www.hirschmann.com
PRS 80 Wind Speed
OPERATOR'S / SERVICE MANUAL
P/N 031-300-190-184 REV. C 05/23/06

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRS 80 Wind Speed and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hirschmann PRS 80 Wind Speed

  • Page 1 PRS 80 Wind Speed OPERATOR’S / SERVICE MANUAL P/N 031-300-190-184 REV. C 05/23/06...
  • Page 3 PRS 80 Wind Speed Operator’s/Service Manual NOTICE Hirschmann ECS makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and/or its fitness for a particular purpose. Hirschmann ECS will not be liable for errors contained in this manual or for incidental or consequential damages in connection with the furnishing, performance, or use of this manual.
  • Page 4 PRS 80 Wind Speed Operator’s/Service Manual © Hirschmann ECS, 2006; PRS 80 Wind Speed Rev.C 05/23/06 190184_C...
  • Page 5: Table Of Contents

    7.3 N ..........................13 ISPLAY 7.4 T ....................13 ROUBLESHOOTING OISTURE 7.5 T ......................14 ROUBLESHOOTING HART MAINTENANCE ..........................15 8.1 B ......................15 ATTERY EPLACEMENT PART NUMBERS.......................... 16 © Hirschmann ECS, 2006; PRS 80 Wind Speed Rev.C 05/23/06 190184_C...
  • Page 7: General Information

    General Information GENERAL INFORMATION The Hirschmann ECS PRS 80 System has been designed to provide indication from a various types of radio sensors. To simplify operation, this PRS 80 console set up for wind speed only, but can be software upgraded to indication other various types of radio sensors, i.e. A2B, Load, and Angle.
  • Page 8: Features

    4.1.1 Liquid Crystal Display The Liquid Crystal Display (LCD) used in the Hirschmann ECS PRS 80 console is a wide temperature- range graphic display with transflective characteristics that give it a high visibility in sunlight and during backlit night operation. Due to the nature of any LCD, it works on the principle of polarization of light. It should be noted that dual polarizations that are at a certain angle to each other can reduce the amount of light up to completely eliminating it if that angle becomes perpendicular.
  • Page 9: Control Identification

    Use this button to decrease values or to scroll down. • Changes which sensors are displayed and how each is displayed Button "SELECT" • Use this button to enter the menu screen and to confirm selections. © Hirschmann ECS, 2006; PRS 80 Wind Speed Rev.C 05/23/06 190184_C...
  • Page 10: System Operation

    The peak will be the highest wind speed recorded since the system was started. When the system is turned off the peak value will be reset. The peak value can also be reset by pressing the button. © Hirschmann ECS, 2006; PRS 80 Wind Speed Rev.C 05/23/06 190184_C...
  • Page 11: Menu's

    Note: a prewarning can be set so as to beep the alarm when a limit is approached but not reached. This is set with the warning option. Menu- SETUP/ SCREEN/BEEPER/ WARNING. © Hirschmann ECS, 2006; PRS 80 Wind Speed Rev.C 05/23/06 190184_C...
  • Page 12: Installation And Setup

    The power supply can be from 12- 24 volt DC. The lockout wire supplies power to operate external solenoids, or relays. The rating of the lockout is 2 amps. An internal fuse protects against overloading this circuit. Power © Hirschmann ECS, 2006; PRS 80 Wind Speed Rev.C 05/23/06 190184_C...
  • Page 13: Wiring

    The wiring at the console connection is: Pin # Description Power 10-30VDC Ground Lockout NO 2 amp max Lockout NC 2 amp max Lockout common 2 amp max Option © Hirschmann ECS, 2006; PRS 80 Wind Speed Rev.C 05/23/06 190184_C...
  • Page 14: Adding Sensors

    4 screws from the transmitter housing and remove the paper insulation tag that reads “REMOVE BEFORE OPERATION” by holding the batteries in place with one hand and removing the tag with the other or insert batteries, if not installed. LOOSEN 4 SCREWS © Hirschmann ECS, 2006; PRS 80 Wind Speed Rev.C 05/23/06 190184_C...
  • Page 15: Wind Speed Sensor

    Affix the mounting pole to the boom tip or possibly the length cable anchor pin so the pipe supports the sensor. It must be installed so that no part of the crane can disrupt the measurement of wind. © Hirschmann ECS, 2006; PRS 80 Wind Speed Rev.C 05/23/06 190184_C...
  • Page 16: Service / Troubleshooting

    When the Hirschmann ECS PRS 80 system is turned on, it will show the following screen. This screen shows the telephone number of Hirschmann ECS and the software version.
  • Page 17: Screens

    To Test the Display: Menu- SETUP/ DIAGNOSTICS/ SCREEN. Various test screens will be displayed by pressing the button. Press to go to the next screen. Note any problems in the display. © Hirschmann ECS, 2006; PRS 80 Wind Speed Rev.C 05/23/06 190184_C...
  • Page 18: To Test The Buttons

    The state of the output will change when the button is pressed. The status indicator text will also change when the button is pressed. © Hirschmann ECS, 2006; PRS 80 Wind Speed Rev.C 05/23/06 190184_C...
  • Page 19: N Odisplay

    1) Water ingress; caused by a cracked or broken housing or lid, or a defective gasket. 2) Condensation This outline gives instructions for detecting the cause for excessive moisture by using simple troubleshooting methods and how to prevent the moisture ingress from happening again. © Hirschmann ECS, 2006; PRS 80 Wind Speed Rev.C 05/23/06 190184_C...
  • Page 20: Troubleshooting Chart

    Transmitter LED Sensor is asleep. Pull switch wire rope. Red LED will flash ~each 2 sec. does not flash Replace batteries. Replace transmitter. © Hirschmann ECS, 2006; PRS 80 Wind Speed Rev.C 05/23/06 190184_C...
  • Page 21: Maintenance

    LED comes on for 1 second, off 1 sec and back on for 1 sec, then begins to flash. Visually inspect the gasket and tighten the battery cover in place with the 4 cover screws. © Hirschmann ECS, 2006; PRS 80 Wind Speed Rev.C 05/23/06 190184_C...
  • Page 22: Part Numbers

    1. 031-300-060-382 1.0 Mounting Arm W/1" Ball PRS80 Console 2. 024-000-100-095 1.0 Membrane Element 3. 031-300-050-223 1.0 Fuse, 2 Amp Auto (Mini) 031-300-060-491 031-300-050-763 cable assembly for PRS80 console Neoprene rubber gasket © Hirschmann ECS, 2006; PRS 80 Wind Speed Rev.C 05/23/06 190184_C...
  • Page 23 RECEIVER LOAD/A2B/WIND/ANGLE 20AWG PWR 031-300-050-672 ANTENNA , 918 MHz MAGNETICBASE 13' long wire 031-300-060-607 SENSOR ASSY, WINDSPEED RADIO MTG PLATE SPREAD SPECTRUM L-B 031-300-050-688 ANTENNA, 918 MHz RCL 90° © Hirschmann ECS, 2006; PRS 80 Wind Speed Rev.C 05/23/06 190184_C...
