X2
General Purpose
THE TERMINAL
*
D. Laser Safety Label
A. Color Display
B. Front Scan Key
E. Product Label
C. Keyboard
F. Micro USB Port
G. Cold Boot Button
*. Remove protective film cover before use
H. Data Capture
I. Dock Contacts
Window
(
822001771
Rev A)
Nov. 2017
K
EYPAD
1. Programmable Function Keys.
2. Scan Key – Use it to turn on the Joya X2.
G
S
ETTING
TARTED
Insert the Battery
1. Insert battery contacts into the hole of the
battery box as shown in the picture below
2. Unscrew and remove the bottom cover
3. Insert the top cover, then insert the bottom
cover and fasten it with a screwdriver
Charge the Battery
With Single Slot Dock
Do not use the Joya X2 until
batteries are charged for minimum
4 hours.
CAUTION
We recommend that the Joya X2 GP
is used only for WiFi applications.
The microUSB connector is intended
only
for
occasional
N
OTE
communications.
R
J
X2
ESETTING THE
OYA
Cold Boot
Simultaneously press F1 + F2 + ENTER
Or
Press with a pin or a paper clip the cold boot
button on the back of the mobile computer.
Warm Boot
Simultaneously press SCAN + ENTER.
Clean Boot
1. Perform a cold boot
2. As soon as the device is rebooting, press
simultaneously Esc + ENTER, holding both
keys down for few seconds
3. Press ENTER to confirm.
Suspend
Simultaneously press SCAN + F1
Resume from Suspend
Press SCAN.
