QuickStart
MODEL RSW12V
™
& RSW12VH
This QuickStart is intended to highlight a
single right-hand gate application. Each
application is unique and it is the
responsibility of the purchaser, installer and
end user to ensure that the total gate
1
system is installed and operated properly.
Refer to the installation manual for
complete information regarding installation,
Dimension (A) thru (E) are from the center of one pivot point to
Testing and programming.
the center of another pivot point.
1
Determine location for the concrete pad
according to the charts shown.
2
Install the electrical conduit and pour the
concrete pad.
3
Attach the operator to the concrete pad.
4
Weld the gate bracket in position according
to the charts shown.
5
Weld the long arm section to the correct
length as shown in the charts.
6
Weld the short arm section to the correct
length as shown in the charts.
Caution: If the gate is longer than 18 feet, follow CHART A: A-2.
7
Position the operator arm onto the output
shaft so that the pin slides into the slot.
A
8
Adjust the nuts on the operator arm so the
operator arm fits snug on the output shaft
46"
35.5"
1
yet still allows enough room to swivel (the
handle must be in a 90° position).
2
46.75"
35.5"
3
46.75"
9
Tighten the handle by pushing it down. Test
to make sure the operator arm does not slip
on the output shaft.
47.25"
37.25"
4
5
47"
6
42.5"
for single gate applications
™
Gate Hinge Center
A
OUT
IN
B
E
Long Arm
C
Short Arm
OUT
IN
D MINUS 10"
D
10"
DISTANCE
CHART A
CHART B
B
C
D
E
A
B
29.5"
35"
11"
45"
34.5"
34.75"
29.5"
1
33.5"
42"
11"
37"
2
44"
36.5"
32.5"
37"
31.5"
40"
11"
41"
3
44"
37"
30.5"
30"
37"
11"
45"
45"
37"
30.5"
4
35"
29.5"
32"
11"
45"
5
44.75"
35.75"
29.5"
33"
26.5"
28.5"
11"
41"
6
41"
39"
27.5"
Concrete Pad
3
4 Concrete Anchors
1/2" x 3 1/2"
Suggestion: The dimensions between the gate and the
concrete pad is always 10 inches less than the dimension D.
Example: D = 42", if the dimensions between the gate
and the concrete pad is 32".
6" ABOVE GROUND
2
C
D
E
35"
14"
43"
42"
14"
32"
40"
14"
40"
37"
14"
43"
32"
14"
44"
28.5"
14"
41"
4
5
11
Gate
Bracket
Long Arm
30"
BELOW
GROUND
28"
6
Short Arm
7
Slot
Pin
8
Nuts
Handle
9
24"
