Summary of Contents for CHIEF PACCS1
- Page 1 I N S T A L L A T I O N I N S T R U C T I O N S Large Shelf Accessory Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description PACCS1...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS! serious personal injury or damage to equipment! It is the installer’s responsibility to make sure the combined weight of all components located on the PACCS1 does not exceed WARNING: A WARNING alerts you to the possibility of 15 lbs (6.8 kg). - Page 3 Installation Instructions PACCS1 LEGEND Tighten Fastener Hex-Head Wrench Apretar elemento de fijación Llave de cabeza hexagonal Befestigungsteil festziehen Sechskantschlüssel Apertar fixador Chave de cabeça sextavada Serrare il fissaggio Chiave esagonale Bevestiging vastdraaien Zeskantsleutel Serrez les fixations Clé à tête hexagonale...
-
Page 4: Tools Required For Installation
PACCS1 Installation Instructions TOOLS REQUIRED FOR INSTALLATION 1/8" (included) 1/4" PARTS A (1) [Shelf Bracket] C (1) [Shelf] B (1) [Adjustment Bracket] G (4) [Rubber Bumper] H (6) F (4) [Cable Tie] D (1) [Mounting Button] [Right Upright] J (2) 1"... -
Page 5: Assembly And Installation
400 x 400 VESA display mounting pattern. IMPORTANT ! : If installing the PACCS1 with the PACLR1 the top mounting flange on the PACCS1 must hang over the top (Q) x 2 of the lower speaker rail on the PACLR1 when installed. (See... - Page 6 Close Flag Display Figure 6 Adjustments The PACCS1 allows for vertical adjustment of the shelf to provide a flush installation against the bottom of the display. To adjust shelf vertical position: Loosen two button head cap screws securing adjustment bracket to shelf bracket using 1/8" hex wrench (K). (See...
- Page 7 Installation Instructions PACCS1 Reposition shelf up or down to desired position. (See Cable Management Figure 7) Route cables and wires to display using cable ties (H) as Tighten two button head cap screws securing adjustment necessary, and following manufacturers installation instructions.
- Page 8 Europe A Franklinstraat 14, 6003 DK Weert, Netherlands P +31 (0) 495 580 852 F +31 (0) 495 580 845 Chief Manufacturing, a products division Asia Pacific A Office No. 1 on 12/F, Shatin Galleria of Milestone AV Technologies 18-24 Shan Mei Street...
