SPLIT CASE PUMP MODULE
Assembly
1. Tighten a maximum of 1.4 N-M (12 in. lbs.) the two fitting sets (12) using spanner wrench provided.
7.6

PROBLEM GUIDE

7.6.1

Piston Frozen In The Cylinder

If the piston gets frozen in the cylinder perform the following steps.
DO NOT TRY TO FORCE THE PISTON FREE!
Damage to the piston/cylinder set may occur.
1. Carefully remove the Pump Module from the Motor/Base Module. Remove the piston and cylinder from the split
case then soak in a compatible solvent.
2. If the Pump Module is not conveniently removable, the tube loop described in section 7.5.2.3 of this chapter may
permit solvent to dissolve the "frozen" residue in reasonable time.
3. If the aforementioned procedures fail, contact IVEK for technical help. It may be necessary to ship the Pump Module back
to the factory. Provide a note describing, in detail, what conditions caused the seizure and what liquids are being pumped.
It may also be necessary to return the Controller and Motor/Base Modules along with the Pump Module should
readjustment of the pump drive components be required to free the pump.
Table 7.2 contains a list of possible problems, causes and solutions for the Pump Module.
7.7

SPECIFICATIONS

7.7.1

Volume

The volume represents the liquid displaced for a single revolution of the motor. If this system is used for dispensing, the
dispenser's VOLUME STROKES setting will determine the total volume for each dispense cycle. Table 7.1 list the
recommended minimum and maximum displacement per stroke for the different size Pump Modules.
Table 7.1 Pump Module Displacement Specifications
Size Max Displacement
Per Stroke
B 0.295 ml
C 0.739 ml
D 1.478 ml
16mm 1.886 ml
7.8

MODEL NUMBER

The model number provides important information about the specifics of your Pump Module. Refer to this number when calling
IVEK Technical support. The model number for your Pump Module is located in the Title Page section of this manual.
15 July, 2019
CAUTION
Recommended
Min Displacement
Per Stroke
0.015 ml
0.037 ml
0.074 ml
0.094 ml
IVEK Corp.
Page 7-11
