Consumables - Tally Dascom DL-820 User Manual

Tally Dascom DL-820
Power
Input
Supply
Output
SDRAM
Memory
FLASH
Standard
Interface
Optional
Software
Dimensions
Casing Color
Weight
Physical
Operating
Spec.
condition
Storage
condition
Certification
Optional kit
Reliability TPH lifetime

1.3 Consumables

Important: Use genuine media to ensure the best print quality. The special
designed paper, polyethylene and polyester media improve the performance
and the print head life.
This printer supports three classes of print media:
Adhesive Labels - individual label or continuous roll, with adhesive material on its back, laying
Receipt - generally thermal sensitive paper in a roll.
Ticket & Tag - generally made of thick paper (max. 0.25 mm); with perforation between label.
The print media can be in a roll or fanfold.
Thermal sensitive media (direct thermal) must be used without ribbon.
Choose correct type of media for your application.
External power adapter
AC 100V-240V, 50-60Hz
DC 24V；1.5A
32MB
8 MB
USB (2.0 Full-Speed)
Ethernet: 10M/100M
Parallel Centronics (IEEE-1284)
Driver (Windows 32bit/64bit), Bartender, SDK system
240(W)×440(D)×255(H)mm
Black
9.8kg
0~45℃ 20%~95%RH (non-condensing)
-20~60℃/≤95%RH (non-condensing)
CE, FCC
Cutter, Peeler
150km
(Condition: use specific thermal roll paper and the print rate is 12%)
over a backing tape (liner).
3
User Guide V1.0
