Digital Outputs, Removing pull-up resistor

h t t p : / / w w w . l i n t r o n i c . d k

TableTop series

Digital Outputs - relay control

and

How to remove pull-up resistor

Hardware Version 4 and 5

IR-Tx

IR-Rx

IR-Tx

http://www.lintronic.dk

Updated: 080207

Need help?

Do you have a question about the TableTop Series and is the answer not in the manual?

Questions and answers

Summary of Contents for LinTronic TableTop Series

Page 1 Digital Outputs, Removing pull-up resistor h t t p : / / w w w . l i n t r o n i c . d k TableTop series Digital Outputs - relay control How to remove pull-up resistor...
Page 2: Hardware Version
350 mA or more 350 mA or more the bottom of the cabinet TT455-RT-238 Hardware version: 5.1 Made in Denmark, http://www.lintronic.dk Hardware Version 5.1 offers 2 digital outputs found on pin 6 and pin 9. Pin 5 is ground reference.
Page 3 When the 100K pull-up resistor is removed, the diagram looks like shown on the right. ZenerDiode The built-in 27 volt ZenerDiode will protect against relay coil surge spikes. 12 or 24 volt TableTop Output TableTop pin 5 Ground http://www.lintronic.dk Updated: 080207...
Page 4 350 mA or more 350 mA or more the bottom of the cabinet TT455-RT-238 Hardware version: 5 Made in Denmark, http://www.lintronic.dk Hardware Version 5 offers 2 digital outputs found on pin 6 and pin 9. Pin 5 is ground reference.
Page 5 If you want to control a 12 or 24 volt relay be sure to use an external 12 or 24 volt protection diode to kill relay coil surge spikes. TableTop Output TableTop pin 5 Ground http://www.lintronic.dk Updated: 080207...
Page 6 350 mA or more 350 mA or more 350 mA or more the bottom of the cabinet TT455-RT-238 Hardware version: 4 Made in Denmark, http://www.lintronic.dk Hardware Version 4 offers 1 digital output found on pin 6. Pin 5 is ground reference. Input...
Page 7 If you want to control a 12 or 24 volt relay be sure to use an external 12 or 24 volt protection diode to kill relay coil surge spikes. TableTop pin 6 TableTop pin 5 Ground http://www.lintronic.dk Updated: 080207...
