 10 NC
7 RRTS# 8 CCTS#
5 GND 6 DDSR#
3 TTXD 4 DDTR#
1 DDCD# 2 RRXD
18 : USB2.0 Header
(USB2_4_5)
13
14
15
16
17
18
1
39
1 2
