Thank you for buying this product, our company is
sure that you will be more than satisfied with the
product's performance. The product is supplied with
a "Warnings" leaflet and an "Instruction booklet".
These should both be read carefully as they provide
important information about safety, installation,
operation and maintenance. This product complies
with the recognized technical standards and safety
regulations.
1) GENERAL OUTLINE
The control panel is supplied by the manufacturer
with standard settings. Any alteration must be set
by means of the incorporated display programmer
or by means of UNIPRO. The Control unit
completely supports the EELINK protocol. Its main
characteristics are:
- Control of two low-voltage motors up to 40W
power
- Electronic torque setting with obstacle detection
- Limit-switch control inputs
- Separate inputs for safety devices
- Incorporated rolling-code radio receiver with
transmitter cloning
- Soft start and close
The IGEA-BT (24V) is suitable for residential use
and has been designed for swing gates and swing
doors. The drive arm, built with a special anti-
shearing shape, allows the leaves to be moved
when the controller is considerably out of place
with respect to the fulcrum of the leaves. The non-
reversible electro-mechanical motor maintains the
stop during closing and opening. The release knob
with personalized key, fitted outside each operator,
makes manual operation extremely easy.
2) SAFETY
If correctly installed and used, this automation
device satisfies the required safety level standards.
However, it is advisable to observe some practical
rules in order to avoid accidental problems. Before
using the automation device, carefully read the
operation instructions and keep them for future
reference.
• Keep children, persons and things outside the
automation working area, particularly during
operation. An incorrect installation or improper
use of the product can cause damage to persons,
animals or things.
• Keep radio control or other control devices out of
children's reach, in order to avoid any unintentional
automation activation.
• Do not intentionally oppose the leaf movement.
• BFT and Real Carriage Door & Sliding Hardware
declines all responsibility for any consequences
resulting from failure to observe Good Technical
Practice when constructing closing structures (door,
gates etc.), as well as from any deformation which
might occur during use.
• The installation must comply with the provisions
set out by the following directives: 89/336/
CEE, 73/23/EEC, 98/37/EEC and subsequent
amendments.
• Do not attempt to open the gate/door by hand, if
the actuator has not been released by means of the
appropriate release knob.
• Do not modify the automation components.
• In case of malfunction, disconnect the power
supply, activate the emergency release to gain
access to the actuator and request the assistance
of a qualified technician (installer).
• Before proceeding to any external cleaning
operation, disconnect the main powers supply and
at least one of the battery pole, if fitted.
• Check that grounding is carried out correctly:
connect all metal parts for closure (doors, gates
etc.) and all system components provided with an
earth terminal.
• Fit all the safety devices (photocells, electric edges
etc.) which are needed to protect the area from
any danger caused by squashing, conveying and
shearing, according to and in compliance with the
applicable directives and technical standards.
• Keep the photocell optical components and
luminous signal indication devices clean. Check
that the photocells are not obscured by branches or
