2 Maintenance and repair work
2.15

Check and replace gear oil

2.15.1 Check oil level

Fig. 2.35
Check oil level
1 Oil view glass
1

2.15.2 Replace the gear oil

While you are replacing the gear oil,
Place a catchment tank under the machine.
Fig. 2.36
Replace the gear oil
1 Oil drain screw
2 Filler plug
1
NOTE
For oil disposal, see"4.3 Disposal" on page 52.
40
2
Version 1.0
Maintenance instructions Aliva-257 Top
Check the oil level at the oil view
glass 1. The view window must be
filled up to a minimum of 10 mm or to
the red marker.
257.065
Lift off the cover.
Unscrew the oil drain screw 1.
The used oil flows off.
Check the seal and replace it if
damaged.
Screw the screw back in and tighten it.
Unscrew the oil filler plug 2. Fill with oil
and screw the filler plug back on.
The gear oil has now been replaced.
Check the oil level at the oil view
257.066
window.
