IVEK SPLIT CASE PUMP MODULE 092122 Series Manual page 16

SPLIT CASE PUMP MODULE
Model Dwg
# Index
Tab #
103 7
104 7
105 7
106 7
113 7
15 July, 2019
Part
#
022218-103
022218-104
022218-105
022218-106
022218-113
Figure
Figure 7.7 Split Case Pump Module (Sheet 3 of 3)
Description
" ; C-Size Alum W/Gland
" ; C-Size Zirc W/Gland
" ; D-Size Alum W/Gland
" ; D-Size Zirc W/Gland
" ; 16mm Alum W/Gland
Figure 7.7 Split Case Pump
Module (Sheet 2 of 2)
Figure 7.7 Split Case Pump
Module (Sheet 2 of 2)
IVEK Corp.
Page 7-16
Qty
1
1
1
1
1
P07R002P
