Summary of Contents for Graco 234237

Page 1: Table Of Contents
Garantia Standard da Graco / Garanzia standard Graco ........34...
Page 2 Read fluid and solvent manufacturer’s warnings. For complete information about your material, request MSDS from distributor or retailer. • Check equipment daily. Repair or replace worn or damaged parts immediately with genuine Graco replacement parts only. • Do not alter or modify equipment.
Page 3 Type, Model Trigger Tip Guard No., Series Silver 5000 psi 4-finger trigger HandTite Tip Guard 517 RAC V SwitchTip 234237, A (345 bar, 34.5 MPa) Silver, 5000 psi Standard (nonreversing) No Spray Tip. 2-finger trigger 235460, C (345 bar, 34.5 MPa)
Page 4: Warning / Mise En Garde / Advertencia / Advertência / Pericolo
Pour plus d’informations sur votre produit, demandez la fiche de sécurité produits à votre distributeur ou revendeur de produit. • Vérifier le matériel quotidiennement. Réparer ou remplacer immédiatement toutes les pièces usées ou endom- magées uniquement par des pièces d’origine Graco. • Ne pas modifier cet équipement. •...
Page 5 Protecteur de buse Buse série Silver 5000 psi Gâchette 4 doigts Garde-buse HandTite Buse 517 RAC V SwitchTip 234237, A (345 bar, 34,5 MPa) Silver, 5000 psi Garde-buse standard Dripless Pas de buse. Gâchette 2 doigts 235460, C (345 bar, 34,5 MPa) (non réversible)
Page 6 Para obtener información completa sobre su material, pida la MSDS a su distribuidor o detallista. • Revise el equipo a diario. Repare o cambie inmediatamente las piezas desgastadas o dañadas únicamente con piezas de repuesto originales de Graco. • No altere ni modifique el equipo.
Page 7 Gatillo Portaboquillas Boquilla serie Silver 5000 psi Gatillo para Portaboquillas HandTite Boquilla de giro 517 RAC V 234237, A (345 bar, 34,5 MPa) 4 dedos Silver, 5000 psi Gatillo para Portaboquillas estándar Sin boquilla de pulverización. 235460, C (345 bar, 34,5 MPa)
Page 8 Não altere nem modifique este equipamento. • Utilize o equipamento apenas para o fim a que se destina. Solicite informações ao seu distribuidor Graco. • Afaste os tubos flexíveis e cabos de áreas com movimento, pontas afiadas, peças em movimento e superfícies quentes.
Page 9 Bico modelo, Série de trabalho Silver 5000 psi Gatilho de Protector do bico HandTite 517 RAC V SwitchTip 234237, A (345 bar, 34,5 MPa) 4 dedos Silver, 5000 psi Gatilho de Protector do bico Dripless de Sem bico de pintura.
Page 10 • Non alterare o modificare l’attrezzatura. • Utilizzare l’apparecchiatura solo per gli scopi previsti. Per informazioni, contattare il distributore Graco. • Disporre i flessibili e i cavi lontano da aree trafficate, spigoli vivi, parti in movimento e superfici calde. •...
Page 11 Protezione dell’ugello Ugello N. modello, serie Silver 345 bar, 34,5 MPa Grilletto Protezione dell’ugello HandTite SwitchTip RAC 517 V 234237, A (5000 psi) a 4 dita Silver, 345 bar, 34,5 MPa Grilletto Protezione dell’ugello standard Senza ugello di spruzzatura. 235460, C...
Page 12: Component Identification
Component Identification / Identification des composants / Identificación de los componentes / Identificação dos componentes / Identificazione dei componenti Component Identification / Identification des compo- sants / Identificación de los componentes / Identifica- ção dos componentes / Identificazione dei componenti ti6929b English Français...
Page 13: Grounding / Mise À La Terre / Conexión A Tierra / Ligação À Terra
Grounding / Mise à la terre / Conexión a tierra / Ligação à terra / Messa a terra Grounding / Mise à la terre / Conexión a tierra / Ligação à terra / Messa a terra English Français Español Português Italiano The sprayer must be Ce pulvérisateur doit être...
Page 14 Grounding / Mise à la terre / Conexión a tierra / Ligação à terra / Messa a terra ti5851a ti6934a • Ground the metal pail by • Maintain grounding connecting a ground wire continuity when flushing to the pail by clamping or relieving pressure by one end to pail and the holding metal part of...
Page 15: Pressure Relief Procedure
Pressure Relief Procedure / Procédure de décompression / Procedimiento de descompresión / Procedimento de descompressão / Procedura di decompressione Pressure Relief Procedure / Procédure de décompres- sion / Procedimiento de descompresión / Procedimento de descompressão / Procedura di decompressione English Français Español Português...
Page 16 Pressure Relief Procedure / Procédure de décompression / Procedimiento de descompresión / Procedimento de descompressão / Procedura di decompressione ti6932a ti6934a Trigger gun into grounded Engage trigger lock. metal bucket. Actionner le pistolet en Verrouiller la gâchette. le tenant dans un seau métallique mis à...
Page 17: Setup / Réglage / Ajuste / Preparação / Configurazione
Setup / Réglage / Ajuste / Preparação / Configurazione Setup / Réglage / Ajuste / Preparação / Configurazione Installing Tip and Guard / Montage de la buse et de sa protection / Instalación de la boquilla y del portaboquillas / Instalação do bico e do protector / Installazione ugello e protezione ti6932a WARNING...
Page 18 Setup / Réglage / Ajuste / Preparação / Configurazione ti6932a • Non oltrepassare la • La mancata installazione Mettere la sicura alla Se sono stati utilizzati lo pressione massima di o l’utilizzo non corretto di pistola. spruzzatore e la pistola, esercizio di 5000 psi un gruppo di protezione scaricare la pressione.
Page 19 Setup / Réglage / Ajuste / Preparação / Configurazione ti6770a ti6966a ti6968a ti7033a WARNING Always replace One- Use end of SwitchTip (A) Insert SwitchTip in tip bore. • Be sure you fully insert ™ ™ Firmly thread assembly onto SwitchTip (A) into tip Seal when replacing to press OneSeal...
Page 20 Setup / Réglage / Ajuste / Preparação / Configurazione ti6937b Connect hose to gun. Refer to sprayer opera- • The trigger force is less Check all connections for tion manual to start and then 10 Lbs (4,5 Kg) to acti- tightness.
Page 21: Spray Instructions
Spray Instructions / Instructions de pulvérisation / Instrucciones de pulverización / Instruções de pintura / Istruzioni di spruzzatura Spray Instructions / Instructions de pulvérisation / Instrucciones de pulverización / Instruções de pintura / Istruzioni di spruzzatura Align Spray / Aligner le jet / Alinear la pulverización / Alinhamento do leque / Allineamento spruzzatura ti7034a ti6939a...
Page 22 Spray Instructions / Instructions de pulvérisation / Instrucciones de pulverización / Instruções de pintura / Istruzioni di spruzzatura Adjust Spray / Régler le jet / Ajustar pulverización / Regulação do leque / Regolazione spruzzatura ti6970a ti6933a ti6932a ti6940b Engage trigger lock. Install tip and guard if Disengage trigger lock.
Page 23 Spray Instructions / Instructions de pulvérisation / Instrucciones de pulverización / Instruções de pintura / Istruzioni di spruzzatura 12" ti6941a ti6942a 5. Hold gun perpendicular and approximately 12 in. 6. Slowly increase pump pressure until coverage is (304 mm) from surface. Move gun first, then pull gun even and uniform.
Page 24: Clear Clog / Déboucher / Elimine La Obstrucción / Desobstrução
Clear Clog / Déboucher / Elimine la obstrucción / Desobstrução / Pulizia delle ostruzioni Clear Clog / Déboucher / Elimine la obstrucción / Desobstrução / Pulizia delle ostruzioni ti6932a ti6933a ti6943a ti6944b Engage trigger lock. Rotate tip 180°. Disengage trigger lock. Trigger gun into pail or ground to remove clog.
Page 25 Clear Clog / Déboucher / Elimine la obstrucción / Desobstrução / Pulizia delle ostruzioni ti6932a ti6945a ti6946b Engage trigger lock. Rotate tip 180°. Disengage trigger lock. Trigger gun into pail or ground to verify tip is clear. Verrouiller la gâchette. Tourner la buse de 180°.
Page 26: Repair / Réparation / Reparación / Reparação / Riparazione
Repair / Réparation / Reparación / Reparação / Riparazione Repair / Réparation / Reparación / Reparação / Riparazione Needle Replacement / Remplacement du pointeau / Cambio de la aguja / Substituição da agulha / Sostituzione dell’ago ti6932a ti6948b ti6947b Relieve pressure, Remove tip and guard Flush gun with cleaning Unscrew diffuser/seat...
Page 27 Repair / Réparation / Reparación / Reparação / Riparazione SILICON SILICONE ti6952a ti6951b ti6950b ti6949b Unscrew pivot pin from Insert punch into rear of Clean internal pas- Grease o-rings of new screw and remove gun. Tap out needle. sages of gun. needle using a non- trigger.
Page 28 Repair / Réparation / Reparación / Reparação / Riparazione Tool ti6954b ti6957b ti6953b 10. Guide new needle into An insertion tool is provided in 11. Position insertion tool 12. Grease tip of new needle. gun. needle kit 235474. This tool from kit over end of helps prevent damage to nee- needle.
Page 29 Repair / Réparation / Reparación / Reparação / Riparazione ti6962a ti6961a ti6958a ti6960b 13. Grease threads of 14. Screw diffuser/seat onto 15. Slide trigger into place 16. Attach tip and guard and diffuser/seat. Place gun nozzle. Torque to and attach with pivot pin attach gun to fluid hose.
Page 30 Repair / Réparation / Reparación / Reparação / Riparazione Changing Tip and Guard / Changement de buse et de garde-buse / Cambio de la boquilla y el portaboquillas / Substituição do bico e do protector / Sostituzione dell’ugello e della protezione ti6970a ti6967a ti6969a...
Page 31: Parts / Pièces / Piezas / Peças / Parti
Parts / Pièces / Piezas / Peças / Parti Parts / Pièces / Piezas / Peças / Parti Flex Spray Guns / Pistolets Flex / Pistolas de pulverización Flex / Pistolas de pintura Flex / Pistole a spruzzo Flex Silver Airless Spray Guns / Pistolets airless de type Silver / Pistolas de pulverización Silver / Pistolas de pintura a alta pressão Silver / Pistole a spruzzo airless Silver Flat Tip XHD Tip 311254J...
Page 32 Qty. Part No. Description Qty. 187346 WARNING TAG, not shown, mod- 220247 TIP GUARD, fine finish, model els 246240, 243283, 234237, and 235462 only 246468 only 220251 TIP GUARD, standard, models 222385 WARNING CARD not shown 235458, 235460, and 235461...
Page 33: Technical Data
Technical Data Technical Data Maximum pressure Models, page 3 Wetted parts Stainless steel, Polyethylene, Polyurethane, Nylon, PTFE Weight 18 oz (510 g) Inlet 1/4 npsm(m) Maximum material temperature 120 F (50 C) *Sound power 87dB(A) *Sound pressure 78dB(A) *Measured while spraying water-base paint, specific gravity 1.36, using a 517 tip at 3000 psi (207 bar, 20.7MPa) per ISO-3744. Caractéristiques techniques Pression maxi Modèles, page 5...
Page 34 Notes / Remarques / Notas / Notas / Note Notes / Remarques / Notas / Notas / Note 311254J...
Page 35 Notes / Remarques / Notas / Notas / Note 311254J...
Page 36: Graco Standard Warranty
With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
Page 37: Airless Accessories
Airless Accessories Essential Tools for Maximum Productivity and Performance P R O V E N Q U A L I T Y . L E A D I N G T E C H N O L O G Y .
Page 38 Pressure Rollers & Accessories Pole Guns & Accessories Strainers & Filters Fluids “Graco equipment is known for its reputation and accessibility for parts and accessories. I am always assured of them having the tips, hoses and repair kits necessary, regardless of where I am.
Page 39 Longest Warranty Proven Quality name to turn to today and as • Graco is the industry leader in contractor spray • Graco parts and accessories are made from equipment and stands behind its products. the highest quality materials to withstand your business grows.
Page 40 Contractor & FTx Guns The Contractor and FTx Guns from Graco ™ ™ are designed to be the longest lasting, Exclusive FlexSeal Design ™ most reliable airless spray guns! You’ll get the maximum performance, reliability and comfort that you’ve come to expect from Graco.
Page 41 Contractor & FTx Guns Introducing the, innovative Contractor and FTx Guns from Graco. Designed to be Exclusive FlexSeal Design the longest-lasting guns on the market ™ and continue to be the #1 choice of painting contractors! Exclusive FlexSeal Design • Totally enclosed needle design (patent pending)
Page 42 Silver Plus The Silver Plus Airless Gun is known for its ™ durability, long life, spraying performance and comfortable design. It is the preferred gun for high pressure applications. Lightweight, Rugged Design • Forged aluminum is durable to withstand harsh work environments •...
Page 43 Airless Spray Gun Specifications Contractor Gun PART NUMBER TRIGGER GUARD 288420 2-Finger RAC X 517 RAC X 288425 4-Finger RAC X 517 RAC X 288421 2-Finger RAC 5 515 RAC 5 • Repair Kit: 288488 • Working Pressure: 3600 psi (248 bar, 24.8 MPa) •...
Page 44 Gun and Hose Kits RAC X BLUEMAX II AIRLESS HOSE HOSE WPR INCLUDES 288489 Contractor 1/4 in x 50 ft 3300 psi RAC X 517 HandTite Guard, (6.4 mm x 15 m) (227 bar, 22.7 MPa) 3 ft (0.9 m) Whip Hose 288490 Contractor 3/8 in x 50 ft...
Page 45 • 1/4 in npsm(m), 1/4 in npsm(f), Maximum Working Pressure: 3600 psi (248 bar, 24.8 MPa) 181085 Gun Adapter - converts 11/16 in (17.5 mm) gun thread on competitive guns to accept the 7/8 in (22 mm) thread used on most Graco accessories.
Page 46 RAC X SwitchTips Product Line Graco has developed a full-range RAC X SwitchTip product line to cover every application on the market today! RAC X SwitchTips include larger sizes for heavy- duty applications requiring 4000 psi (276 bar) and below, and smaller sizes for the finishing work.
Page 47 RAC 5 SwitchTips RAC 5 SwitchTips are high-performance tips and the #1 selling tip on the market today. RAC 5 provides excellent fan pattern life and a high quality finish. Most Widely Used Reversible Spray Tip on the Market (Black Handle) •...
Page 48 Tip Specifications RAC X COLOR MAXIMUM WPR TYPICAL APPLICATIONS BEST USED WITH THESE TIP GUARD SWITCHTIP MATERIALS LTXxxx Blue 4050 psi (280 Residential, Commercial or Lacquers to Mastics RAC X HandTite Tip Guard bar, 28.0 MPa) Industrial Latex Paints (246215) WIDERAC COLOR MAXIMUM WPR TYPICAL APPLICATIONS...
Page 49 1. The first three digits (LTX) are Graco’s identification numbers which differentiate various tip styles. An LTX is a Graco RAC X SwitchTip. The second finish and help you save a three digits (517) represent the actual tip size (fan and orifice).
Page 50 Tip Charts RAC X SwitchTips ORIFICE SIZE - INCHES (MM) .007 .009 .011 .013 .015 .017 .019 .021 .023 .025 .027 .029 .031 .033 .035 .037 .039 .041 .043 .045 .051 .055 .061 .065 .071 (LTXxxx) (51-102) 4-6 (102-152) 207 6-8 (152-203) 8-10 (203-254) 10-12 (254-305)
Page 51 Tip Charts XHD RAC SwitchTips ORIFICE SIZE - INCHES (XHDxxx) (MM) .007 .009 .011 .013 .015 .017 .019 .021 .023 .025 .027 .029 .031 .033 .035 .037 .039 .041 .043 .045 .047 .049 (51-102) (102-152) (152-203) 8-10 (203-254) 10-12 (254-305) 12-14 (305-356) 14-16...
Page 52 Standard Graco thread RAC X, FFT, WR ™ 246437 RAC X HandTite Tip Guard 11/16 in (17.5 mm) Older style Graco Pole Guns, RAC X, FFT, WR Fits Competitive Guns with 11/16 in threads 243161 RAC 5 HandTite Tip Guard...
Page 53 Seals and Gaskets TIP GASKETS AND SEAL KITS Compatible with most fluids; easy installation without tools 246453 RAC X OneSeals - 5 pack. Use only with RAC X SwitchTip and Guard 243281 RAC 5 OneSeals - 5 pack. Use only with RAC 5 SwitchTip and Guard 248936 RAC X Solvent Seal Kit –...
Page 54 BlueMax II Hose To maximize performance, choose ™ BlueMax II high performance airless hose. With superior flexibility and durability, BlueMax II is designed to ensure you get the best results from your airless sprayer. Feel the Difference Lighter Weight • Over 10% lighter weight and increased hose flexibility improves usability while spraying under pressure Highest Safety Standards...
Page 55 Airless Hose and Hose Fittings BLuEMAX II HP HIGH PRESSuRE HOSE Synthetic-braided, 4000 psi (276 bar, 27.6 MPa) maximum working pressure rated at 180˚ (82.2˚ C) 277249 1/4 in x 3 ft (6.4 mm x 0.9 m) MxF Whip Hose 277250 1/4 in x 50 ft (6.4 mm x 15 m) FBE 277351...
Page 56 Contractor In-Line Valve, 20 in (50 cm) Fixed Extension Roller Assembly 9 in (230 mm) EvenFlow Roller Frame and 1/2 in (13 mm) Roller Cover Geosperse 12 in (305 mm) Pressure Roller. 9 in (230 mm) EvenFlow Roller Frame. Graco perforated Roller Covers. ™...
Page 57 Pressure Roller Accessories PRESSuRE ROLLER FRAMES 244271 9 in (230 mm) EvenFlow Roller Frame with 7/8 in (22 mm) thread; for use with Graco Heavy Duty Extensions 244623 9 in (230 mm) EvenFlow Roller Frame with 1/8 npt thread; for use with Graco Telescoping Extensions...
Page 58 Pole Guns Graco’s full line of Extended Reach Tools are ideal for hard-to-reach areas like soffits, stairways and vaulted ceilings. Extend your range and spray more efficiently without ladders or scaffolding. Pole Gun • For unmatched spraying performance in high or recessed areas •...
Page 59 ADAPTERS 235486 180˚ Easy Turn Directional Spray Nozzle • Sprays at a variety of angles by attaching to any Graco Extensions • Maximum Working Pressure: 3600 psi (248 bar, 24.8 MPa) • Thread Size: 7/8 in (22 mm) • Instruction Manual: 308244 45˚...
Page 60 Strainers and Gun Filters STRAINERS A strainer prevents foreign objects from entering into the pump and provides the first stage of filtration. 246385 7/8 in (unf) thread - SST Cap 390, 490, Ultra 395/495/595 Ultra Max 695 Lo-Boy, GMax 3400, ™...
Page 61 Manifold and Tip Filters THE CORRECT FILTER REDuCES TIP CLOGS Mesh Size Materials Stains, Varnishes, Lacquers, Latex, Heavy Latex, Polyurethane, Enamels (Solvent), Enamels (Latex) Block Filler, Solvent-Based Paints Solvent-Based Paints Elastomeric use with .007” - .013” .013” - .015” .015” - .029” .031”+ Tip Sizes Clean and replace filters often to ensure proper spraying pressure...
Page 62 Prevents paint and coatings from drying onto the displacement rod and packings Extends pump life 206994 8 ounces (.24 Liter) 206995 1 Quart (1 Liter) 206996 1 Gallon (3.8 Liters) HYDRAuLIC FLuID Use with Graco HydraMax and GH Sprayers 207428 1 Gallon (3.8 Liters)
Page 63 Coverage against defects in materials and workmanship on accessories and parts. “Time is money. Airless accessories are lightweight, easy to use and clean, and the performance is excellent. I buy Graco because they have the right tool for the right job.”...
Page 64 Fax 800-334-6955 ©2007-2013 Graco Inc. 300621 Rev. J 4/13 All written and visual data contained in this document are based on the latest product information available at the time of publication. Graco reserves the right to make changes at any time without notice. All other brand names or marks are used for identification purposes...
Page 65 High-Pressure Airless Accessories High-Pressure Equipment for Protective Coatings...
Page 66 Get superior spray results with Graco parts ® Rely on Graco parts and accessories for durability and long-lasting performance. Graco parts are engineered and rated specifically for high-pressure applications, which means you get the job done faster with less downtime for maintenance.
Page 67 Ordering Information To get genuine Graco accessories, see your nearest Graco distributor, or call Graco at 877-844-7226 Spray Guns and Accessories XTR-5 Airless Spray Gun, 5000 psi (345 bar, 34.5 MPa) (Ref. manual 312145) XTR500 1-in round handle, four-finger trigger, no tip...
Page 68 Ordering Information To get genuine Graco accessories, see your nearest Graco distributor, or call Graco at 877-844-7226 Ball Valves (Ref. manual 306861) 102644 Inlet: 3/4 npt(f), outlet: 3/4 npt(f) 3000 psi (207 bar, 20.7 MPa) cs, ptfe seals, nylon seats 102646 Inlet: 1/2 npt(f), outlet: 1/2 npt(f) 3000 psi (207 bar, 20.7 MPa) cs, ptfe seals, nylon seats 218901 Inlet: 1/4 npsm(m), outlet: 3/4 unf(m) 5000 psi (345 bar, 34.5 MPa) cs, ptfe seals, JIC-8 outlet 239018 Inlet: 1/4 npt(m), outlet: 1/4 npt(m) 5000 psi (345 bar, 34.5 MPa) ss, ptfe seals, nylon seats 223959 Inlet: 3/8 npt(m), outlet: 1/4 npt(m) 5000 psi (345 bar, 34.5 MPa) cs, ptfe seals, nylon seats 248271 Inlet: 1/4 npt(m), outlet: 1/4 npt(m) 5000 psi (345 bar, 34.5 MPa) ss, ptfe seals, nylon seats 235992 Inlet: 3/8 npt(m), outlet: 1/4 npt(m) 5000 psi (345 bar, 34.5 MPa) ss, ptfe seals, nylon seats 238635 Inlet: 1/4 npt(m), outlet: 1/4 npt(m) 5000 psi (345 bar, 34.5 MPa) cs, fluoroelastomer seals, nylon seats 210659 Inlet: 1/4 npt(m), outlet: 3/8 npt(m) 5000 psi (345 bar, 34.5 MPa) cs, fluoroelastomer seals, nylon seats 214037 Inlet: 1/4 npt(m), outlet: 1/4 npt(m) 5000 psi (345 bar, 34.5 MPa) cs, ptfe seals, nylon seats...
Page 69 Xtreme Sprayer Accessories 262231 Heavy-duty external regulator kit for HD carts only. Ref. manual 3A0278 262230 Light-weight external regulator kit for LW or HD carts. Ref. manual 3A0278 244841 Air motor lubricator kit. Ref. manual 406512 NXT021 Integrated air control module NXT092 Integrated air control filters, 10-pack NXT093 Extended filter with auto drain for integrated air control NXT094 Extended filter with manual drain for integrated air control NXT107 NXT air motor valve (fits all three air motor sizes). Includes motor end cap gaskets. NXT206 DataTrak upgrade kit for the NXT 2200. Converts a standard NXT motor to the DataTrak. NXT306 DataTrak upgrade kit for the NXT 3400. Converts a standard NXT motor to the DataTrak. NXT606 DataTrak upgrade kit for the NXT 6500. Converts a standard NXT motor to the DataTrak. NXT102 De-ice control repair kit. Includes knob, air valve stem and seal. NXT112 De-ice control (5-pack). Knob only.
Page 70 Ordering Information To get genuine Graco accessories, see your nearest Graco distributor, or call Graco at 877-844-7226 Elbow Fitting 100840 Fitting, elbow, street, 90, 7500 psi (517 bar, 51.7 MPa), 1/4 npt (m), 1/4 npt (f) 164259 Fitting, elbow, street, 90, 7250 psi (500 bar, 50 MPa), 3/8 npt (m), 1/4 npt (f) 155699 Fitting, elbow, street, 90, 7250 psi (500 bar, 50 MPa), 3/8 npt (m), 3/8 npt (f) 158683 Fitting, elbow, street, 90, 7400 psi (510 bar, 51 MPa), 1/2 npt (m), 1/2 npt (f) 166999 Fitting, elbow, street, 90, reducing, 7250 psi (500 bar, 50 MPa), 1/2 npt (m), 1/4 npt (f) 15M987 Elbow, 60, street, 7,250 psi (500 bar, 50 MPa), 1/2 npt (m), 1/2 npt (f) Nipple 166606 Nipple, reducing, Hex, 7000 psi (483 bar, 48.3 MPa), 3/4 npt (m), 3/8 npt (m), 4 1/2 in 158979 Nipple, reducing, Hex, 7250 psi (500 bar, 50 MPa), 1/2 npt (m), 3/8 npt (m), 2 3/4 in 164672 Nipple, reducing, Hex, 7250 psi (500 bar, 50 MPa), 3/8 npt (m), 1/4 npsm, 1 3/8 in 162449 Nipple, reducing, Hex, 7400 psi (510 bar, 51 MPa), 1/2 npt (m), 1/4 npt (m), 1 5/8 in...
Page 71 Ordering Information To get genuine Graco accessories, see your nearest Graco distributor, or call Graco at 877-844-7226 Xtreme-Duty High-Pressure Hoses 4500 psi 5600 psi 7250 psi Xtreme-Duty 4500 psi (310 bar) High Pressure Hose Xtreme-Duty 5600 psi (386 bar) High Pressure Hose...
Page 72 ©2009 Graco Inc. 339361 Rev. A 11/09 All written and visual data contained in this document are based on the latest product information available at the time of publication. Graco reserves the right to make changes at any time without notice. All other brand names or marks are used for identification...
