Page 1: Power Supply
Uninterruptible Power Supply SBP Plus Series (Venus Plus) 450-1500 USER'S GUIDE Models: SBP450U Plus-T, SBP650U Plus-T, SBP800U Plus-T, SBP1000U Plus-T, SBP1500U Plus-T... - Page 2 This manual contains important instructions for models SBP450UPlus-T, SBP650UPlus-T, SBP800UPlus-T, SBP1000UPlus-T, SBP1500UPlus-T that should be followed during installation and maintenance of the UPS and batteries. Read this manual thoroughly before attempting to unpack, install, or operate your UPS. Safety Cautions! CAUTION! To prevent the risk of fire or electric shock, install in a temperature and humidity controlled indoor area free of conductive contaminants.
- Page 3 CONSIGNES DE SÉCURITÉ IMPORTANTES CONSERVER CES INSTRUCTIONS Ce manuel contient des instructions importantes pour les modèles SBP450UPlus-T, SBP650UPlus-T, SBP800UPlus-T, SBP1000UPlus-T, SBP1500UPlus-T à suivre lors de l'installation et de la maintenance de l'onduleur et des batteries. Lisez attentivement ce manuel avant de déballer, d’installer ou d’utiliser votre système UPS. Précautions de sécurité! MISE EN GARDE! Pour éviter tout risque d’incendie ou de choc électrique, installez-le dans une zone intérieure à...
-
Page 4: System Description
System Description FRONT PANEL 1.LCD Display The LCD will display the UPS status including input voltage, output voltage, runtime, percentage of load and battery etc. 2.Power On/Off Switch Press the power switch to turn the UPS ON or OFF. Press the power switch 2 times to disable and enable the alarm beeping sound. 3.Led Indicators This LED is illuminated when the UPS is ON. -
Page 5: How To Determine The Power Requirements Of Your Equipment
Installation and Operation UNPACKING Inspect the UPS upon receipt. The box should contain the following: (1) UPS (2) User Manual OVERVIEW The SBP Plus provides automatic voltage regulation for inconsistent utility power, and battery backup during power outages. The SBP Plus ensures consistent power to your computer system and its included software will automatically save your open files and shutdown your computer system during a utility power loss. - Page 6 2. With the UPS turned off and unplugged, connect the computer, monitor, and any equipment into the battery power supplied outlets. DO NOT plug a laser printer, copier, space heater, vacuum, paper shredder or other large electrical device into the battery power supplied outlets. The power demands of these devices will overload and possibly damage the unit.
- Page 7 Computer Connection Connect one computer-related device into each of the power receptacles supplied on the back of the UPS (maximum of three devices). Uninterruptible Power Supply UTBF COMPUTER Modem/Phone line Connection Plug incoming internet line into the “In” socket at the back of the UPS. Use one more Internet line cable and plug one end of the Internet line cable to the “Out”...
-
Page 8: Battery Replacement Procedure
REPLACING THE BATTERY (1000VA/1500VA only) Replacement of batteries located in an OPERATOR ACCESS AREA. 1. When replacing batteries, replace with the same number of the battery． 2. CAUTION! Risk of Energy Hazard! Before replacing batteries, remove conductive jewelry such as chains, wrist watches, and rings. High energy conducted through these materials could cause severe burns. -
Page 9: Power Management Software
Free Software Download Smart Power Master P O W E R M A N A G E M E N T S O F T WA R E Smart Power Master management software provides a user-friendly interface for your power systems. The graphic user-interface is intuitive and displays essential power information at a glance. -
Page 10: Troubleshooting
Troubleshooting Symptom Possible Cause Solution Recharge the battery by Batteries are not fully The UPS does not leaving the UPS plugged in. charged perform expected runtime. battery is slightly worn out Contact technical support The on/off switch is designed Turn the UPS off. Wait 10 to prevent damage by rapidly seconds and then turn the turning it off and on. -
Page 11: Specifications
Specifications MODEL SBP450UPLUS-T SBP650UPLUS-T SBP800UPLUS-T SBP1000UPLUS-T SBP1500UPLUS-T 450 / 270 Rated capacity (VA/W) 650 / 390 800 / 450 1000 / 600 1440 / 900 Rated power factor INPUT 100-120VAC Voltage Input voltage range 82-150VAC 50/60Hz± 3Hz Input frequency range Plug type NEMA 5-15P Plug style... -
Page 12: Definitions For Illuminated Lcd Indicators
Definitions for illuminated LCD indicators LCD Indication Battery Mode Line mode UPS is running on battery UPS is running from an input line mode due to power failure or power source. severe input voltage fluctuation. Mute/Silent Fault Press the power switch 2 times UPS detected a fault to disable and enable the alarm beeping sound. -
Page 13: Limited Product Warranty
LIMITED PRODUCT WARRANTY We warrant this product to be free from defects in material and workmanship for 2 years. The battery has a 2 year warranty. If a product proves to be defective in material or workmanship during the warranty period, we will at our sole option repair or replace the product with a like product. -
Page 14: Fcc Compliance Statement
FCC Compliance Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. - Page 15 P.N.16002111 Rev.06/19 1760 Stebbins Dr. • Houston, TX 77043 1-800-882-8285 • URL:www.smartpowersystems.com Email:support@smartpowersystems.com...
