- Page 1 Инструкция по использованию гитарных звукоснимателей EMG 81TWX (на английском языке) • Размеры звукоснимателя EMG • Технические характеристики • Перечень комплекта поставки • Схемы подключения для различных конфигураций в картинках...
- Page 2 Warranty All EMG Pickups and accessories are warranted for a period of two years. This warranty does not cover failure due to improper installation, abuse or damage. If upon examination the pickup is determined to be defective, a replacement will be made. Warranty replacement products are covered by this same warranty. This warranty covers only those pickups and accessories sold by authorized EMG Dealers.
- Page 3 WHITE sound in either the up or down position and the same for the dual-coil sound. YELLOW Diagrams #1 and #2 show how to connect the 81-TW-X pickup cable to choose BLUE Diagram #2 either option. Select the diagram that suits you and push the cable...
- Page 4 Installation (One Pickup Guitars): 1) Plug the pickup cable onto the EMG Pickup header as shown in diagram #6 and route the cable to the control cavity. Diagram #6 If the cable is too long, wind up the excess and keep it...
- Page 5 Diagram #10 2 Pickups (1 EMG + 1-TW) Toggle Style Select Switch Push-Pull Pot as Master Volume with a Master Active Tone - 9V + BATTERY NEG (-) GROUND NOTE REVERSED CONNECTOR NECK P/U MASTER TONE (VLPF) OUTPUT BRIDGE P/U...
