feather&black Provence Series Assembly Instruction

Bed

Provence Collection

Universal Assembly Instruction

135cm Double Bed

150cm King Size Bed

180cm Super King Size Bed

Step By Step Assembly Instructions

PRE-ASSEMBLY PREPARATION

1. Please check the part contents before attempting to assemble this product. A full checklist of

components is given in this leaflet. If any components are missing, please contact the retailer from

whom you bought this product.

2. This product is HEAVY, it should be assembled as near as possible to the point of use. TAKE

CARE WHEN LIFTING to avoid personal injury and (or) damage to the product.

3. This product takes approximately 60 MINUTES to assemble with 2 PEOPLE.

4. The fittings pack contains SMALL ITEMS which should be KEPT AWAY FROM YOUNG

CHILDREN.

5. Read this leaflet in full before commencing assembly.

6. You will require a cross head screwdriver (not provided) and a spanner (provided) to assemble this

product.

Page 1

Table of Contents

Do you have a question about the Provence Series and is the answer not in the manual?

Page 1 Provence Collection Universal Assembly Instruction 135cm Double Bed 150cm King Size Bed 180cm Super King Size Bed Step By Step Assembly Instructions PRE-ASSEMBLY PREPARATION 1. Please check the part contents before attempting to assemble this product. A full checklist of components is given in this leaflet.
Page 2 Panel and Fittings Identification Item Description Item Description Item Description Qty. Qty. Qty. Headboard Footboard Side Rail Slat Centre Rail 135cm 150cm/180cm 12mm Spanner Flat Washer Spring Washer Slats cap Bracket 135cm 150cm/180cm Flat Washer 12 N Dowel Page 2...
Page 3 Step 1 -Insert four wooden dowels (P) into the headboard (A) and footboard (B). This will assist in the alignment of the side rail. Screw the eight threads (F) into the headboard (A) and footboard (B) and tighten by hand. Ensuring that there is enough thread remaining for attachment in Step 2.
Page 4 Step 3 -Attach the brackets (L) to the headboard and footboard using the screws (M) inserted into the pre-drilled pilot holes. Tighten using a cross head screwdriver (Not provided). L x 2 Crosshead M x 12 screwdriver (Not provided) Step 4 -Locate the centre rail (D) into the brackets.
Page 5 Step 5 -Push fit two plastic caps (K) onto either end of each slat (E). Push fit the slat (E) into the pre-drilled pilot holes. Please note that the slat may need to be pushed flat to ease installation. It may also require a light tap with a soft hammer to secure the plastic end caps into the holes.
