PS1
+
4.35V - 5.5V supply
1A
-
Note: All connections from equipment should be Kelvin connected directly to the board
pins which they are connected on this diagram and any input or output leads should be
twisted pair.
2
Arrow.com.
Arrow.com.
Downloaded from
Downloaded from
AM1
-
+
+
VM1
-
Figure 1. Proper Measurement Equipment Setup for DC1584A
Figure 2. Measuring Input or Output Ripple
LTC4070EDDB
-
+
AM2
+
3.6Ω
+
PS2
VM2
0V - 5V supply
-
-
1A
