Datalogic JOYA X2 Quick Start Manual

X2
General Purpose

THE TERMINAL

* D. Laser Safety Label
A. Color Display
B. Front Scan Key E. Product Label
C. Keyboard F. Micro USB Port
G. Cold Boot Button
*. Remove protective film cover before use
H. Data Capture I. Dock Contacts
Window
K
EYPAD
1. Programmable Function Keys.
2. Scan Key – Use it to turn on the Joya X2.
R J X2
ESETTING THE OYA

Cold Boot

Simultaneously press F1 + F2 + ENTER
Or
Press with a pin or a paper clip the cold boot
button on the back of the mobile computer.

Warm Boot

Simultaneously press SCAN + ENTER.

Clean Boot

1. Perform a cold boot
2. As soon as the device is rebooting, press
simultaneously Esc + ENTER, holding both
keys down for few seconds
3. Press ENTER to confirm.

Suspend

Simultaneously press SCAN + F1

Resume from Suspend

Press SCAN.
G S
ETTING TARTED

Insert the Battery

1. Insert battery contacts into the hole of the
battery box as shown in the picture below
2. Unscrew and remove the bottom cover
3. Insert the top cover, then insert the bottom
cover and fasten it with a screwdriver

Charge the Battery

With Single Slot Dock
Do not use the Joya X2 until
batteries are charged
minimum 4 hours.
CAUTION
We recommend that the Joya X2
GP is used only for
applications. The microUSB
connector is intended only for
N
occasional communications.
OTE
for
WiFi
