Hdmi Transmitter - Paralinx Tomahawk User Manual

8

HDMI TRANSMITTER

TRANSMITTER
TRANSMITTER
SLIDE SWITCH
SETTINGS
1 Dual RP-SMA
Type Antenna Connectors
2 Connection status LED
Indicates the wireless network status.
3 VIDEO status LED
indicates the video connection status.
4 Low battery LED
Indicates the battery voltage status.
5 Link button
For linking the transmitter to
additional receivers
6 Reset button
SINGLE-LINK MODE
S1 S2
PARALINX TOMAHAWK
7 USB Port
The USB port can be used for firmware
updates.
8 S1 Slide Switch
Left position: Single-link mode
Right position: Multicast mode
9 S2
Not used
10 HDMI Input port
11 7-17v LEMO power input connector
Pin 1 Hot, Pin 2 Ground
MULTI-LCAST MODE
S1 S2
