SETUP & OPERATION MANUAL
FEATURES
Safety switch with key. Unit cannot be
started when key is removed from the
switch.
Precision spin-balanced impeller for
smooth operation and minimal noise.
Reusable clear plastic collector bag
for improved dust collection efficiency.
Collector body mounted on 3 heavy-
duty supports.
Quick-release bag clamps with metal
straps.
Equipped with high efficiency 1 micron
canister filter.
Large 7" rubber wheels for exceptional
stability and smooth mobility.
SPECIFICATIONS
INLET DIAMETER
4" (102 mm)
AIRFLOW CAPACITY
506 CFM
SOUND RATING
80 to 85 dB
STATIC PRESSURE
6 3/4" OF WATER
BLOWER WHEEL DIAMETER
10" (254 mm)
CANISTER FILTER SIZE
14 1/2" x 11 3/4" (370 x 300 mm)
FILTER AREA
20.33 sq.ft.
OVERALL DIMENSIONS (L X W X H)
31 1/8" x 18 7/8" x 47 5/8"
(790 x 480 x 1210 mm)
MOTOR
1 HP , 110 V, 7 A
WEIGHT
67 LBS (31 Kg)
1 HP DUST COLLECTOR
MODEL
# 10-030CF M1
Rev. 1 January 29/2019
VERSION 1 -
© Copyright General® International 11/2012
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for General 10-030CF M1
Summary of Contents for General 10-030CF M1
- Page 1 OVERALL DIMENSIONS (L X W X H) 31 1/8” x 18 7/8” x 47 5/8” (790 x 480 x 1210 mm) MOTOR 1 HP , 110 V, 7 A WEIGHT Rev. 1 January 29/2019 VERSION 1 - 67 LBS (31 Kg) © Copyright General® International 11/2012...
- Page 2 GENERAL® INTERNATIONAL 8360 Champ-d’Eau, Montreal (Quebec) Canada H1P 1Y3 Telephone (514) 326-1161 • Fax (514) 326-5555 • www.general.ca THANK YOU for choosing this General ® International 10-030CF M1 - 1 HP Dust Collector. This dust collector has been carefully tested and inspected before shipment and if properly used and maintained, will provide you with years of reliable service.
- Page 3 2 years (24 months) from the date of purchase. General® International agrees to repair or replace any part or compo- nent which upon examination, proves to be defective in either workmanship or material to the original purchaser during this 2-year warranty period, subject to the “conditions and excep-...
-
Page 4: Table Of Contents
TABLE OF CONTENTS Rules for safe operation ..........Electrical requirements . -
Page 5: Rules For Safe Operation
To help ensure safe operation, please take a moment to learn the machine’s applications and limitations, as well as poten- tial hazards. General® International disclaims any real or implied warranty and holds itself harmless for any injury that may result from improper use of its equipment. -
Page 6: Electrical Requirements
ELECTRICAL REQUIREMENTS BEFORE CONNECTING THE MACHINE TO THE POWER SOURCE, VERIFY THAT THE VOLTAGE OF YOUR POWER SUPPLY CORRE- SPONDS WITH THE VOLTAGE SPECIFIED ON THE MOTOR I.D. NAMEPLATE. A POWER SOURCE WITH GREATER VOLTAGE THAN NEEDED CAN RESULT IN SERIOUS INJURY TO THE USER AS WELL AS DAMAGE TO THE MACHINE. IF IN DOUBT, CONTACT A QUAL- IFIED ELECTRICIAN BEFORE CONNECTING TO THE POWER SOURCE. -
Page 7: Identification Of Main Parts
1 HP DUST COLLECTOR MODEL #10-030CF M1 IDENTIFICATION OF MAIN PARTS AND COMPONENTS A. CANISTER CLEANING HANDLE B. CANISTER FILTER C. MOTOR D. HANDLE E. ON/OFF SAFETY SWITCH F. IMPELLER/SEPARATOR ASSEMBLY G. COLLECTION BAG H. VERTICAL SUPPORT RODS WHEELS J. BASE... -
Page 8: Unpacking
Carefully unpack and remove the components from the box and check for damaged or missing items as per the list of contents below. NOTE: Please report any damaged or missing items to your General International distributor immediately. LIST OF CONTENTS M- CASTERS . -
Page 9: Laying Out A Plan For The Piping
LAYING OUT A PLAN FOR THE PIPING For permanent installations, it is advisable to map out a rough layout of your planned installation starting from the dust collector out to all the machines that you wish to connect to the system. You may vary your layout to suit your specific shop needs and may choose to use metal or plastic ducting, or flexible hose in any combination as suited to your needs. - Page 10 3. Attach the 2 vertical support rods F to the base 4. Attach the 3rd support rod I as shown in J, using 2 hex flange head bolts. using (4) hex flange head bolts G, as shown in H. NOTE: The 3rd rod has an angled end to sit over the lip of NOTE: The front and rear support rods are identical.
-
Page 11: Operating Instructions
HEARING PROTECTION IS USED AND THAT THE OVERALL SOUND LEVEL WITHIN THE WORKING ENVIRONMENT IS TAKEN INTO CONSIDERATION. BASIC INSTRUCTIONS This Model 10-030CF M1 Dust Collector has been designed to capture, remove, and collect non-metallic dust and wood dust around the workshop and from woodworking machinery. ON/OFF SWITCH The model 10-030CF M1 is equipped with a simple “rocker... -
Page 12: Maintenance & Servicing
Use only recommended parts and accessories. The use of parts or accessories NOT recommended by GENERAL® INTERNATIONAL may result in a risk of injury or damage to the machine. TURN THE SWITCH TO THE "OFF" POSITION AND UNPLUG THE UNIT FROM THE POWER SOURCE BEFORE CLEANING OR REPLACING CANISTER FILTER OR BEFORE PERFORMING ANY MAINTENANCE. -
Page 13: Recommended Optional Accessories
Dimensions (dia. x h): 14 1/2” x 11 3/4” (370 x 300 mm) For more information about our products, please visit our website at www.general.ca 4” X 10’ Hose for Accessory Kit for Dust Collector - 1 Machine Hook-Up #10-100... - Page 15 PARTS LIST 10-030CF M1 PART N0. DESCRIPTION SPECIFICATIONS 10030-01 BASE 10030-02 HEX HEAD BOLT 1/2" X 4" 10030-03 WASHER 1/2" X19 10030-04 WHEEL 7" 10030-05 LOCK NUT 1/2" 10030-06 VERTICAL SUPPORT ROD (F & R) 10030-07 HEX HEAD BOLT 5/16" X 1/2"...
- Page 16 MODEL 10-030CF M1 8360 Champ-d’Eau, Montreal (Quebec) Canada H1P 1Y3 Tel.: (514) 326-1161 Fax: (514) 326-5565 - Fax: (514) 326-5555 - Parts & Service / Order Desk orderdesk@general.ca www.general.ca IMPORTANT When ordering replacement parts, always give the model number, serial number of the machine and...
