MANUEL D'INSTRUCTIONS ET D'ASSEMBLAGE

CARACTÉRISTIQUES

Puissant moteur 1 CV, lubrifié à vie

pour un roulement silencieux et de

longue durée.

Interrupteur de sureté avec clé. L'unité

ne peut démarrer lorsque la clé n'est

pas insérée dans l'interrupteur.

Ventilateur à ailette balancé avec

précision pour un fonctionnement en

douceur et un minimum de bruit.

Sac de récupération réutilisable en

plastique transparent améliorant l'effi-

cacité de la récupération de pous-

sière.

Châssis du capteur monté sur 3 tiges

de support ultra-robustes.

Ceinture de métal avec attache à

ressort.

Muni de cartouches de filtration à

rendement élevé de un micron.

Larges roues de 7" en caoutchouc

permettant une meilleure stabilité et

un déplacement tout en douceur.

SPÉCIFICATIONS

DIAMÈTRE DE L'ENTRÉE

4" (102 mm)

CAPACITÉ D'ASPIRATION

506 Pi

/MIN.

NIVEAU SONORE

80-85 dB

PRESSION STATIQUE

6 3/4" d'eau

DIAMÈTRE DU VENTILATEUR

10" (254 mm)

DIMENSIONS DE LA CARTOUCHE

14 1/2" x 11 3/4" (370 x 300 mm)

SURFACE DE FILTRATION

20.33 Pi

DIMENSIONS DE LA MACHINE

31 1/8" x 18 7/8" x 47 5/8"

(790 x 480 x 1210 mm)

MOTEUR

1 CV, 110 V, 7 A

POIDS

67 LBS (31 Kg)

CAPTEUR DE POUSSIÈRE 1 CV

MODÈLE

# 10-030 M1

VERSION 1 - FÉVRIER 2012

Table of Contents

Need help?

Do you have a question about the 10-030 M1 and is the answer not in the manual?

Questions and answers

Summary of Contents for General 10-030 M1

Page 2: Specifications
20.33 Sq.Ft. OVERALL DIMENSIONS 31 1/8” x 18 7/8” x 47 5/8” (790 x 480 x 1210 mm) MOTOR 1 HP , 110 V, 7 A WEIGHT VERSION 1 - FEBRUARY 2012 67 LBS (31 Kg) © Copyright General® International 2012...
Page 3 Because of our commit- ment to quality and customer satisfaction, General® International agrees to repair or replace, within a period of 24 months from date of purchase, any genuine part or parts which, upon examination, prove to be defective in work- manship or material.
Page 4 étapes de la production et chaque machine est rigoureusement inspectée une fois l’assemblage terminé. En rai- son de son engagement envers la qualité et la satisfaction du consommateur, General® International accepte de réparer ou de remplacer toute pièce qui, suite à l’examen, se révèle défectueuse quant au matériel et au fini d’exé- cution pour une période de 24 mois suivant la date d’achat.
Page 6: Rules For Safe Operation
To help ensure safe operation, please take a moment to learn the machine’s applications and limita- tions, as well as potential hazards. General® International disclaims any real or implied warranty and holds itself harmless for any injury that may result from improper use of its equipment.
Page 7: Unpacking And Checking Contents
1 HP DUST COLLECTOR 10-060 UNPACKING AND CHECKING CONTENTS UNPACK AND REMOVE ALL COMPONENTS OF YOUR MACHINE FROM THE BOX AND COMPARE WITH THE PARTS LISTED BELOW. REPORT DAMAGED OR MISSING ITEMS TO YOUR DEALER/DISTRIBUTOR IMMEDIATELY: MINI DUST COLLECTOR PIPE CONNECTOR (12) MOUNTING BRACKETS (2) FLEXIBLE HOSE 90 cm COLLECTION BAG (3)
Page 10: Assembly And Installation
Note: As a general guideline, the maximum suggested distance from a dust source to the unit is 30 ft when using 2-1/2” hose. Maximum distances may drop considerably when using 4” hose. Since each shop situation is different, your results may vary.
Page 11 SELECTING A SITE FOR THE DUST COLLECTOR AND LAYING OUT A PLAN FOR THE PIPING Note: Plan, measure and mark before you drill! Having a mapped out rough layout of your planned installation, starting from the dust collector unit at the far left and working out to your furthest point on the right, may help simplify the installation and avoid surprises.
Page 14: Mounting
ASSEMBLY 1/4” 5 9/16” 6 7/8” STEP 1 Install the wall anchors for the dust collector. Wall anchors should be installed in the wall at the selected location for the unit. Using the dimensions shown below as a reference, mark the location of the wall anchors on the wall.
Page 15 STEP 3 STEP 4 Align the four holes in the dust intake port with the Mount the dust collector to the wall as shown. Ensure that mounting holes and using the four pan-head screws, the exposed heads of the four screws fit into the narrow attach the dust intake port to the unit as shown.
Page 18 STEP 9 STEP 10 Secure the piping to the wall as per your layout plan Use the pipe connectors, T-fittings and blast gates at using the supplied wall hangers. Screw the hangers into each dust connection hook up point in your layout. the wall anchors to secure the piping to the wall.
Page 19: Power Off
OPERATIONS CONNECTING TO A POWER SOURCE Plug the dust collector into a proper receptacle. Your power tools should be con- nected to a dedicated electrical circuit of not less than #14 wire and should be protected with a 15 amp time lag fuse. If an extension cord is needed, use only 3-wire cords with 3-prong grounded-type plugs and 3-pole receptacles.
Page 22: Maintenance
30’ of 2-1/2” dust safety when using your dust collector. Here’s hose, hose clamps and a 4” to 2-1/2” adapter. a small sampling of accessories available from your local General International dealer. 4” X 2 1/2” Reducer Electronic earmuffs #10-086 #99-200...
Page 26: Parts List
PARTS LIST 10-060 PART N0. DESCRIPTION SPECIFICATION 10060-01 TOP COVER 10060-02 SWITCH 10060-03 MOTOR 10060-04 POWER CORD 10060-05 PLUG 10060-06 MOTOR GASKET 10060-07 MOTOR COVER 10060-08 HEX HEAD SCREW 5/16" x 3/4" 10060-09 LOCK WASHER 5/16" 10060-10 10060-11 FLAT WASHER 5/16"...
Page 27 Fax : (514) 326-5565 Parts & Service Fax : (514) 326-5555 Order Desk orderdesk@general.ca www.general.ca IMPORTANT: When ordering replacement parts, always give the model number, serial number of the machine and part number. Also a brief description of each item and quantity...
