SPLIT CASE PUMP MODULE
Case Type
1 - No Heater Ports, 420SS Locating Key
2 - No Heater Ports, 316SS Locating Key
3 - Heater Ports, 420SS Locating Key
4 - Heater Ports, 316SS Locating Key
O-Ring Material
1 - Buna-N
2 - Ethylene Propylene
3 - Kalrez
4 - Polyurethane
5 - Silicone
6 - Teflon
7 - Teflon Encapsulated Silicone
8 - Viton
Ceramic Size and Material
001 - B-Size Alumina
002 - B-Size Zirconia
003 - C-Size Alumina
004 - C-Size Zirconia
005 - D-Size Alumina
006 - D-Size Zirconia
013 - 16mm-Size Alumina
101 - B-Size Alumina W/Gland
102 - B-Size Zirconia W/Gland
103 - C-Size Alumina W/Gland
104 - C-Size Zirconia W/Gland
105 - D-Size Alumina W/Gland
106 - D-Size Zirconia W/Gland
113 - 16mm Size Alumina W/Gland
An example of a Pump Module model number would be 092122-18004. This would be a Split Case Pump Module without
heater ports, 420SS Locating Key with a Viton O-ring and C-size Zirconia piston/cylinder set.
7.9

ILLUSTRATED PARTS BREAKDOWN

The illustrated parts breakdown (Figure 7.7) contains the information required for identifying and ordering parts for the
Split Case Pump Module.
15 July, 2019
092122 - # # ###
