Summary of Contents for Inter-m MATRIX RX-8000
Page 1
SERVICE MANUAL S Y S T E M 8 X 8 A U D I O MATRIX PX/RM/LM-8000...
Page 2
PX-8000 RM-8000 LM-8000...
Page 3
ELECTRICAL PARTS LIST (PX-8000) ELECTRICAL PARTS LIST (PX-8000) IC138 R593-594 C22 C96 C607 S35604702430 CAP,CE,MONO,COG,47PF,50V,J,1608,TA IC20 S2110001100 IC,REC/PLAY,APR9600,SOP28 APR 9600 R605-606 C615 C651 C658 Q1 Q10 2008606998-T TR,SG,NPN,300mA,20V,KTD1302,TO-92,TA KTD1302 IC23-24 S2110001200 IC,OP AMP,QUAD,LM324MT,TSSOP 14P LM324 R617-618 C669 C676 C687 2058500973 DIODE,ZN,500mW,BM,4.7V,DO-35,TA 4.7BM IC1-4 IC10-19...
Page 4
C165 C333 C360 R304 R315 4428592530 CON WAFER,BOX(M),30P,2/ST TPH1419-30P C179 C185 C191 C373 C386 R326 R368 R382 S30104727231 RES,TF,4.7K,1/10W,5%,2012 4.7K AN10-11 4428592540 CON WAFER,BOX(M),40P,2/ST TPH1419-40P C197 C203 C209 C18-20 C48-49 3609472120-T CAP,FILM,POLYESTR,0.0047uF,100V,J,TA 4700P100(M) R396 R410 R424 4628981610 SW,SLIDE,HOR,DPDT,S,L6 JSS-2208A C215 C221 C54-64 R438 R452 SW15...
Page 5
ELECTRICAL PARTS LIST (RM-8000) ELECTRICAL PARTS LIST (RM-8000) LED19-21 S30102797231 RES,TF,2.7,1/10W,5%,2012 LED24-26 S30103637230 RES,TF,36K,1/10W,5%,2012 LED29-31 2008606998-T TR,SG,NPN,300mA,20V,KTD1302,TO-92,TA KTD1302 S30103927231 RES,TF,3.9K,1/10W,5%,2012 3.9K LED34-36 2058100964 DIODE,RE,1A,40V,1N5819,DO-41,TA 1N5819 S30103937231 RES,TF,39K,1/10W,5%,2012 LED39-41 2058100996 DIODE,RE,1A,800V,1N4006,DO-41,TA 1N4006(4007) R4-5 S30104717231 RES,TF,470,1/10W,5%,2012 LED8 LED13 S2300000300 LED,SMD,RED,CLR,1U,1608,TA C191KRKT Z3-6 2058502056 DIODE,ZN,500mW,BM,5.6V,DO-35,TA 5.6BM...
Page 6
ELECTRICAL PARTS LIST (LM-8000) ELECTRICAL PARTS LIST (LM-8000) 2058100964 DIODE,RE,1A,40V,1N5819,DO-41,TA 1N5819 2168640978 IC,SW REG,5V,1A,LM2575T-5,T05D LM2575 3089100275 RES,FS,MF,10,1/4W,5%,RA R,TA FR 10 3409222071-T CAP,E,SM,SG,85C,22uF,50V,M,5P,TA 22/50 3409233147-T CAP,E,SM,SD,85C,330uF,25V,M,8x11.5,TA 330/25 4355461901 CON ASS'Y 4P 50MM LM88A ASS'Y-04P 4408193508 JACK,MODULAR,1U,8P,ST,RJ-45 MODULAR08P 4428536309 CON WAFER,LOCK(M),9P,2/AN FMN-BTRK-09P 4428594010 CON WAFER,BOX(M),10P,2/ST 5532-10P...
Page 7
TOP AND BOTTOM VIEW OF P .C.BOARD (PX-8000) TOP AND BOTTOM VIEW OF P .C.BOARD (PX-8000)
Page 11
TOP AND BOTTOM VIEW OF P .C.BOARD (LM-8000) TOP AND BOTTOM VIEW OF P .C.BOARD (LM-8000)
Page 13
TOP AND BOTTOM VIEW OF P .C.BOARD (RM-8000) TOP AND BOTTOM VIEW OF P .C.BOARD (RM-8000)
Page 14: Wiring Diagram
WIRING DIAGRAM WIRING DIAGRAM REMOTE B’D AN10 AN11 CN10 CN11 CN12 DSUB B’D OUTPUT B’D MAIN B’D AC CORD AN109 PWR SW CN1+6 SMPS CN15 CN13 CN14 LED B’D MONITER AN15 SPEAKER FRONT B’D AN13 AN12 PAGING B’D...
Page 15: Block Diagram
BLOCK DIAGRAM BLOCK DIAGRAM...
Page 16
SCHEMATIC DIAGRAM (PX-8000) SCHEMATIC DIAGRAM (PX-8000)
Page 17
> > > >...
Page 18
& & & & &...
