Maintenance instructions Aliva-257 Top
2.4.2
If the rubber seals for the Rotor discs are insufficiently or over-lubricated, then
change the lubrication time for the lube pump.
NOTE
To increase intensity of lubrication, you can extend the lubrication time
accordingly.
Remove the blue frame to the left of the lube pump.
Remove the four screws from the view window and then remove the view
window itself.
The two small locking screws are exposed.
Fig. 2.4
Lubrication and
cycle time
2
32
Leave the cycle time set to one minute.
Using a small screwdriver, turn the lubrication time one notch (± 2 sec.), either
to the left (= 6 sec.) or to the right (= 10 sec.).
Attach the view window and screw the screws tight.
Place on the frame.
The lubrication time is now set and you can continue to work.
NOTE
if you find out later that the lubrication time is incorrect, re-adjust it as described
above.

Adjust lubrication time

EA / PA Controller PICO S-EP 4
Schmierzeit (sec.)
Zykluszeit (min.)
1
16
Version 1.0
2 Maintenance and repair work
Factory setting:
Cycle time = 1 minute (Do not adjust!)
Lubrication time = 8 seconds
257 037
