Receiver - Paralinx Tomahawk User Manual

14

RECEIVER

RECEIVER
RECEIVER
DIP SWITCH
SETTINGS
10 5x RP-SMA
Antenna Connectors
11 Power LED
12 Network LED
13 Video LED
14 Diagnostic LED
15 Receiver DIP Switches
DIP switch # 1, 2, & 3 should be UP
DIP switch # 4 UP = Single-link mode
DOWN = Multi-link mode
SINGLE-LINK MODE
1 2 3 4
PARALINX TOMAHAWK
16 Link Button
17 Input Voltage connector 7-17v
18 ON/OFF Switch
19 IR input connector
20 HD-SDI output
21 HD-SDI output
22 Reset Button
23 Mini-USB for firmware updates
MULTICAST MODE
1 2 3 4
