Connector Summary

Designator Connector
P1 NVIDIA
TX2/TX2i/TX1
P2 External Battery
P3 HDMI Port
P4 NVIDIA
TX2/TX2i/TX1 Gigabit
Ethernet
P5 POE Gigabit Ethernet
Ports 0-1
P6 POE Gigabit Ethernet
Ports 2-3
P7 GPIO/Serial Port
P8 Serial Port
P9 mSATA Slot
P10 Mini-PCIe Slot
P11 SIM Card Slot
P12 microSD Slot
P13 USB 2.0 OTG
P14 USB 2.0 Type A
P15 USB 3.0 Type A
P16 CAN Bus
P17 Power
P18 PWM Fan
DIP Switch Summary & Locations
Designator Function
S2 Force Recovery
Button
S3 Reset Button
S4 Power Button
DIP Switch Summary & Locations
Designator Function
SW1A Power Override
SW1B Auto Start Operation
SW2A NVIDIA
TX2/TX2i/TX1
Module Selection
SW2B USB OTG Mux
Control
Document: CTIM-00484
Revision: 0.06
Description
Jetson™ NVIDIA Jetson™ TX2/TX2i/TX1 Module Connector
®
External Battery Header
HDMI Right Angle Vertical Connector
Jetson™
®
RJ45 Gigabit Ethernet Connector (10/100/1000)
RJ45 Gigabit Ethernet Connectors (10/100/1000)
RJ45 Gigabit Ethernet Connectors (10/100/1000)
GPIO/RS-232 Samtec 2x6 Right Angle Header
RS-232 Samtec 2x5 Vertical Header
mSATA Full Sized Slot
Mini-PCIe Full Sized Slot
Mini-PCIe SIM Card Slot
MicroSD Card Slot
USB 2.0 Link 0 OTG Micro-AB Connector (USB Link shared
with P14)
USB 2.0 Link 0 Type A Connector (USB Link shared with
P13)
USB 3.0 Link 1 Type A Connector
CAN Bus Header
Input Power TE Connector
Jetson Module Fan Connector for Active Cooling Solution
Description
Cogswell System Force Recovery Button (Used for NVIDIA
Jetson™ TX2/TX2i/TX1 System Reprogramming with USB
OTG Port)
Cogswell System Reset Push Button
Cogswell System Power ON/OFF Button
Description
Cogswell System Power Override Operation
Cogswell System Auto Start Operation
Jetson™ NVIDIA Jetson™ TX2/TX2i/TX1 USB 3.0 MUX Selection
®
USB OTG Override Operation Switch
