- Page 1 ZR10-D Controller Installation and Operating Instructions 10/2013...
- Page 2 Observe all safety regulations in this documentation. TRADEMARKS inVENTer® is a registered trademark of ÖkoHaustechnik inVENTer GmbH. Other names used in this documentation may be trademarks whose use by third parties may infringe upon the rights of the owner. EXEMPTION FROM LIABILITY The content of this documentation has been reviewed for compliance with the hardware and software described.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Description of ZR10-D controller......5 Overview .........................5 Modes ........................7 Synchronization of multiple controllers ..............7... - Page 4 All legal notices in the installation and operating instructions are also applicable for this document without restriction. This pertains to the warning signs convention, qualified personnel, intended use, trademarks and exemption from liability. ZR10-D Controller • Installation and Operating Instructions 10/2013...
-
Page 5: Description Of Zr10-D Controller
• 4 iV14 ventilation systems or • 2 iV25 ventilation systems or • 2 iV-Twin ventilation systems It features easy installation and straightforward operation. The ZR10-D controller allows the control of the iV14 ventilation system in two modes: • Heat recovery (HR) •... - Page 6 • ZR10-D-Standard • ZR10-D-Flat The ZR10-D-Standard and ZR10-D-Flat differ in the airflows in power stage 0. Use of the ZR10-D-Flat is rec- ommended in rooms having the requirement that the ventilation system must remain ON to maintain ventilation for moisture protection.
-
Page 7: Modes
This mode is recommended for cooling rooms during summer nights. 1.3 Synchronization of multiple controllers The ZR10-D controller allows multiple controllers to be synchronized to each other. It automatically rates the line frequency via the upstream transformer and generates from it the interval switching of the fans. The follow- ing requirements must be met for this: •... -
Page 8: Interfaces
INTERFACES / INSTALLATION 3. INTERFACES The figure shows the layout of the interfaces on the ZR10-D controller board. 2-pin transformer connector Jumper * 3-pin fan connector *) For service settings only Figure 3: ZR10-D board interfaces 4. INSTALLATION Danger - Before starting any work on electrical systems, disconnect all relevant equipment from the power supply. - Page 9 If ribbon cable is used, connect two leads in one conductor sleeve. Connect the transformer connecting lead (5) to the terminal block (4) Dimensional drawing Figure 6: Dimensional drawing for junction box ZR10-D Controller • Installation and Operating Instructions 10/2013...
-
Page 10: Surface Mount And And Control Cabinet
INSTALLATION 4.2 Surface mount and control cabinet The ZR10-D controller is intended for installation into a surface mount junction box and for installation in a control cabinet. SURFACE MOUNT ACE MOUNT CONTROL CABINET CONTROL CABINET Figure 7: Front view Wiring... - Page 11 Pre-stamped holes for the cable feedthroughs are on the base plate and also on the sides of the control cabinet junction box. This makes it possible to tailor the wiring to your own practical requirements. ZR10-D Controller • Installation and Operating Instructions 10/2013...
-
Page 12: Electrical Connection
Fan 1 ... 4 Fan 1 ... 4 Fan 1 ... 4 Fan 1 ... 4 Controller Controller Controller Controller Controller Other controllers connectable. Other contr Figure 9: ZR10-D controller connection example ZR10-D Controller • Installation and Operating Instructions 10/2013... -
Page 13: Junction Box
Controller connecting lead Figure 12: Board connection Attach the fan connector (2) to the socket contact on the controller board. Attach the transformer connector (3) to the socket contact on the controller board. ZR10-D Controller • Installation and Operating Instructions 10/2013... -
Page 14: Surface Mount And Control Cabinet
4. Push the dividing plate aside. Ensure that the controller connecting lead (1) is positioned accurately in the hole. This will mean the cable is not squashed. *) Always ensure that the short fixing screws are fitted on the right-hand side ZR10-D Controller • Installation and Operating Instructions 10/2013... - Page 15 Connect the fan connecting lead plug (1) to the 3-pin interface of the controller board (3) and the con- troller connecting lead plug (2) to the 2-pin interface. ZR10-D Controller • Installation and Operating Instructions 10/2013...
-
Page 16: Startup
6.1 Junction box Caution - Make sure that all renovation work inside the building has been completed. This ensures that the ZR10-D controller does not come into contact with wall paint, wallpaper glue and plaster, so that its functionality is maintained. -
Page 17: Surface Mount And Control Cabinet
ACE MOUNT CONTROL CABINET CONTROL CABINET Fixing screw (x 2) Figure 18: Fitting the ZR10-D controller Fold the controller board upwards Use the two fixing screws (1) to attach the controller board ZR10-D Controller • Installation and Operating Instructions 10/2013... - Page 18 Figure 20: Fitting the control cover Put the cover (1) on Make sure that the hole for the fixing screw is at the bottom. Use the screw (2) to attach the cover. ZR10-D Controller • Installation and Operating Instructions 10/2013...
-
Page 19: Operation
*) The ZR10-D-Flat controller does not switch off but operates in HR or V mode **) The luminosity of the LED increases or decreases depending on the power stage set On the ZR10-D-Flat controller, the LED of the mode set last remains active Figure 22: Operation of the ZR10-D-Standard Turn the marker line on the knob to the power stage indicator you wish to set. -
Page 20: Technical Details
0 ... 60°C Thermostatic switch 100°C 100°C 9. DELIVERABLES AND ACCESSORIES Deliverables • ZR10-D controller (controller with transformer) • Control unit • Junction box appropriate for the installation (wall, surface mount or control cabinet) ZR10-D Controller • Installation and Operating Instructions 10/2013... -
Page 21: Maintenance And Repair
Controller board Controller board Plastic / copper Plastic / copper Plastic / copper Plastic / copper Housing parts Housing parts Plastic Plastic Plastic Plastic Plastic Plastic Recycling Recycling Recycling Recycling Recycling Recycling ZR10-D Controller • Installation and Operating Instructions 10/2013... -
Page 22: Warranty And Service
ZR10-D controller are made, • spare parts that are not original spare parts from the manufacturer of the ZR10-D controller are used, • damage is caused by the impact of force majeure or environmental factors, or •... -
Page 23: Legal Notice
District court Jena, company reg. no. 208892 Images: © Öko-Haustechnik inVENTer GmbH 2013 Rights to all content: © Öko-Haustechnik inVENTer GmbH 2013 Subject to changes. All information provided "as is". No liability assumed for printing errors. ZR10-D Controller • Installation and Operating Instructions 10/2013... - Page 24 Öko-Haustechnik inVENTer GmbH Ortsstraße 4a 07751 Löberschütz, Germany Phone: +49 (0)36427 / 2192-0 Fax: +49 (0)36427 / 2192-13 Email: info@inventer.de Subject to change © Öko-Haustechnik inVENTer GmbH 2013 www.inventer.de...
