Instructions
Double Drop Kit / Additional Bead Gun Kit for
™
RoadLazer
For use on RoadPak
Model 24G775
Important Safety Instructions
Read all warnings and instructions in this manual and in related manuals.
Be familiar with the controls and the proper usage of the equipment.
Save these instructions.
Related Manuals:
3A5384
Operation
™
RoadPak
™
Line Striping Systems. For Professional use only.
Line Striping System
3A1308C
EN

Advertisement

loading

Related Manuals for Graco 24G775

Summary of Contents for Graco 24G775

  • Page 1 For use on RoadPak ™ Line Striping Systems. For Professional use only. Model 24G775 Important Safety Instructions Read all warnings and instructions in this manual and in related manuals. Be familiar with the controls and the proper usage of the equipment.

  • Page 2: General Instructions

    General Instructions Bead Hose The following paragraphs provide instructions for install- 1. Unstrap and unclamp hose wrap so hose (13) can ing the Double Drop Bead Kit or Additional Bead Gun kit be added to the bundle. components on the RoadPak Line Striper. Refer to 2.
  • Page 3 Additional Bead Gun Kit Operation 1. Install hose fitting (12) to bead gun (1). 1. Bead gun will actuate with same paint gun if selected using the skipline control. 2. Install mounting arm (8) to bead gun, and dual wing- nut clamp (9) to arm (8).
  • Page 4 Parts Parts Ref. Part Description Qty. 24G979 GUN, spray, bead 191164 ARM, mtg, gun 24Y645 KIT, clamp, dual wingnut 111834 NIPPLE, pipe, hex 16G167 HOSE, bead, 3/4 in., clear 191163 ARM, pivot, gun narrow 192214 ARM, pivot, gun wide (optional) 24J173 DEFLECTOR, adjustable bead 238664 SEAT, valve 238665 SEAT, valve...

  • Page 5: Graco Standard Warranty

    With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.

  • Page 6: Graco Information

    Graco Information For the latest information about Graco products, visit www.graco.com. TO PLACE AN ORDER, contact your Graco distributor or call 1-800-690-2894 to identify the nearest distributor. For patent information, see www.graco.com/patents All written and visual data contained in this document reflects the latest product information available at the time of publication.
