The charging procedure is automatically started and the light will flash blue.
To stop the charging process, hold your pass in front of the scan point or
press the button (only for the version with a button). You will hear 2 audio
signals, the light starts to blink green and stops when the plug is unlocked.
You can now remove the plug.
The version with a flexible/spiral cable does not lock/unlock the Homebox.
The button or autostart operation is used instead of the scan point; with this
version no back office check is needed to start the system.

24. TECHNICAL SPECIFICATIONS

Number of charging points:
Power output:
Socket:
Flexible coiled cord:
Protocol:
Positioning:
Communication:
Connection value:
Output voltage:
Total weight: with socket:
with coiled cord:
Casing dimensions HxWxD:
Casing material:
Standard colour:
Water resistance:
Vandalism resistance:
Treatment:
Operating/ambient temperature:
Ecotap® B.V. reserves the right to change the above technical data without
prior notice as a result of continued innovative development of the charging
system. Please note also that the technical data may vary between countries.
1
22 Kw
Type 2
Type 1 of Type 2
Mode 3
GPS (with registration)
GSM Modem / Controller with
RFID-reader (with registration)
1x 16A tot 3x 32A
230 V/ 400 V 50 Hz
10 Kg
12 Kg
530 mm x 220 mm x 200 mm
Steel 2,2 mm
RAL 7011/RAL 9016
IP 54
IK 10
Anti-corrosion and powder coating
-25°- tot 60°
