LinTronic TT455-RT-238 Hardware Manual

Signal converter hardware version 6 / 6.1
Hide thumbs Also See for TT455-RT-238:

Advertisement

Quick Links

Download this manual See also: Manual, Quick Manual
LinTronic
TT455-RT-238
Signal Converter
Hardware version 6 / 6.1
Updated 180822

Advertisement

loading
Need help?

Need help?

Do you have a question about the TT455-RT-238 and is the answer not in the manual?

Questions and answers

Related Manuals for LinTronic TT455-RT-238

Summary of Contents for LinTronic TT455-RT-238

  • Page 1 LinTronic TT455-RT-238 Signal Converter Hardware version 6 / 6.1 Updated 180822...
  • Page 2 LinTronic We keep expanding Hardware 6 Introduced 2011 Hardware 5 Introduced 2006 Hardware 4 Introduced 2003 32KByte 128KByte 256KByte...

  • Page 3: What's New

    LinTronic What's new ? Feature Hardware 5 Hardware 6 Built-in 455 KHz receiver for B&O External 455 KHz receiver required for B&O Reading IR receivers buttons Control of IR receivers LEDs Number of RS232 comports Programmable RS232 signals/port Ready for B&O Masterlink Gateway...
  • Page 4 LinTronic What's new ? 31. July 2018 We added support for this 8-channel relay. See section about RS232.
  • Page 5 LinTronic Hardware 6.1 includes a new 3 volt IR LED with 30% more light adding 30% to the original range. When controlling B&O systems, this increases the operation range to beyond BEO4 level. 850 NM 940 NM Hardware Version Hardware Version...
  • Page 6 LinTronic Circuit boards dimensions GREEN LED 1 RED LED GREEN LED 2 940 nM 850 nM 940 nM 93 mm...
  • Page 7 LinTronic Programmable jack-connector IR LOW-POWER OUTPUT 2 IR BUTTONS/LED FACTORY DEFAULT LED 1 IR RECEIVER Button 1 Button 2 Button 3 Button 4 LED 2...
  • Page 8 Unfortunately the cable wires, often vary in colors. Below we have listed the typical combinations. If the cable you have received, is not included below, then please contact LinTronic, or get some local help to measure how the cable is wired. Cable type 1 Pin Letter Desc...
  • Page 9 LinTronic Programmable jack-connector IR AND BUTTONS CONTROL If you want to make use of the buttons or the LEDs of your external B&O receiver, the jumpers must be in this position (factory set). You wire two 3.5 mm jack connectors as show...
  • Page 10 LinTronic Programmable jack-connector BUTTONS CONTROL ONLY If you only want to control the TT455-RT-238 by the buttons on the front of the external receiver, you will still need to install both connectors. The data wire carrying the IR signal can be leaved out.
  • Page 11 B&O 8087030 3 - B IR SIGNAL 4 - C 5 Volt 5 - A Ground Jack connector seen from solderside TO TT455-RT-238 OR BEOSYSTEM A Jack connector seen from solderside Do not connect center, 5 volt IR/DATA Ground TO TT455-RT-238...
  • Page 12 LinTronic IR receivers & transmitters B&O 455 KHz oscillator IR TRANSMITTER FRONT IR LOW-POWER OUTPUT 2 IR LOW-POWER 2 IR LOW-POWER 1 IR RECEIVER 3-CHANNEL SOFTWARE PROGRAMMABLE IR DISTRIBUTOR LEVEL 50% or 100% IR FRONT BOOSTER IR LOW-POWER 1 IR TRANSMITTER...
  • Page 13 LinTronic External low-power IR output TableTop Transmitter or Converter TT-IR-ET02 Input Output Communication Output Power 2 pcs low-power IR outputs...
  • Page 14 LinTronic RS232 comports Digital Inputs Digital Outputs 5 volt pulled-up. 100K active low, 5 volt pulled-up Programmable RS232 PORT 1 RS232 PORT 2 Rx (in) Rx (in) Tx (out) Tx (out) SOFTWARE PROGRAMMABLE RS232 DISTRIBUTOR RS232 COMPORT 2 RS232 COMPORT 1...
  • Page 15 - 4 paired relays (for example curtains, lifts, motors) Activate the wanted relay and it will turn off automatically when wanted. Timing can easily be adjusted in the configurator: TT455-RT-238 - RELAY 208 For operation and timing - see manuals for RELAY 208: http://lintronic.dk/getstarted.aspx...

  • Page 16: Digital Inputs

    The digital Input is internally pulled up by a 100 Kohm resistor. In order to activate the input, the input pin 1, must be grounded. The TT455-RT-238’s digital inputs can be configured to react to both ON and OFF. This allows you to activate one action when the input is activated and another action when the input is released.
  • Page 17 LinTronic Digital Outputs The digital outputs are programmable in the in/out tab, in Memory Map of the Configurator. Outputs can work as: Active 12 volt (default) Active Ground Ative Ground with 5 volt pull-up...
  • Page 18 LinTronic Digital Outputs, Active 12 volt The digital outputs are designed for direct control of 12 V relays. This can be used to control lamps, curtains, motors, etc. We offer Schrack relays and DIN/WALL mount housing. Active 12 volt 12 volt...
  • Page 19 LinTronic Digital Output 1, Active 12 volt 12 volt Pin 6 Digital output 1 COIL Pin 5 = Ground Digital Output 2, Active 12 volt 12 volt Pin 9 Digital output 2 COIL Pin 5 = Ground...
  • Page 20 Run pin 14 (on/off output for lamp 1) to lamp 1. Run pin 24 (on/off output for lamp 2) to lamp 2. Run TT455-RT-238's digital output 1 (or 2) to A2 (coil) of the relay. Run TT455-RT-238's ground to A1 (coil) of the relay.
  • Page 21 LinTronic Digital Outputs, Active Ground Active ground 5 volt 100K solder 6 or 9 The Digital Output is a Ground-active Open Collector. When the output is on the signal is grounded. An internal optional 5 volt pull-up resistor can be connected, by soldering a solder-pad for each output.
  • Page 22 Digital Outputs, Active Ground The below red marking shows where to solder, in order to insert the 5 volt pull-up resistor for the digital output 2. Simply solder the two pads together. OBSERVE Please consult with LinTronic before soldering. Updated 110725...
  • Page 23 RS232 comport 2 Computer, Controller, PLC, Computer, Controller, PLC, B&O MasterLink gateway, B&O MasterLink gateway, RELAY RELAY 208 board,TT455-RT-238, 208 board, TT455-RT-238, light light system,audio/video switcher, system, audio/video switcher, tv, tv, screen,projector, etc. screen, projector, etc. 2 pcs. Digital inputs 2 pcs.
  • Page 24 LinTronic Selectable IR and RS232 ports Send commands to an optional port In this example - triggered by the BEO4 or BEO5 - we send out an RS232 command to a relay board in order to close the curtains, we send an RS232 command to lower the light levels and we send an infrared PLAY command the DVD player.
  • Page 25 LinTronic Selectable IR and RS232 ports Receive RS232 commands as trigger In this example we receive a customized RS232 command from a B&O Masterlink Gateway, then converts it to a command for the RELAY 208 board (curtains, lift, etc.) or your light system - and control multiple audio/video devices by infrared.
  • Page 26 LinTronic Cascading transparent RS232 ports Example: A computer sends a command to ADR 3. The command will pass through ADR 1 and ADR 2 and finally reach ADR 3. Port 1 Port 2 Port 1 Port 2 Port 1 ADR 1...
  • Page 27 TT455-RT-238 (audio/video), the RELAY 208 (curtains, lift, etc.) and your light system. Simply control the TT455-RT-238 and let it control the rest - or send the commands straight through the TT455-RT-238 or the RELAY 208.
  • Page 28 Perfect for B&O MasterLink Gateway Since the B&O MasterLink Gateway only holds one RS232 port, you can now expand the controls to include for example the TT455-RT-238 and/or the RELAY 208 and/or your light system, etc. etc. B&O MasterLink Gateway Light system B&O receiver...
  • Page 29 We offer you endless combinations The Iphone controls the B&O MasterLink Gateway, which controls the TT455-RT-238, which controls your audio/video by IR, and controls your curtains by relays and your light system by RS232 - even if your products are not supported by B&O MasterLink Gateway.
  • Page 30 LinTronic BeoRepeater / MultiRoom Allows your TT455-RT-238 to "shoot around corners" and "through" walls. Room 3 Room 2 Room 1 Updated 110725...
