SETUP & OPERATION MANUAL
FEATURES
All single phase models are equipped with
totally enclosed, fan cooled, permanently
lubricated motors.
Heavy-duty motor design with a continu-
ous duty rating for industrial applications.
Heavy-duty base,mounted on four swivel
casters for total mobility and stability.
Precision spin-balanced aluminum impel-
ler for smooth operation,minimal noise
and to reduce the risk of sparking.
All models are equipped with 2 micron
filter bags. (Not included on "CF"canister
filter model)
Quick-release bag clamps with metal
straps on all models.
Safety switch with key, prevents unit from
being started when key is removed.
Heavy-duty collection bags made from
extra thick, transparent, recyclable plastic.
SPECIFICATIONS
INLET DIAMETERS
(1) 6" (152 mm)
(2) 4" (102 mm)
AIRFLOW CAPACITY
1550 CFM
BLOWER WHEEL DIAMETER
12 3/4'' (324 mm)
SOUND RATING
80 TO 90 dB
BAG DIAMETER
20'' (508 mm)
BAG CAPACITY
42 GAL (190.9 L.)
STATIC PRESSURE
11 1/4" OF WATER
MOTOR
M1: 2 HP, 220 V, 1 Ph, 9 A
M3: 2 HP, 600 V, 3 Ph, 2.6 A
OVERALL DIMENSIONS (L x W x H)
39 3/8" x 31 1/2" x 74 3/4"
(1000 x 800 x 2000 mm) -
#10-110
39 3/8" x 31 1/2" x 66 3/4"
(1000 x 800 x 1746 mm) -
#10-110CF
WEIGHT
132 LBS (60 kg)
-
#10-110
141 LBS (64 kg)
-
#10-110CF
2 HP DUST COLLECTOR
MODEL
#10-110
#10-110CF
VERSION 2_REVISION 1 - January 2015
© COPYRIGHT GENERAL INTERNATIONAL
Advertisement
Table of Contents
Related Manuals for General 10-110
Summary of Contents for General 10-110
-
Page 1: Specifications
(1000 x 800 x 2000 mm) - #10-110 39 3/8” x 31 1/2” x 66 3/4” (1000 x 800 x 1746 mm) - #10-110CF WEIGHT 132 LBS (60 kg) #10-110 141 LBS (64 kg) VERSION 2_REVISION 1 - January 2015 #10-110CF © COPYRIGHT GENERAL INTERNATIONAL... - Page 2 Because of our commit- ment to quality and customer satisfaction, General® International agrees to repair or replace, within a period of 24 months from date of purchase, any genuine part or parts which, upon examination, prove to be defective in workmanship or material.
- Page 3 2 years (24 months) from the date of purchase. General® International agrees to repair or replace any part or component which upon examination, proves to be defective in either workmanship or mate- rial to the original purchaser during this 2-year warranty period, subject to the “conditions and...
-
Page 4: Rules For Safe Operation
To help ensure safe operation, please take a moment to learn the machine’s applications and limita- tions, as well as potential hazards. General® International disclaims any real or implied warranty and holds itself harmless for any injury that may result from improper use of its equipment. -
Page 5: Electrical Requirements
ELECTRICAL REQUIREMENTS BEFORE CONNECTING THE MACHINE TO THE POWER SOURCE, VERIFY THAT THE VOLTAGE OF YOUR POWER SUPPLY CORRE- SPONDS WITH THE VOLTAGE SPECIFIED ON THE MOTOR I.D. NAMEPLATE. A POWER SOURCE WITH GREATER VOLTAGE THAN NEEDED CAN RESULT IN SERIOUS INJURY TO THE USER AS WELL AS DAMAGE TO THE MACHINE. IF IN DOUBT, CONTACT A QUALIFIED ELECTRICIAN BEFORE CONNECTING TO THE POWER SOURCE. -
Page 6: Identification Of Main Parts And Components
2 HP DUST COLLECTOR 10-110 or 10-110CF IDENTIFICATION OF MAIN PARTS AND COMPONENTS CONNECTOR FILTER BAG (10-110 ONLY) DRUM CANISTER FILTER (10-110CF ONLY) COLLECTOR BODY W/MOTOR ASS’Y COLLECTOR BAG BASE PLATE BELT CLAMP (2X ) HOSE INLET (“Y” FITTING) CASTER (4X) - Page 7 Carefully unpack and remove the unit and its components from its shipping container and check for missing or damaged items as per the list of contents below. Note: Please report any damaged or missing items to your GENERAL® INTERNATIONAL distributor immediately. LIST OF CONTENTS LIST OF CONTENTS A- DRUM ................
-
Page 8: Shop Placement / Space Considerations
SHOP PLACEMENT / SPACE CONSIDERATIONS 66 3/4” 73 3/4” Because each shop situation is unique, the following fac- Consider the space requirements for the unit and its use when tors should be taken into consideration when determining deciding where to install your dust collector in your shop. and before deciding on the ideal installation to best suit your shop dust collection needs. -
Page 9: Assembly Instructions
ASSEMBLY INSTRUCTIONS SERIOUS PERSONAL INJURY COULD OCCUR IF YOU CONNECT THE MACHINE TO THE POWER SOURCE BEFORE YOU HAVE COMPLETED THE INSTALLATION AND ASSEMBLY STEPS. DO NOT CONNECT THE MACHINE TO THE POWER SOURCE UNTIL INSTRUCTED TO DO SO. STEP 2 - ATTACH COLLECTOR BODY W/ MOTOR ASSEMBLY STEP 1 - INSTALL THE CASTERS Turn the base plate upside down and using the sup- Turn the base plate back over (right side up) and place... - Page 10 (IF NEEDED) (#10-110CF ONLY) Basic assembly is now complete and your dust col- If you have model 10-110 with filter bag skip ahead to step #10. lector is ready to be put into service. Once the unit is hooked up to an appropriate electrical connection,...
-
Page 11: Maintenance And Servicing
HEARING PROTECTION IS USED AND THAT THE OVERALL SOUND LEVEL WITHIN THE WORKING ENVIRONMENT IS TAKEN INTO CONSIDERATION. BASIC INSTRUCTIONS The MODEL 10-110 & 10-110CF Dust Collector has been designed to capture, remove, and collect non- metallic dust and wood dust around the workshop and from woodworking machinery. ON/OFF SWITCH The model 10-110 &... - Page 12 CLEANING OR REPLACING THE FILTER BAGS (10-110 only) TURN THE SWITCH TO THE “OFF” POSITION AND UNPLUG THE UNIT FROM THE POWER SOURCE BEFORE CLEANING OR REPLACING FILTER BAGS OR BEFORE PERFORMING ANY MAINTENANCE. Tip/Hint: To avoid potentially costly down-time, consider keeping a spare filter bag on-hand and nearby for use if needed.
-
Page 13: Recommended Optional Accessories
RECOMMENDED OPTIONAL ACCESSORIES We offer a large variety of products for increased convenience, productivity, accuracy and safety when using your dust collector. Here’s a small sampling of optional accessories available from your local General International dealer. For more information about our products, please visit our website at www.general.ca 4”... - Page 15 1/4” *Not supplied/required for Model #10-110CF **Filter bag #10-115 for model 10-110 or Canister filter #10-106C for model 10-110CF. IMPORTANT: When ordering replacement parts, always give the model number, serial number of the machine and part number. Also a brief description of each item and quantity desired.
- Page 16 Canister supplied on Model 10-110CF PARTS LIST 10-106C PART # DESCRIPTION SPEC. PART # DESCRIPTION SPEC. 10106C-25 CANISTER FILTER DIA.500MM 10106C-38 ROUND HEAD SCREW M5X6 10106C-26 5/16” 10106C-39 FIXING PLATE 10106C-40 BOTTOM FIXING PLATE 10106C-27 SET SCREW 5/16”X3/4” 10106C-41 PHILLIPS HEAD SCREW M5X15 10106C-28 HANDLE...
- Page 17 Notes...
- Page 18 MODEL 10-110 & 10-110CF 8360 Champ-d’Eau, Montreal (Quebec) Canada H1P 1Y3 Tel.: (514) 326-1161 Fax: (514) 326-5565 - Fax: (514) 326-5555 - Parts & Service / Order Desk orderdesk@general.ca www.general.ca Follow us:...
